Register addresses are displayed in the Modicon™ 5-digit addressing format. I.e.
Register 65=40065 (subtract 1 for direct addressing).
Modbus (RTU) Registers
16 Bit Unsigned
Address Function
40001 Alarm status (SP1=Bit 0,
SP2=Bit 1, SP3=Bit 2, SP4=Bit 3)
40065– Hysteresis (SP1=40065, SP2=
40068 40066, SP3=40067, SP4=40068)
40071– Make delay (SP1=40071, SP2=
40074 40072, SP3=40073, SP4=40074)
A.3 - Ranger A mode
Ranger A is a continuous output, used to drive remote displays and other instru-
ments in the Rinstrum™ range. (Ranger is a trade name belonging to Rinstrum Pty
Ltd.) Ranger A output strings are constructed as shown:
<Start> <Sign> <Output Value> <Status> <End>
Start - STX character (ASCII 02)
Sign - Output value sign (space for + and dash for -)
Output Value - Seven character ASCII string containing the current output value and
decimal point. (If there is no decimal point, then the fi rst character is a space.
Leading zero blanking applies.)
Status - Single character output value status. 'U'=Under, 'O'=Over, 'E'=Error.
End - ETX character (ASCII 03)
Copyright © 2015 Defi ne Instruments
32 Bit Signed (2 x 16 Bit)
LSW MSW Function
40513 40514 Process display
40525 40526 Peak
40527 40528 Valley
40535 40536 Setpoint 1–4
–541 –542 (SP1=40535, SP2=40537,
SP3=40539, SP4=40541)
40587 40588 D/A scale low value
40591 40592 D/A scale high value
