FRONT PANEL & DISPLAY
2.1 - Front panel
The SP LED's are used to indicate
active setpoints.
The 'Up' button is used to access
the Input Setup & Calibration menu
(Section 6).
It is also used to scroll through options
or increase values in the setup menu.
The 'Prog' button is used to save
your settings and advance to the next
step in the setup process.
The 'Down' button is used to access
the Setpoint Setup menu (Section 7)
and the Setpoint Open Access menu
(Section 8).
It is also used to scroll through options
or decrease values in the setup menu.
2.2 - Display brightness
To adjust the display brightness, press the
main display. BRI appears and toggles with the current brightness setting.
Use the
and
Copyright © 2015 Defi ne Instruments
buttons to adjust the LED backlight, and then press
96
mm
(3.78")
and
buttons together from the
TEX-BAR-MAN-15V05 (0903)
48
mm (1.89")
to fi nish.
