Summary of Contents for Planet FNSW-1600S

  • Page 1 NOVASwitch FNSW-1600S FNSW-2400S 10/100Base-TX Fast Ethernet Smart Switch...
  • Page 2: Fcc Warning

    In this User's Manual, "Switch" is used for FNSW- 1600S/2400S, “NovaSwitch” Ethernet Switch, where “switch” represent the third part switch. The term “port 16/24” or “port 12/20” represent port 16 or 12 of FNSW-1600S and port 24 or 20 of FNSW-2400S. protection against harmful PLANET’s 19”-range...
  • Page 3: Table Of Contents

    EATURES 2.2 F ... 8 RONT ANEL 2.2.1 Ports Speed... 8 2.2.2 Cabling ... 8 2.2.3 MDI Switch... 9 2.2.4 Status LEDs ... 9 2.3 T ... 10 ANEL 2.3.1 Extension Slot... 10 2.3.2 Power Connector ... 10 2.3.3 Fan ...
  • Page 4 5.2 H UPLEX 5.3 F ... 24 THERNET 5.4 A ... 25 EGOTIATION 5.5 MAC A ... 25 DDRESS ABLE 5.6 S ... 26 AMPLE PPLICATION 6. TROUBLESHOOTING... 27 7. PRODUCT SPECIFICATIONS... 29 8. RJ-45 PIN ASSIGNMENT... 30 8.1 S TRAIGHT HROUGH ROSSOVER...
  • Page 5: Unpacking Information

    Thank you for purchasing a PLANET NOVASwitch series Ethernet Switches. Before continuing, please check the contents of the product package. This product package should contain the following items: One NOVASwitch Ethernet Switch One Power Cord Two Rack-Mounting Brackets with Attachment Screws This User’s Guide...
  • Page 6 This page intentionally left blank! PLANET NOVASwitch series...
  • Page 7: Product Introduction

    2.1 Key Features Compliant with IEEE802.3 and 802.3u standards for 10Base-T / 100Base-TX/FX. 16-port/24-port Fast Ethernet Switch, pure 10/100Base- Wire-speed "Store-and-Forward" filtering/forwarding eliminates bad data packets with minimal delay 100Base-TX ports automatically sense and set optimal...
  • Page 8: Front Panel

    (rear) At the mean time, the RJ- 45 port of #16/24 will being disabled. The Half-/Full-Duplex is selectable by the DIP-switch on the module. Please refer to the installation guide of the extension module for more. 2.2.2 Cabling...
  • Page 9: Mdi Switch

    Table A: Supported port list 2.2.3 MDI Switch Each numbered port of the Switch are MDI-X port, you can direct use straight cable for the connection to your end nodes. However, port 12/20 is with one push button. To push the button to convert the port to MDI-II port for direct hub cascade.
  • Page 10: The Rear Panel

    2.3 The Rear Panel Figure 2: Rear View of the Switch 2.3.1 Extension Slot The Switch port 16/24 can be a 100Base-FX switching port as the extension module installed. As the module installed, the port 16/24 on the front panel will be disabled.
  • Page 11: Rs-232 Console

    2.3.4 RS-232 Console The RS-232 console helps to manage the Switch. Please use the cable with the package. Attach one end to the switch and the other to your PC’s COM1 or COM2. Then startup your console program like Windows Hyper Terminal, or ProCOMM with parameter: 19200, n, 8, 1.
  • Page 12 This page intentionally left blank! PLANET NOVASwitch series...
  • Page 13: Installation

    However, the Console port will helps to have more setting to your Switch. To get the best use of the Switch, many things need to be considered first. See Chapter 5 for details.
  • Page 14: Power Notes

    Supply) for your device. It will prevent you from network data loss or network downtime. 2. In some area, installing a surge suppression device may also help to protect your hub from being damaged by unregulated surge or current to the Switch or the power adapter. PLANET NOVASwitch series...
  • Page 15: Console Configuration

    4. CONSOLE CONFIGURATION On the rear panel, there is one console port for configuring the switch. The attached cable in the packing box is used to connect to PC’s RS232C port (COM1, or COM2). Following the instructions below to configure the switch.
  • Page 16: Trunk/ Vlan Setting

    (1) Trunking (2) VLAN Setting (3) Exit >> Purpose: Set up the TRUNKING or VLAN Group Be noted: the Switch support either TRUNKING or VLAN. As soon as one is enabled, it also means the other is turned off at the mean time.
  • Page 17: Vlan Group Setting

    : 3, 7, 11, 15, 19, 23 : 4, 8, 12, 16, 20, 24 Once trunk-port enabled, your are free to connect the Switch to any 3 party’s standard switch with two links or four links without fears of network looping. The trunks will two or four times the bandwidth between the Switch to the connected switch.
  • Page 18 Toggle Group(1~4) to add/remove (5)Update VLAN setting >>4 Toggle Group(1~4) to add/remove (5)Update VLAN setting >>5 With the setting below, the Switch will separate port 1 to port 4 into 4 VLANs, i.e. those ports can not reach each other. However, they can still access port 5 without problem.
  • Page 19: Port Status

    01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 AutoN BackP Pause SWITCH in 1-VLAN mode Any key to quit!! Purpose: Display the Port Status group AutoN for “Auto-Negotiaion”, BackP for “Back Pressure”, half-duplex...
  • Page 20: Factory Setting

    Select (1)Port Mode (2)Pause (3)Back Pressure>>2 Select Pause in FDX (1)Enable (2)Disable>>1 PAUSE frame is used while the devices that connect to the Switch runs in Full-duple mode. In full-duplex mode, once the Switch can not handle the incoming packets, the Switch send out the PAUSE frame to warn the device hold the transmission.
  • Page 21: Redundant Link Setting

    Set up the Factory default value, the system will be Auto Reboot 4.6 Redundant Link Setting Entry: Select “5” from < Console Manu> Redundant Link on Port-20/Port-19(19 is Backup link) (1)Enable (2)Disable >>1 Purpose: Set up Redundant Link. So the backup line enabled once the primary line is absent.
  • Page 22 This page intentionally left blank! PLANET NOVASwitch series...
  • Page 23: Optimizing Configuration

    5. OPTIMIZING CONFIGURATION 5.1 Prior to Installation Before installing the Switch and connecting network devices, it is important to plan the new network layout. Consider: Dedicated Bandwidth: hardware can improve if they have their own direct connection with dedicated 10 or 100Mbps bandwidth.
  • Page 24: Fast Ethernet

    1 Class-II Repeater 205m 2 Class-II Repeaters NOTES: 1) "DTE" is an end-station such as a PC or switch port 2) Copper+Fiber assumes the max. Copper length is used 3) "Repeater" is a standard hub, NOT a Switch. 4) Half-/Full-Duplex. Fiber's distance depends on mode.
  • Page 25: Auto-Negotiation

    This 6-byte ID is called the MAC (Media Access Control) Address. Every Ethernet data packet includes both source and destination addresses. The Switch can automatically learn and store up to 2K MAC addresses. The MAC address table is volatile: it disappears when the switch is powered off or reset.
  • Page 26: Sample Application

    5.6 Sample Application The optimal application for the Switch, no matter with the extension module or not, is as a "big pipe" backbone interconnecting file servers with bandwidth-hungry workgroups, departments, and offices. In the figure, the first FNSW-2400S links to another switch‘s Uplink (MDI-II) port, some ports connect to 100Mbps Workstations, and attached to file servers at 200Mbps.
  • Page 27: Troubleshooting

    4 Check that the attached device is not set to HECKPOINT dedicated full-duplex. (Some devices use a physical or software switch to change duplex modes. Auto-negotiation may not recognize this type of full-duplex setting. After setting the DIP-switch of the 100Base-FX...
  • Page 28 This page intentionally left blank! PLANET NOVASwitch series...
  • Page 29: Product Specifications

    7. PRODUCT SPECIFICATIONS RODUCT FNSW-1600S / FNSW-2400S 16/24 10/100Base-TX RJ-45 (MDI-X) ETWORK ORTS UFFER EMORY 1 open slot (shared with port 16/24 for optional module) XTENSION 100Base-TX Cat. 5 UTP, RJ-45 EDIA UPPORT 10Base-T Cat. 3, 4, 5 UTP RJ-45...
  • Page 30: Pin Assignment

    8. RJ-45 PIN ASSIGNMENT Numbered Ports (MDI-X port) Input Receive Data + Input Receive Data - Output Transmit Data+ Input Receive Data + Output Transmit Data- 4,5,7,8 Not used Schematics for both straight and crossover twisted-pair cable are shown below. (Note that crossover cable is only required if you cascade hubs via the RJ-45 station ports;...
  • Page 31 ISO9002 EMFNSWSv1...
