Planet FNSW-4800 Datasheet

48-Port 10/100Mbps Fast Ethernet Switch
T
he Planet's FNSW-4800 is a 48-Port 10/100Mbps Fast Ethernet switch,
perfectly designed for low cost, high performance, and easy installation,
the PLANET 48-Port 10/100Base-TX Fast Ethernet Switch in your best
choice of switched networks.
With increasing bandwidth requirements for local area networks, PLANET's
FNSW-4800 Fast Ethernet Switch is the ideal option to alleviate bottlenecks
in Client / server and peer-to-peer environments in a cost-effective way.
The switch provides a combination of 48 Fast Ethernet Switching ports that
provide users with high-speed network connections.
With it's Auto-Negotiation capability, all the RJ-45/STP ports of FNSW-4800
can be configured to speeds of 10/20Mbps or 100/200Mbps automatically.
In addition, the product is equipped with the MDI/MDI-X auto detection
for easily plug and play connection, regardless of cabling types-straight
through or crossover.
The high-performance throughput at filtering / forwarding rate is up to
14880 packets per second in 10Mbps, and 148800 packets per second in
100Mbps. Along with its dynamic shared memory buffer, the FNSW-4800
can boost bandwidth, eliminate unnecessary traffic and relieve congestion
on your critical server path.
Data Sheet
1
Key Feature
•
Comply with IEEE 802.3 and IEEE 802.3u standards for
10/100Base-TX
•
48-Port 10/100Mbps Fast Ethernet Switch
•
Each Switching ports support auto-negotiation-10/20,
100/200Mbps supported
•
Auto-MDI/MDI-X detection on each RJ-45 port
•
Prevents packet loss with back pressure (half-duplex) and
802.3x PAUSE frame flow control (full-duplex)
•
High performance Store and Forward architecture, broadcast
storm control, runt/CRC filtering eliminates erroneous packets
to optimize network bandwidth
•
8K MAC address table, automatic source address learning
and ageing
•
2.5Mbit embedded memory for packet buffers
•
Support up to 1522 bytes packet and 802.1Q VLAN
transparent
•
19-inch rack mount size
•
Internal full-range power supply suitable for worldwide use
•
EMI standards comply with FCC, CE class A
FNSW-4800
