Model appears very 'stringy'
• Ensure that the filament diameter is set to match your filament spool (1.75mm), then try
creating a new GCODE before printing again
• Check you are using the correct temperature for the filament used
Print stopped halfway
• Check that the GCODE file is complete and not corrupt
• Check the original model file
The motor does not stop at the end of axis
Check that the stop micro switches are aligned with the motor mount and registering.
The print head/bed does not move
Check the part can be moved by hand when stepper motor is disabled. Clear anything that is
blocking the path
10.1.2 Connectivity Problems
My 3D Printer isn't turning on
Check that you have correctly inserted the power cable into the rear of the Control Box, the power
cord is plugged into the mains outlet and that the Control Box power switch is on.
Micro SD Card not shown
• Please ensure your MicroSD Card is 32GB or less
• Please ensure your MincroSD Card is formatted as FAT32
• Navigate SD Card,select Unmounts SD Card, then select Mount SD Card.Your MicroSD Card
should now appear in the menu.
33
