Reference Manual
00809-0100-4727, Rev EA
October 2010
Rosemount 8700 Series
Magnetic Flowmeter Sensors
www.rosemount.com
HongKong|UK|China
www.aotewell.com
sales@aotewell.com
Industry Automation
+86-755-8660-6182

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8700 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Rosemount 8700 Series

Summary of Contents for Rosemount 8700 Series

  • Page 1 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA October 2010 Rosemount 8700 Series Magnetic Flowmeter Sensors www.rosemount.com sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 2 Aotewell Ltd www.aotewell.com Industry Automation sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 3 Within the United States, Rosemount Inc. has two toll-free assistance numbers. Customer Central: 1-800-999-9307(7:00 a.m. to 7:00 p.m. CST) Technical support, quoting, and order-related questions.
  • Page 4 Aotewell Ltd www.aotewell.com Industry Automation sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...

  • Page 5: Table Of Contents

    Sensor Connections ........2-18 Rosemount Sensors ........2-18 Transmitter to Sensor Wiring .
  • Page 6 Dimensional Drawings ........A-20 Rosemount Flanged Sensors ......A-36 Rosemount High-Signal Magmeter System .

  • Page 7: Manual Description

    Rosemount 8705, 8707 High-Signal, and 8711 Magnetic Flowmeter Sensor. Attempting to install and operate the Rosemount 8705, 8707 High-Signal, or 8711 Magnetic Flowmeter Sensor without reviewing the instructions contained in this manual could result in personal injury or equipment damage.

  • Page 8: Safety Information

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 SAFETY INFORMATION Procedures and instructions in this manual may require special precautions to ensure the safety of the personnel performing the operations. Refer to the safety messages listed at the beginning of each section before performing any operations.

  • Page 9: Safety Messages

    Verify that the operating environment of the sensor and transmitter is consistent with the appropriate hazardous area approval. Do not connect a Rosemount transmitter to a non-Rosemount sensor that is located in an explosive atmosphere. www.rosemount.com sales@aotewell.com...
  • Page 10 Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Explosions could result in death or serious injury: Installation of this transmitter in an explosive environment must be in accordance with the appropriate local, national, and international standards, codes, and practices. Please review the approvals section of this reference manual for any restrictions associated with a safe installation.

  • Page 11: Sensor Handling

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 SENSOR HANDLING Handle all parts carefully to prevent damage. Whenever possible, transport the system to the installation site in the original shipping containers. PTFE-lined sensors are shipped with end covers that protect it from both mechanical damage and normal unrestrained distortion.

  • Page 12: Sensor Mounting

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 SENSOR MOUNTING Physical mounting of a sensor is similar to installing a typical section of pipe. Conventional tools, equipment, and accessories (bolts, gaskets, and grounding hardware) are required.
  • Page 13 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure 2-4. Incline or Decline FLOW Orientation FLOW Horizontal installation should be restricted to low piping sections that are normally full. Orient the electrode plane to within 45 degrees of horizontal in horizontal installations.

  • Page 14: Flow Direction

    Rosemount 8700 Series October 2010 The electrodes in the Rosemount 8711 are properly oriented when the top of the sensor is either vertical or horizontal, as shown in Figure 2-6. Avoid any mounting orientation that positions the top of the sensor at 45 degrees from the vertical or horizontal position.

  • Page 15: Installation (Flanged Sensor)

    The following section should be used as a guide in the installation of the (FLANGED SENSOR) flange-type Rosemount 8705 and Rosemount 8707 High-Signal Sensors. Refer to page 2-10 for installation of the wafer-type Rosemount 8711 Sensor. Gaskets The sensor requires a gasket at each of its connections to adjacent devices or piping.
  • Page 16 All sensors require a second torquing 24 hours after initial flange bolt tightening. Table 2-1. Flange Bolt Torque Specifications for Rosemount 8705 and 8707 High-Signal Sensors PTFE/ETFE liner...
  • Page 17 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 2-2. Flange Bolt Torque and Bolt Load Specifications for Rosemount 8705 PTFE/ETFE liner PN10 PN 16 PN 25 PN 40 Size Code Line Size (Newton-meter) (Newton) (Newton-meter) (Newton) (Newton-meter) (Newton) (Newton-meter) (Newton) -in.

  • Page 18: Installation (Wafer Sensor)

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 2-3. Flange Bolt Torque and Bolt Load Specifications for Rosemount 8705 Polyurethane Liner PN 10 PN 16 PN 25 PN 40 Size Code Line Size (Newton-meter) (Newton) (Newton-meter) (Newton) (Newton-meter) (Newton) (Newton-meter) (Newton) -in.

  • Page 19: Flange Bolts

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 2-4. Stud Specifications Nominal Sensor Size Stud Specifications 0.15 – 1-in. (4 – 25 mm) 316 SST ASTM A193, Grade B8M Class 1 threaded mounted studs –...

  • Page 20: Installation (Sanitary Sensor)

    The sensor requires a gasket at each of its connections to adjacent devices or piping. The gasket material selected must be compatible with the process fluid and operating conditions. Gaskets are supplied with all Rosemount 8721 Sanitary sensors except when the process connection is an IDF sanitary screw type.

  • Page 21: Process Leak Protection (Optional)

    00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 PROCESS LEAK The Rosemount 8705 and 8707 High-Signal Sensor housing is fabricated from carbon steel to perform two separate functions. First, it provides PROTECTION shielding for the sensor magnetics so that external disturbances cannot (OPTIONAL) interfere with the magnetic field and thus affect the flow measurement.

  • Page 22: Relief Valves

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Relief Valves The first optional configuration, identified by the W1 in the model number option code, uses a completely welded coil housing. This configuration does not provide separate electrode compartments with external electrode access.

  • Page 23: Conduit Ports And Connections

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure 2-15. Housing Configuration — Sealed Electrode Compartment (Option Code W3) Fused Glass Seal O-ring Seal Sealed Electrode Compartment - 27 NPT Optional: Use drain port to...

  • Page 24: Conduit Cables

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Conduit Cables Run the appropriate size cable through the conduit connections in your magnetic flowmeter system. Run the power cable from the power source to the transmitter.

  • Page 25: Electrical Considerations

    Transmitter Input Power The Rosemount transmitter is designed to be powered by 90-250 Vac, 50–60 Hz or 12–42 Vdc. The eighth digit in the transmitter model number designates the appropriate power supply requirement.

  • Page 26: Sensor Connections

    This section covers the steps required to physically install the transmitter including wiring and calibration. Rosemount Sensors To connect the transmitter to a non-Rosemount sensor, refer to the appropriate wiring diagram in “Universal Sensor Wiring Diagrams” on page E-1. The calibration procedure listed is not required for use with Rosemount sensors.
  • Page 27 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Rosemount recommends using the combination signal and coil drive for N5, E5 approved sensors for optimum performance. Remote transmitter installations require equal lengths of signal and coil drive cables. Integrally mounted transmitters are factory wired and do not require interconnecting cables.
  • Page 28 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 2-20 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...

  • Page 29: Calibration

    Appendix A: Reference Data and Appendix C: Field-Removable Electrodes. CALIBRATION Rosemount sensor are wet calibrated at the factory. They do not need further calibration during installation. GROUNDING Process grounding the sensor is one of the most important details of sensor installation.
  • Page 30 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure 3-1. No Grounding Options or Grounding Electrode in Lined Pipe Figure 3-2. Grounding with Grounding Rings or Lining Protectors Grounding Rings or Lining Protectors sales@aotewell.com...

  • Page 31: Material Selection

    MATERIAL SELECTION Several liner types, electrode materials, and electrode types are available on Rosemount Magnetic Sensor to ensure compatibility with virtually any application. See Appendix A: for information on liner types, on electrode materials, and electrode types. For further guidance on selecting materials, refer to the Magnetic Flowmeter Material Selection Guide located on Rosemount.com (document number 00816-0100-3033).

  • Page 32: Magnetic Flowmeter Sizing

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 MAGNETIC Flowmeter Sizing FLOWMETER SIZING Because of its effect on flow velocity, sensor size is an important consideration. It may be necessary to select a magnetic flowmeter that is larger or smaller than the adjacent piping to ensure the fluid velocity is in the specified measuring range of the sensor.
  • Page 33 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 3-3. Line Size vs. Conversion Factor Nominal Line Size Liters Per Inches (mm) Gallons Per Minute Factor Minute Factor 0.30 (8) 0.220 2.732 ½ (15) 0.947...
  • Page 34 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 3-4. Line Size vs. Velocity/Rate Minimum/Maximum Flow Rate Gallons per Minute Liters per Minute Nominal Line Size in at 0.04 ft/s at 1 ft/s at 39 ft/s at 0.012 m/s...

  • Page 35: Safety Information

    FM or CSA approval. Do not connect a Rosemount transmitter to a non-Rosemount sensor that is located in an explosive atmosphere. Mishandling products exposed to a hazardous substance may result in death or serious injury.

  • Page 36: Installation Check And Guide

    Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 INSTALLATION CHECK Use this guide to check new installations of Rosemount magnetic flowmeter AND GUIDE systems that appear to malfunction. Before You Begin Transmitter Apply power to your system before making the following transmitter checks.

  • Page 37: Diagnostic Messages

    Problems in the magnetic flowmeter system are usually indicated by incorrect MESSAGES output readings from the system, error messages, or failed tests. Consider all sources in identifying a problem in your system. Table 4-1. Rosemount Basic Diagnostic Messages Local Display Error Message Message (English)
  • Page 38 Process Noise” on page 4-7 Consult factory Low conductivity fluids Trim electrode and coil wires - refer to “Installation” on (below 10 microsiemens/cm) page 2-1 Table 4-3. Rosemount SMART Meter Verification Diagnostic Messages Message Potential Cause Corrective Action Transmitter Calibration Verification Verify pass/fail criteria...

  • Page 39: Transmitter Troubleshooting

    Complete the Noisy Process Basic procedure; in process Consult factory Electrode coating Use replaceable electrodes in Rosemount 8705. Use a smaller sensor to increase flow rate above 3 ft/s. Periodically clean sensor. Air in line Move the sensor to another location in the process line to ensure that it is full under all conditions.
  • Page 40 Sensor calibration number Units Line size Electrode coating Use bulletnose electrodes in the Rosemount 8705 Sensor. Downsize the sensor to increase the flow rate above 3 ft/s. Periodically clean the sensor Air in line Move the sensor to another location in the process line to...

  • Page 41: Quick Troubleshooting

    To interpret the results, the hazardous location certification for the sensor must be known. Applicable codes for the Rosemount 8705 are N0, N5, and KD. Applicable codes for the Rosemount 8707 are N0 and N5. Applicable codes for the Rosemount 8711 are N0, N5, E5, and KD.
  • Page 42 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 4-5. Sensor Test Sensor Required Measuring at Test Location Equipment Connections Expected Value Potential Cause Corrective Action   A. Sensor Installed or Multimeter 1 and 2 = R 2...

  • Page 43: Step 4: Uninstalled Sensor Tests

    Sensor Tests interpret the results, the hazardous location certification for the sensor must be known. Applicable codes for the Rosemount 8705 are N0, N5, and KD. Applicable codes for the Rosemount 8707 are N0 and N5. Applicable codes for the Rosemount 8711 are N0, N5, E5, and KD.
  • Page 44 Measure both electrodes. One electrode should result in an open reading, while  the other electrode should be less than 275 Table 4-7. Uninstalled Rosemount 8711 Wafer Sensor Tests Hazardous Location Certification Measuring at Connections N5, E5, CD 18 and Electrode ...

  • Page 45: Rosemount 8700 Series Product Specifications Overview

    High Signal System Performance Specifications ..page A-7 Rosemount Flanged Sensor Specifications ... page A-9 Rosemount 8711 Wafer Sensor Specifications ..page A-13 Rosemount 8721 Sanitary Sensor Specifications .
  • Page 46 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table A-2. Lining Material Selection Liner Material General Characteristics • Best chemical resistance • Better abrasion resistance than PTFE • Best high temperature capabilities • -20 to 350 °F (-29 to 177 °C) PTFE •...
  • Page 47 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table A-3. Electrode Selection Electrode Material General Characteristics 316L Stainless Steel • Good corrosion resistance • Good abrasion resistance • Not recommended for sulfuric or...
  • Page 48 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table A-4. Grounding Options Grounding Options General Characteristics No Grounding Options • Acceptable for conductive unlined (grounding straps) pipe • Grounding straps provided at no cost Grounding Electrodes •...

  • Page 49: E-Series Performance Specifications

    Includes the combined effects of linearity, hysteresis, repeatability, and calibration uncertainty. Rosemount E Series with 8705/8707 Sensor: Standard system accuracy is ±0.25% of rate ±1.0 mm/sec from 0.04 to 6 ft./s (0.01 to 2 m/s); above 6 ft./s (2 m/s), the system has an accuracy of ±0.25% of rate ±1.5 mm/sec.
  • Page 50 0.04 and 3.0 ft./s (0.01 and 1 m/s), the system has an accuracy of ±0.015 ft./s (0.005 m/s). Rosemount E-Series with Other Manufacturers’ Sensors: When calibrated in the Rosemount Flow Facility, system accuracies as good as 0.5% of rate can be attained. There is no accuracy specification for other manufacturers’ sensors calibrated in the process line.

  • Page 51: High Signal System Performance Specifications

    Includes the combined effects of linearity, hysteresis, repeatability, and calibration uncertainty. Rosemount High Signal Flowmeter System System accuracy is ±0.5% of rate from 3 to 30 ft./s (1 to 10 m/s); between 0.04 and 3.0 ft./s (0.01 and 0.3 m/s), the system has an accuracy of ±0.015 ft./s (0.005 m/s).
  • Page 52 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Repeatability ±0.1% of reading Response Time 0.2 seconds maximum response to step change in input Stability ±0.1% of rate over six months Ambient Temperature Effect ±1% per 100 °F (37.8 °C)

  • Page 53: Rosemount Flanged Sensor Specifications

    –36 in. (15–900 mm) for Rosemount 8705 3–36 in. (80–600 mm) for Rosemount 8707 Interchangeability Rosemount 8705 Sensors are interchangeable with 8732 and 8712E Transmitters. Rosemount 8707 High-Signal Sensors are interchangeable with 8732, 8712E, and 8712H High-Signal Transmitters. System accuracy is maintained regardless of line size or optional features.
  • Page 54 This requires the user to install sealed IP68 approved cable glands, conduit connections, or conduit plugs. For more details on proper installation techniques for an IP68 / submersible application, reference Rosemount Technical Document 00840-0100-4750 available on www.Rosemount.com. Conductivity Limits Process liquid must have a conductivity of 5 microsiemens/cm (5 micromhos/cm) or greater for 8705.

  • Page 55: Flanged Sensor Physical Specifications

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table A-7. Temperature vs. Pressure Limits Sensor Temperature vs. Pressure Limits for AS2129 Table D and E Flanges (4- to 24-in. line sizes) Pressure @ -200 to 50 °C @ 100 °C...
  • Page 56 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Process Connections ASME B16.5 (ANSI) Class 150, Class 300, Class 600, Class 900, Class 1500, or Class 2500 0.5- to 36-in. (Class 150) 0.5- to 30-in. (Class 300) 0.5- to 24-in.

  • Page 57: Rosemount 8711 Wafer Sensor Specifications

    Line Sizes 0.15-in. through 8 -in. (4 through 200 mm) Interchangeability Rosemount 8711 Sensors are interchangeable with 8732 and 8712E Transmitters. System accuracy is maintained regardless of line size or optional features. Each sensor nameplate has a sixteen-digit calibration number that can be entered into a transmitter through the Local Operator Interface (LOI) or the Field Communicator.

  • Page 58: 8711 Physical Specifications

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Maximum Safe Working Pressure at 100 °F (38 °C) ETFE Lining Full vacuum to 740 psi (5.1 MPa) for 0.5- through 8-in. (15 through 200 mm) sensors PTFE Lining Full vacuum through 4-in.
  • Page 59 Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 0.15- through 1-in. (4 through 25 mm): 316 SST, ASTM A193, Grade B8M, Class 1 threaded mounting studs; ASTM A194, Grade 8M heavy hex nuts; SAE per ANSI B18.2.1, Type A, Series N flat washers.

  • Page 60: Rosemount 8721 Sanitary Sensor Specifications

    Line Sizes - 4 in. (15–100 mm) Sensor Compatibility and Interchangeability The Rosemount 8721 Sensors are interchangeable with Rosemount 8732 and 8712E transmitters. System accuracy is maintained regardless of line size or optional features. Each sensor nameplate has a sixteen-digit calibration number that can be entered into the transmitter through the Local Operator Interface (LOI) or the Field Communicator.

  • Page 61: 8721 Physical Specifications

    This requires the use of sealed IP68 approved cable glands, conduit connections, or conduit plugs. For more details on proper installation techniques for an IP 68/submersible application, reference Rosemount Technical Document 00840-0100-4750 available on www.rosemount.com. 8721 PHYSICAL...
  • Page 62 80% Platinum-20% Iridium with Ra < 15in. (0.38 m) Process Connections The Rosemount 8721 Sanitary Sensor is designed using a standard IDF fitting as the basis for providing a flexible, hygienic interface for a variety of process connections. The Rosemount 8721 Sensor has the threaded or “male”...
  • Page 63 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 ANSI Weld Nipple DIN 11850 Weld Nipple DIN 11851 (Imperial and Metric) DIN 11864-1 form A DIN 11864-2 form A SMS 1145 Cherry-Burrell I-Line Process Connection Material 316L Stainless Steel with Ra <...

  • Page 64: Dimensional Drawings

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 DIMENSIONAL DRAWINGS  Figure A-1. 0.5-in. through 2-in. Slip-on Flanges - Low pressure (P ANSI 300#) A-20 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 65 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table A-9. 0.5-in. through 2-in. Slip-on Flanges (mm) Overall Length Liner Dia. on Sensor Dim “A” Body Dia. CL to UMB Face DIM Weight lbs.
  • Page 66 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010  Figure A-2. 3-in. through 36-in. Slip-on Flanges - Low pressure (P ANSI 300#) A-22 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 67 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table A-10. 3-in. through 36-in. Slip-on Flanges (mm) Overall Length Liner Dia. on Lift Ring Sensor Dim “A” Dim “A” Body Dia. CL to UMB...
  • Page 68 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table A-11. 14-in. through 36-in. with Slip-On Flanges (mm) Overall Length Lift Ring Dim. “A” Dim. “A” Body Dim. CL to UMB Liner on Face Height Dim.
  • Page 69 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-3. 0.5-in. through 36-in. with W3 Option Table A-12. Body Width with Electrode Access (W3) Body Width with Body Width with Size -- in (mm) All Flanges W3 DIM “E”...
  • Page 70 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-4. Lining Protector / Grounding Ring Assembly Table A-13. When Liner Protectors Are Used Add This Value to “A” (Overall Flange Style Sensor Size Length) 0.5-in.
  • Page 71 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-5. 0.5-in. to 24-in. with slip-on flanges - High Pressure Meters (ANSI 600# - ANSI 900#) A-27 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 72 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010  6 00#)  Table A-14. 0.5-in. through 24-in. with Slip-on Flanges (mm) High-pressure (P Overall Length Liner on Lift Ring Sensor DIM “A” Body DIM...
  • Page 73 Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-6. 1-in. through 24-in. Weld Neck Flanges - High-pressure Meters (ANSI 600# - ANSI 2500#) Table A-15. 1-in. through 24-in. Weld Neck Flanges (mm) Liner on...
  • Page 74 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-7. Standard Wafer Magmeters Table A-16. 0.15-in. through 8-in. Wafer (mm) Overall Length Liner on Sensor DIM “A” DIM “A” DIM “A” Body DIM...
  • Page 75 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-8. Dimensional Drawings of Rosemount 8721 Sensors Typical of 1- through 4-in. (25 through 100mm) line sizes. 5.00 (127) 4.02 (102) 2.00 (50.8) (46) (66)
  • Page 76 Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-9. Dimensional Drawings of Rosemount 8721 Sensors Typical of 1- through 4-in. (25 through 100mm) line sizes Tri-Clamp Weld Nipple Option NOTE Dimensions are in inches (millimeters) Table A-18.
  • Page 77 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-10. DIN 11851 (Imperial) Code D Figure A-11. DIN 11851 (Metric) Code E A-33 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 78 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-12. 11864-1 Figure A-13. 11864-2 A-34 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 79 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure A-14. SMS1145 Code H Figure A-15. Cherry Burrell I-Line Code J A-35 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...

  • Page 80: Rosemount Flanged Sensors

    The increased signal strength of the Rosemount high-signal system, coupled with advanced signal processing and superior filtering techniques, provide the solution to demanding flow measurement applications.
  • Page 81 Rosemount 8700 Series October 2010 Table 2. Rosemount Flanged Sensor Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery. __The Expanded offering is subject to additional delivery lead time.
  • Page 82 Rosemount 8700 Series October 2010 Table 2. Rosemount Flanged Sensor Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery. __The Expanded offering is subject to additional delivery lead time.

  • Page 83: Options (Include With Selected Model Number

    Rosemount 8700 Series October 2010 Table 2. Rosemount Flanged Sensor Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery. __The Expanded offering is subject to additional delivery lead time.
  • Page 84 Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 (3) Available in 1-in. to 24-in. line sizes ANSI 150, ANSI 300, and DIN Flanges. Available in 30- and 36-in. AWWA Class 125 and ANSI 150. Available in 1-in.
  • Page 85 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 3. Carbon Steel ASME B16.5 (ANSI) Flange Rating Availability Line Size MSS-SP44 Line Size Inches Class 150 Class 150 Class 300 Class 600 Class 600...
  • Page 86 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table 5. EN 1092-1 (DIN) Flange Rating Availability Carbon Carbon Carbon Carbon Carbon Carbon Stainless Stainless Stainless Stainless Line Line Size Steel Steel Steel t...

  • Page 87: Rosemount 8711 Wafer Sensors

    Alignment rings provided with every 8711, center the sensor in the process line and makes installation easier. Table 7. Rosemount 8711 Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
  • Page 88 Rosemount 8700 Series October 2010 Table 7. Rosemount 8711 Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery. __The Expanded offering is subject to additional delivery lead time.

  • Page 89: Options (Include With Selected Model Number

    Rosemount 8700 Series October 2010 Table 7. Rosemount 8711 Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery. __The Expanded offering is subject to additional delivery lead time.

  • Page 90: Rosemount 8721 Hygienic Sensors

    (15mm) to 4-in. (100mm) and are available in a variety of industry standard process connections. Table 8. Rosemount 8721 Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.

  • Page 91: Options (Include With Selected Model Number

    Rosemount 8700 Series October 2010 Table 8. Rosemount 8721 Ordering Information ★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery. __The Expanded offering is subject to additional delivery lead time.

  • Page 92: Tagging

    20 mA (5 Vdc): Sensor Size: 3-in. Empty Pipe: Sensor Calibration Number: 1000005010000000 Integrally Mounted Rosemount 8732E Transmitters are factory configured with the attached sensor size and appropriate calibration number. Cable Requirements for Remote Transmitters Description Length Signal Cable (20 AWG)

  • Page 93: Approved Manufacturing Locations

    EUROPEAN DIRECTIVE The EC declaration of conformity for all applicable European directives for this product can be INFORMATION found on our website at www.rosemount.com. A hard copy may be obtained by contacting your local sales office. ATEX Directive Rosemount Inc. complies with the ATEX Directive.

  • Page 94: Electro Magnetic Compatibility (Emc) (2004/108/Ec

    Compliance with all applicable European Union Directives. (Note: CE Marking is not available on Rosemount 8712H). IECEx Certificates C-Tick Marking Rosemount Inc. complies with the following IEC Requirements. For Rosemount 8732E transmitters: IEC 60079-0: 2004 IEC 60079-0: 2007 IEC 60079-1: 2007...

  • Page 95: Hazardous Locations Product Approvals Offering

    00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 HAZARDOUS The Rosemount 8700 Series Magnetic Flowmeters offer many different LOCATIONS PRODUCT hazardous locations certifications. The table below provides an overview of APPROVALS OFFERING the available hazardous area approval options. Equivalent hazardous locations certifications for sensor and transmitter must match in integrally mounted magnetic flowmeter systems.
  • Page 96 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table B-2. Canadian Standards Association (CSA) Approvals Offering Transmitter 8732E 8712E 8712H Sensor 8705 8707 8711 8705 8707 8711 8707 Hazardous Area Approval Code Non-Classified Locations...
  • Page 97 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table B-3. ATEX Approvals Offering Transmitter 8732E 8712E Sensor 8705 8711 8705 8711 Hazardous Area Approval Code Non-Hazardous Trans: LVD and EMC Sensor: LVD and EMC...
  • Page 98 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Table B-4. IECEx Approvals Offering Transmitter 8732E 8712E Sensor 8705 8711 8705 8711 Hazardous Area Approval Code Non-Hazardous Trans: Low Voltage and EMC Sensor: Low Voltage and EMC...

  • Page 99: Hazardous Location Certifications

    Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 HAZARDOUS LOCATION Equivalent Hazardous Location Certifications for sensor and transmitter must match in CERTIFICATIONS integrally-mounted magnetic flowmeter systems. Remote-mounted systems do not require matched hazardous location certification option codes.

  • Page 100: International Certifications

    90 °C. A fuse with a rating of maximum 0,7 A according to IEC 60127-1 shall be included in the coil excitation circuit if the sensors are used with other flow transmitters (e.g. Rosemount 8712). International...
  • Page 101 Pulsed output circuit: 30 V DC (pulsed), 0,25 A, 7,5 W maximum 4-20 mA output circuit: 30 V DC, 30 mA, 900 mW maximum Rosemount 8705 and 8711 Sensors Coil excitation circuit: 40 V 0,5 A, 20 W maximum Electrode circuit:...
  • Page 102 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Maximum process temperature °F (°C) per temperature class Maximum Ambient Temperature 1.0 in. sensor size 131°F (55°C) 343°F (173°C) 183°F (84°C) 97°F (36°C) 59°F (15°C) 122°F (50°C)
  • Page 103 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Maximum process temperature °F (°C) per temperature class Maximum Ambient Temperature 2.0 in. sensor size 149°F (65°C) 289°F (143°C) 163°F (73°C) 95°F (35°C) 66°F (19°C) 140°F (60°C)
  • Page 104 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-1. ATEX Installation Drawings B-12 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 105 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-2. ATEX Installation Drawings (Cont.) B-13 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 106 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-3. ATEX Installation Drawings (Cont.) B-14 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 107 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-4. ATEX Installation Drawings (Cont.) B-15 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 108 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-5. ATEX Installation Drawings (Cont.) B-16 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 109 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-6. ATEX Installation Drawings (Cont.) B-17 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 110 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-7. Installation Drawings with FM Certified I.S. Output B-18 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 111 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-8. Installation Drawings with FM Certified I.S. Output (Cont.) B-19 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 112 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-9. Installation Drawings with FM Certified I.S. Output (Cont.) B-20 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 113 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-10. Installation Drawings with FM Certified I.S. Output (Cont.) B-21 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 114 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-11. Installation Drawings with CSA Certified I.S. Output B-22 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 115 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-12. Installation Drawings with CSA Certified I.S. Output (Cont.) B-23 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 116 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-13. Installation Drawings with CSA Certified I.S. Output (Cont.) B-24 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 117 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-14. Installation Drawings with CSA Certified I.S. Output (Cont.) B-25 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 118 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-15. Installation Drawings Hazardous (Classified Location) – PRINTED COPIES ARE UNCONTROLLED – Electronic Master Rosemount Proprietary B-26 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 119 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 Figure B-16. Installation Drawings Factory Mutual Hazardous Location – PRINTED COPIES ARE UNCONTROLLED – Electronic Master Rosemount Proprietary B-27 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 120 Aotewell Ltd www.aotewell.com Industry Automation Reference Manual 00809-0100-4727, Rev EA Rosemount 8700 Series October 2010 B-28 sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 121 Aotewell Ltd www.aotewell.com Industry Automation sales@aotewell.com +86-755-8660-6182 HongKong|UK|China...
  • Page 122 The Emerson logo is a trade mark and service mark of Emerson Electric Co. Rosemount and the Rosemount logotype are registered trademarks of Rosemount Inc. PlantWeb is a registered trademark of one of the Emerson Process Management group of companies.

Table of Contents
