TOBY-L1 and MPCI-L1 series
LTE modules
System Integration Manual
Abstract
This document describes the features and the system integration of
TOBY-L1 and MPCI-L1 series LTE cellular modules.
These modules are a complete and cost efficient 4G solution offering
100 Mb/s download, 50 Mb/s upload, and covering 2 LTE Bands in
the compact TOBY form factor or in the industry standard PCI Express
Mini Card (MPCI) form factor.
.
www.u-blox.com
UBX-13001482 - R04
MPCI-L1 series
TOBY-L1 series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOBY-L1 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ublox TOBY-L1 series

Summary of Contents for Ublox TOBY-L1 series

  • Page 1 These modules are a complete and cost efficient 4G solution offering 100 Mb/s download, 50 Mb/s upload, and covering 2 LTE Bands in the compact TOBY form factor or in the industry standard PCI Express MPCI-L1 series TOBY-L1 series Mini Card (MPCI) form factor. www.u-blox.com UBX-13001482 - R04...
  • Page 2 TOBY-L1 and MPCI-L1 series - System Integration Manual Document Information Title TOBY-L1 and MPCI-L1 series Subtitle LTE modules Document type System Integration Manual Document number UBX-13001482 Revision, date 15-Oct-2014 Document status Advance Information Document status explanation Objective Specification Document contains target values. Revised and supplementary data will be published later. Advance Information Document contains data based on early testing.

  • Page 3: Preface

    TOBY-L1 and MPCI-L1 series - System Integration Manual Preface u-blox Technical Documentation As part of our commitment to customer support, u-blox maintains an extensive volume of technical documentation for our products. In addition to our product-specific technical data sheets, the following manuals are available to assist u-blox customers in product design and development.

  • Page 4: Table Of Contents

    Overview .............................. 7 Architecture ............................9 1.2.1 Internal blocks ..........................10 Pin-out ............................... 11 1.3.1 TOBY-L1 series pin assignment ....................11 1.3.2 MPCI-L1 series pin assignment ....................13 Operating modes ..........................15 Supply interfaces ..........................17 1.5.1 Module supply input (VCC or 3.3aux) ..................17 1.5.2...
  • Page 5 Mini PCIe specific signals (W_DISABLE#, LED_WWAN#) ..............62 Reserved pins (RSVD) .......................... 64 2.10 Module placement .......................... 64 2.11 TOBY-L1 series module footprint and paste mask ................65 2.12 MPCI-L1 series module installation ....................66 2.13 Thermal guidelines .......................... 68 2.14...
  • Page 6 TOBY-L1 and MPCI-L1 series - System Integration Manual 4.2.1 Declaration of Conformity – United States only ................81 4.2.2 Modifications ..........................81 Product Testing......................83 u-blox in-series production test ......................83 Test parameters for OEM manufacturer ....................84 5.2.1 “Go/No go” tests for integrated devices ..................84 5.2.2 RF functional tests ........................

  • Page 7: System Description

    TOBY-L1 and MPCI-L1 series - System Integration Manual 1 System description Overview The TOBY-L1 and MPCI-L1 series comprises 4G LTE-only modules supporting two LTE bands for data communication: • TOBY-L1 and MPCI-L1 series modules are designed for operation on the LTE Verizon network in North America (LTE bands 4, 13), and meets the requirements of Verizon network certification for LTE only devices.
  • Page 8 TOBY-L1 and MPCI-L1 series - System Integration Manual Table 2 reports a summary of LTE characteristics of the TOBY-L1 and MPCI-L1 series module. 4G LTE Characteristics 3GPP Release 9 - Long Term Evolution (LTE) Evolved Universal Terrestrial Radio Access (E-UTRA) Frequency Division Duplex (FDD) Multi-Input Multi-Output (MIMO) 2 x 2 antenna support Band support:...

  • Page 9: Architecture

    TOBY-L1 and MPCI-L1 series - System Integration Manual Architecture Filter Duplexer 26 MHz Filter Filter Switch ANT1 Filter 32.768 kHz Duplexer Filter Filter Transceiver Cellular Base-band Filter Filter GPIO * Switch Processor Memory ANT2 Filter Filter VCC (Supply) Power On V_BCKP Power Management Unit External Reset...

  • Page 10: Internal Blocks

    TOBY-L1 and MPCI-L1 series - System Integration Manual 1.2.1 Internal blocks As described in Figure 2, each MPCI-L100 module integrates one TOBY-L100 module, which consists of the following internal sections: RF, baseband and power management. RF section The RF section is composed of RF transceiver, PAs, LNAs, crystal oscillator, filters, duplexers and RF switches. Tx signal is pre-amplified by RF transceiver, then output to the primary antenna input/output port (ANT1) of the module via power amplifier (PA), SAW band pass filters band, specific duplexer and antenna switch.

  • Page 11: Pin-Out

    TOBY-L1 and MPCI-L1 series - System Integration Manual Pin-out 1.3.1 TOBY-L1 series pin assignment Table 3 lists the pin-out of the TOBY-L100 module, with pins grouped by function. Function Pin Name Pin No Description Remarks Power 70,71,72 Module supply input VCC pins are internally connected each other.
  • Page 12 TOBY-L1 and MPCI-L1 series - System Integration Manual Function Pin Name Pin No Description Remarks VSIM VSIM = 1.8 V / 3 V automatically generated according to SIM supply output the connected SIM type. See section 1.8 for functional description. See section 2.5 for external circuit design-in.

  • Page 13: Mpci-L1 Series Pin Assignment

    TOBY-L1 and MPCI-L1 series - System Integration Manual 1.3.2 MPCI-L1 series pin assignment Table 4 lists the pin-out of the MPCI-L100 module, with pins grouped by function. Function Pin Name Pin No Description Remarks Power 3.3Vaux 3.3Vaux pins are internally connected each other. 2, 24, 39, Module supply input 41, 52...
  • Page 14 TOBY-L1 and MPCI-L1 series - System Integration Manual Function Pin Name Pin No Description Remarks USB_D- USB Data Line D- USB interface for AT commands, Data communication, FOAT, FW update by u-blox tool and diagnostic. 90 Ω nominal differential impedance (Z 30 Ω...

  • Page 15: Operating Modes

    MPCI-L1 modules do not support Power-Off Mode. switched on by a low level on PWR_ON, input (refer to 1.6.1): module switches from power-off to active-mode. When VCC supply is removed, the TOBY-L1 series module switches from power-off mode to not-powered mode. Idle-Mode...
  • Page 16 TOBY-L1 and MPCI-L1 series - System Integration Manual Operating Mode Description Transition between operating modes Connected-Mode RF Tx/Rx data connection is in progress. When a data connection is initiated, the TOBY-L1 and MPCI-L1 modules enter connected-mode from idle-mode. The module is prepared to accept data signals from an external device unless power saving configuration If power saving configuration is enabled by the AT+UPSV is enabled by AT+UPSV (see TOBY-L1 / MPCI-L1...

  • Page 17: Supply Interfaces

    1.5.1 Module supply input (VCC or 3.3aux) TOBY-L1 series modules must be supplied via the three VCC pins, and MPCI-L1 modules are supplied via the five 3.3Vaux pins. All supply voltages used inside the modules are generated from the VCC or the 3.3aux supply input by integrated voltage regulators, including V_BCKP supply, V_INT digital interface supply and VSIM or UIM_PWR SIM interface supply.
  • Page 18 Figure 4 shows an example of the module current consumption profile versus time in LTE connected-mode. Detailed VCC or 3.3Vaux current consumption values can be found in the TOBY-L1 series Data Sheet [1] or in the MPCI-L1 series Data Sheet [2].
  • Page 19 The module is registered with network, automatically enters the low power idle-mode and periodically wakes up to active-mode to monitor the paging channel for the paging block reception. Detailed current consumption values can be found in TOBY-L1 series Data Sheet [1] or in MPCI-L1 series Data Sheet [2]. Current [mA]...
  • Page 20 Power saving configuration is by default disabled. It can also be disabled using the AT+UPSV command (refer to TOBY-L1 series AT Commands Manual [3] for detail usage). The module processor core is activated during idle-mode, and the 26 MHz reference clock frequency is used. It would draw more current during the paging period than that in the power saving mode.

  • Page 21: Rtc Supply Output (V_Bckp)

    V_BCKP output pin is not accessible on MPCI-L1 series modules. The V_BCKP output pin of the TOBY-L1 series module is connected to an internal 2.5 V supply with low current capability (refer to TOBY-L1 series Data Sheet [1]). This supply is internally generated by a linear LDO regulator integrated in the Power Management Unit, as shown in Figure 7.

  • Page 22: System Function Interfaces

    PERST# pin when 3.3Vaux module supply voltage stabilizes at its proper nominal value within the normal operating range. For more pin information and electrical characteristics, refer to the TOBY-L1 series Data Sheet [1] and the MPCI-L1 Data Sheet [2].
  • Page 23 Before a TOBY-L1 series module is fully ready to operate, the host application processor should not send any AT command over the AT communication interface (USB) of the module.
  • Page 24 TOBY-L1 and MPCI-L1 series - System Integration Manual Figure 11 shows MPCI-L1 modules power-on sequence from not-powered mode, describing these phases: • The external supply is applied to 3.3Vaux module supply inputs, representing the start-up event. • PERST# pins rise suddenly to high logic level due to internal pull-ups •...

  • Page 25: Module Power-Off

    3.3Vaux supply can be removed. An abrupt hardware shutdown occurs on TOBY-L1 series modules when a low level is applied on the RESET_N pin for at least 1 second. In this case, the current parameter settings are not saved in the module’s non-volatile memory and a proper network detach is not performed.
  • Page 26 Operational → Tristate BB Pads State Figure 12: TOBY-L1 series power-off sequence description The Internal Reset signal is not available on a module pin, but the application can monitor the V_INT pin to sense the end of the power-off sequence.

  • Page 27: Module Reset

    • AT+CPWROFF command (see TOBY-L1/ MPCI-L1 series AT Commands Manual [3]): the behavior differs than TOBY-L1 series, as MPCI-L1 modules will reboot rather than remain switched off due to MPCI-L1 modules’ internal configuration. Implementing the procedures listed above, a “software” reset of the module is executed. During the process, the current parameter settings are saved in the module’s non-volatile memory and a proper network detach is...
  • Page 28 TOBY-L1 and MPCI-L1 series - System Integration Manual Figure 15 describes the hardware reset (reboot) sequence of TOBY-L1 modules, with the following main phases: • RESET_N pin set low for at least 1 second, causing module hardware shutdown. • PWR_ON pin set low for at least 5 seconds, causing module switch-on (reboot) as described in Figure 10. Start-up RESET_N RESET_N...

  • Page 29: Antenna Interface

    The data stream is divided into 2 independent streams by the Tx-antennas of the base station • The modules, at the receiver side, receive both data streams by 2 Rx-antennas (ANT1 / ANT2) Base Station TOBY-L1 series Tx-1 Rx-1 MPCI-L1 series...
  • Page 30 TOBY-L1 and MPCI-L1 series - System Integration Manual 1.7.1.1 Antenna RF interfaces requirements Table 8, Table 9 and Table 10 summarize the requirements for the antennas RF interfaces (ANT1 / ANT2). Refer to section 2.4.1 for suggestions to properly design antennas circuits compliant to these requirements. The antennas circuits affect the RF compliance of the device integrating TOBY-L1 and MPCI-L1 series modules with applicable required certification schemes.
  • Page 31 TOBY-L1 and MPCI-L1 series - System Integration Manual Item Requirements Remarks Impedance 50 Ω nominal characteristic impedance The impedance of the antenna RF connection must match the 50 Ω impedance of the ANT2 pin / connector. Frequency Range 746…756 MHz (Rx) The required frequency range of the antennas connected •...

  • Page 32: Sim Interface

    TOBY-L1 and MPCI-L1 series - System Integration Manual SIM interface 1.8.1 SIM card interface TOBY-L1 and MPCI-L1 series modules provide high-speed SIM/ME interface including automatic detection and configuration of the voltage required by the connected SIM card or chip. Both 1.8 V and 3 V SIM types are supported. Activation and deactivation with automatic voltage switch from 1.8 V to 3 V are implemented, according to ISO-IEC 7816-3 specifications.

  • Page 33: General Purpose Input/Output (Gpio)

    GPIOs are not accessible on MPCI-L1 series modules. TOBY-L1 series modules provide 6 pins that can be configured as general purpose input/output (GPIO). For more details refer to the TOBY-L1 / MPCI-L1 series AT Commands Manual [3], +UGPIOC AT command.

  • Page 34: Mini Pcie Specific Signals (W_Disable#, Led_Wwan#)

    TOBY-L1 modules have pins reserved for future use (RSVD), to be left unconnected on the application board. 1.13 Not connected pins (NC) Pins internally not connected, marked as NC, are not available on TOBY-L1 series modules. MPCI-L1 series modules have pins internally not connected, marked as NC: they can be left unconnected or they can be connected on the application board according to any application requirement, given that none function is provided by the modules over these pins.

  • Page 35: System Features

    Manual [3]). When power saving is enabled, the module automatically enters the low power idle-mode whenever possible, reducing current consumption (refer to chapter 1.5.1.3, TOBY-L1 series Data Sheet [1], and MPCI-L1 series Data Sheet [2]). During the low power idle-mode, the module is not ready to communicate with an external device by means of the USB interface, since it is configured to reduce power consumption.

  • Page 36: Design-In

    TOBY-L1 and MPCI-L1 series - System Integration Manual 2 Design-in Overview For an optimal integration of TOBY-L1 and MPCI-L1 series modules in the final application board, follow the design guidelines stated in this chapter. Every application circuit must be properly designed to guarantee the correct functionality of the related interface, however a number of points require high attention during the design of the application device.

  • Page 37: Supply Interfaces

    See sections 2.2.1.3, 2.2.1.6, 2.2.1.8, 2.2.1.9 for specific design-in. If TOBY-L1 series modules are deployed in a mobile unit where no permanent primary supply source is available, then a battery will be required to provide VCC. A standard 3-cell Li-Ion or Li-Pol battery pack directly connected to VCC is the usual choice for battery-powered devices.
  • Page 38 Keep in mind that the use of batteries requires the implementation of a suitable charger circuit (not included in TOBY-L1 series modules). The charger circuit should be designed in order to prevent over-voltage on VCC beyond the upper limit of the absolute maximum rating. See section 2.2.1.7 for specific design-in.
  • Page 39 VCC or 3.3Vaux normal operating range (e.g. ~4.1 V for VCC and ~3.44 V for the 3.3Vaux, as in the circuit described in Figure 20 and Table 11). This reduces the power on the linear regulator and improves the thermal design of the circuit. TOBY-L1 series BOOST SYNC MPCI-L1 series 3.3Vaux...
  • Page 40 Power capabilities: the LDO linear regulator with its output circuit must be capable of providing a voltage value to the VCC or 3.3Vaux pins within the specified operating range, and must be capable of withstanding and delivering the maximum current specified in TOBY-L1 series Data Sheet [1] or MPCI-L1 series Data Sheet [2] when in connected-mode.
  • Page 41 Maximum pulse and DC discharge current: the rechargeable Li-Ion battery with its output circuit must be capable of extensively delivering the maximum current pulses to the VCC pins specified in TOBY-L1 series Data Sheet [1]. The maximum discharge current is not always reported in battery data sheets, but the maximum DC discharge current is typically almost equal to the battery capacity in Amp-hours divided by 1 hour.
  • Page 42 2.2.1.7 Guidelines for external battery charging circuit TOBY-L1 series modules do not have an on-board charging circuit. Figure 23 provides an example of a battery charger design, suitable for applications that are battery powered with a Li-Ion (or Li-Polymer) cell.
  • Page 43 Alternatively the L6924U, providing input voltage range up to 12 V, can charge from an AC wall adapter. When a current-limited adapter is used, it can operate in quasi-pulse mode, reducing power dissipation. Li-Ion/Li-Polymer TOBY-L1 series Battery Charger IC Supply...
  • Page 44 TOBY-L1 and MPCI-L1 series - System Integration Manual • The bypass capacitors in the pF range described in Figure 22 and Table 13 should be placed as close as possible to the VCC / 3.3Vaux pins. This is highly recommended if the application device integrates an internal antenna •...

  • Page 45: Rtc Supply Output (V_Bckp)

    2.2.3.1 Guidelines for V_INT circuit design TOBY-L1 series modules provide the V_INT digital interfaces 1.8 V supply output, which can be mainly used to: • Supply voltage translators to connect 1.8 V digital interfaces of the module to a 3.0 V device •...

  • Page 46: System Functions Interfaces

    V_BCKP pin (refer to TOBY-L1 series Data Sheet [1]), the V_BCKP supply cannot be used to bias the pull-up resistor. The supply rail of the application processor or the module VCC supply could be used.

  • Page 47: Module Reset (Reset_N And Perst#)

    The power-on circuit (PWR_ON) requires careful layout, since it is the sensitive input available to switch on the TOBY-L1 series modules, once a valid VCC supply is provided beforehand. For the PWR_ON pin, ensure the voltage level is well defined during operation and no transient noise is coupled on this line, otherwise the module might detect an undesirable spurious power-on request.
  • Page 48 TOBY-L1 and MPCI-L1 series - System Integration Manual If the external reset function is not required by the customer application, the RESET_N input pin can be left unconnected to external components, but it is recommended providing direct access on the application board by means of an accessible test point directly connected to the RESET_N pin.

  • Page 49: Antenna Interface

    TOBY-L1 and MPCI-L1 series - System Integration Manual Antenna interface TOBY-L1 and MPCI-L1 series modules provide two RF interfaces for connecting the external antennas: • The ANT1 port represents the primary RF input/output for transmission and reception of the LTE RF signals. •...
  • Page 50 2.4.1.2 Guidelines for antenna RF interface design Guidelines for TOBY-L1 series ANT1 / ANT2 pins RF connection design Proper transition between ANT1 / ANT2 pads and the application board PCB must be provided, implementing the following design-in guidelines for the layout of the application PCB close to the ANT1 / ANT2 pads: •...
  • Page 51 TOBY-L1 and MPCI-L1 series - System Integration Manual Guidelines for MPCI-L1 series ANT1 / ANT2 receptacles RF connection design The Hirose U.FL-R-SMT RF receptacles implemented on the MPCI-L1 series modules for ANT1 / ANT2 ports require a suitable mated RF plug from the same connector series. Due to its wide usage in the industry, several manufacturers offer compatible equivalents.
  • Page 52 TOBY-L1 and MPCI-L1 series - System Integration Manual Guidelines for RF transmission line design Any RF transmission line, such as the ones from the ANT1 and ANT2 pads up to the related antenna connector or up to the related internal antenna pad, must be designed so that the characteristic impedance is as close as possible to 50 Ω.
  • Page 53 An example of proper RF circuit design is reported in the Figure 30. In this case, the ANT1 and ANT2 pins are directly connected to SMA connectors by means of proper 50 Ω transmission lines, designed with proper layout. TOBY-L1 series SMA Connector...
  • Page 54 TOBY-L1 and MPCI-L1 series - System Integration Manual Guidelines for RF termination design RF terminations must provide a characteristic impedance of 50 Ω as well as the RF transmission lines up to the RF terminations themselves, to match the characteristic impedance of the ANT1 / ANT2 ports of the modules. However, real antennas are not perfect 50 Ω...

  • Page 55: Sim Interface

    TOBY-L1 and MPCI-L1 series - System Integration Manual SIM interface 2.5.1 Guidelines for SIM circuit design Guidelines for SIM cards, SIM connectors and SIM chips selection The ISO/IEC 7816, the ETSI TS 102 221 and the ETSI TS 102 671 specifications define the physical, electrical and functional characteristics of Universal Integrated Circuit Cards (UICC), which contains the Subscriber Identification Module (SIM) integrated circuit that securely stores all the information needed to identify and authenticate subscribers over the LTE network.
  • Page 56 Limit capacitance and series resistance on each SIM signal to match the SIM requirements (27.7 ns is the maximum allowed rise time on clock line, 1.0 µs is the maximum allowed rise time on data and reset lines) SIM CARD TOBY-L1 series HOLDER VPP (C6)
  • Page 57 Limit capacitance and series resistance on each SIM signal to match the SIM requirements (27.7 ns is the maximum allowed rise time on clock line, 1.0 µs is the maximum allowed rise time on data and reset lines). TOBY-L1 series SIM CHIP...

  • Page 58: Guidelines For Sim Layout Design

    TOBY-L1 and MPCI-L1 series - System Integration Manual 2.5.2 Guidelines for SIM layout design The layout of the SIM card interface lines (VSIM / UIM_PWR, SIM_CLK / UIM_CLK, SIM_IO / UIM_DATA, SIM_RST / UIM_RESET) may be critical if the SIM card is placed far away from the TOBY-L1 and MPCI-L1 series modules or in close proximity to the RF antenna: these two cases should be avoided or at least mitigated as described below.

  • Page 59: Data Communication Interfaces

    The USB_D+ and USB_D- pins of the modules can be directly connected to the USB host application processor without additional ESD protections if they aren’t externally accessible or according to EMC/ESD requirements. USB DEVICE USB HOST CONNECTOR PROCESSOR TOBY-L1 series TOBY-L1 series VBUS USB_D+ USB_D+ USB_D-...
  • Page 60 TOBY-L1 and MPCI-L1 series - System Integration Manual 2.6.1.2 Guidelines for USB layout design The USB_D+ / USB_D- lines require accurate layout design to achieve reliable signaling at the high speed data rate (up to 480 Mb/s) supported by the USB serial interface. The characteristic impedance of the USB_D+ / USB_D- lines is specified by the Universal Serial Bus Revision 2.0 specification [4].

  • Page 61: General Purpose Input/Output (Gpio)

    Higher protection level could be required if the lines are externally accessible and it can be achieved by mounting an ESD protection (e.g. EPCOS CA05P4S14THSG varistor array) close to accessible points. Before a TOBY-L1 series module is fully ready to operate, no voltage drives from a host should apply to any GPIO of the module.

  • Page 62: Mini Pcie Specific Signals (W_Disable#, Led_Wwan#)

    TOBY-L1 and MPCI-L1 series - System Integration Manual Mini PCIe specific signals (W_DISABLE#, LED_WWAN#) Mini PCI Express specific signals: W_DISABLE# and LED_WWAN# are not available on TOBY-L1. 2.8.1.1 Guidelines for W_DISABLE# circuit design As described in Figure 37, the MPCI-L1 series modules W_DISABLE# wireless disable input is equipped with an internal pull-up to the 3.3Vaux supply: an external pull-up resistor is not required and should not be provided.
  • Page 63 TOBY-L1 and MPCI-L1 series - System Integration Manual 2.8.1.2 Guidelines for LED_WWAN# circuit design As described in Figure 38 and Table 23, the MPCI-L1 series modules LED_WWAN# active-low open drain output can be directly connected to a system-mounted LED to provide the Wireless Wide Area Network status indication as specified by the PCI Express Mini Card Electromechanical Specification [15].

  • Page 64: Reserved Pins (Rsvd)

    Reserved pins (RSVD) Pins reserved for future use, marked as RSVD, are not available on MPCI-L1 series. TOBY-L1 series modules have pins reserved for future use. All the RSVD pins are to be left unconnected on the application board. It is recommended to provide direct access to the RSVD pins 16, 17 and 49 on the application board by means of an accessible test point directly connected to the related pin.

  • Page 65: Toby-L1 Series Module Footprint And Paste Mask

    2.11 TOBY-L1 series module footprint and paste mask Figure 40 and Table 24 describe the suggested footprint (i.e. copper mask) layout for TOBY-L1 series modules. The proposed land pattern layout slightly reflects the modules’ pads layout, with most of the lateral pads designed wider on the application board (1.8 x 0.8 mm) than on the module (1.5 x 0.8 mm).

  • Page 66: Mpci-L1 Series Module Installation

    TOBY-L1 and MPCI-L1 series - System Integration Manual 2.12 MPCI-L1 series module installation MPCI-L1 series modules are fully compliant to the 52-pin PCI Express Full-Mini Card Type F2 form factor, with top-side and bottom-side keep-out areas, with 50.95 mm nominal length, 30 mm nominal width and all the other dimensions as defined by the PCI Express Mini Card Electromechanical Specification [15] except for the card thickness (which nominal value is 3.7 mm), as described in Figure 41.
  • Page 67 TOBY-L1 and MPCI-L1 series - System Integration Manual MPCI-L1 series modules are equipped with two Hirose U.FL-R-SMT RF receptacles for ANT1 / ANT2 ports, which require a suitable mated RF plug from the same connector series as the examples listed in Table 17. To mate the connectors, the mating axes of both connectors must be aligned.

  • Page 68: Thermal Guidelines

    TOBY-L1 and MPCI-L1 series - System Integration Manual 2.13 Thermal guidelines Modules’ operating temperature range is specified in TOBY-L1 Data Sheet [1] and MPCI-L1 Data Sheet [2]. The most critical condition concerning module thermal performance is the uplink transmission at maximum power (data upload in connected-mode), when the baseband processor runs at full speed, radio circuits are all active and the RF power amplifier is driven to higher output RF power.

  • Page 69: Esd Guidelines

    TOBY-L1 and MPCI-L1 series - System Integration Manual In addition to taking hardware design measures, the increase of module temperature can be moderated by the software implementation of the application: • Enable module connected-mode for a given time period, and then disable it for a time period enough long to properly mitigate temperature increase.

  • Page 70: Esd Application Circuits

    TOBY-L1 and MPCI-L1 series - System Integration Manual Since external antennas are used, the antenna port can be separated from the enclosure port. The reference design is not enclosed in a box so that the enclosure port is not identified with physical surfaces. Therefore, some test cases cannot be applied.
  • Page 71 TOBY-L1 and MPCI-L1 series - System Integration Manual Maximum ESD sensitivity rating of the RESET_N and PERST# pin is 1 kV (Human Body Model according to JESD22-A114). Higher protection level could be required if the RESET_N or PERST# pin is externally accessible on the application board.

  • Page 72: Schematic For Toby-L1 And Mpci-L1 Series Module Integration

    TOBY-L1 and MPCI-L1 series - System Integration Manual 2.15 Schematic for TOBY-L1 and MPCI-L1 series module integration Figure 44 is an example of a schematic diagram where a TOBY-L1 series module is integrated into an application board, using all the available interfaces and functions of the module.
  • Page 73 TOBY-L1 and MPCI-L1 series - System Integration Manual Figure 45 is an example of a schematic diagram where a MPCI-L1 series module is integrated into an application board, using all the available interfaces and functions of the module. MPCI-L1 series 3.3Vaux 3.3Vaux 3.3Vaux...

  • Page 74: Design-In Checklist

    VCC / 3.3aux supply should be clean, with very low ripple/noise: provide the suggested bypass capacitors, in particular if the application device integrates an internal antenna.  For TOBY-L1 series modules, do not leave PWR_ON floating: fix properly the level, e.g. adding a proper pull-up resistor to V_BCKP. ...

  • Page 75: Antenna Checklist

    TOBY-L1 and MPCI-L1 series - System Integration Manual 2.16.3 Antenna checklist  Two antennas (one connected to ANT1 pin / connector and one connected to ANT2 pin / connector) must be used to support the Down-Link MIMO 2 x 2 radio technology as mandatory feature for LTE category 3 User Equipments (up to 100 Mb/s DL data rate) designed to operate on Verizon Wireless LTE 3GPP Band 4 / 13 network.

  • Page 76: Handling And Soldering

    For information pertaining to reels, tapes or trays, Moisture Sensitivity levels (MSD), shipment and storage, as well as drying for preconditioning refer to the TOBY-L1 series Data Sheet [1] or the MPCI-L1 series Data Sheet [2] and the u-blox Package Information Guide [13].

  • Page 77: Soldering

    Soldering 3.3.1 Soldering paste "No Clean" soldering paste is strongly recommended for TOBY-L1 series modules, as it does not require cleaning after the soldering process has taken place. The paste listed in the example below meets these criteria. Soldering Paste: OM338 SAC405 / Nr.143714 (Cookson Electronics)

  • Page 78: Optical Inspection

    Figure 46: Recommended soldering profile TOBY-L1 series modules must not be soldered with a damp heat process. 3.3.3 Optical inspection After soldering the TOBY-L1 series modules, inspect the modules optically to verify that the module is properly aligned and centered. 3.3.4 Cleaning Cleaning the soldered modules is not recommended.

  • Page 79: Wave Soldering

    TOBY-L1 and MPCI-L1 series - System Integration Manual 3.3.6 Wave soldering Boards with combined through-hole technology (THT) components and surface-mount technology (SMT) devices require wave soldering to solder the THT components. Only a single wave soldering process is encouraged for boards populated with the modules.

  • Page 80: Approvals

    TOBY-L1 and MPCI-L1 series - System Integration Manual 4 Approvals For the complete list of all the certification schemes approvals of TOBY-L1 and MPCI-L1 series modules and the corresponding declarations of conformity, refer to the u-blox web-site (http://www.u-blox.com). Product certification approval overview Product certification approval is the process of certifying that a product has passed all tests and criteria required by specifications, typically called “certification schemes”...

  • Page 81: Federal Communications Commission And Industry Canada Notice

    TOBY-L1 and MPCI-L1 series - System Integration Manual Federal Communications Commission and Industry Canada notice Federal Communications Commission (FCC) ID: • R5Q-TOBYL100 Industry Canada (IC) Certification Number: • 8595B-TOBYL100 The MPCI-L1 module integrates the TOBY-L1 module and therefore the two modules share the same FCC ID and IC Number.
  • Page 82 TOBY-L1 and MPCI-L1 series - System Integration Manual Radio Frequency (RF) Exposure Information The radiated output power of the u-blox Cellular Module is below the Industry Canada (IC) radio frequency exposure limits. The u-blox Cellular Module should be used in such a manner such that the potential for human contact during normal operation is minimized.

  • Page 83: Product Testing

    TOBY-L1 and MPCI-L1 series - System Integration Manual 5 Product Testing u-blox in-series production test u-blox focuses on high quality for its products. All units produced are fully tested automatically in production line. Stringent quality control process has been implemented in the production line. Defective units are analyzed in detail to improve the production quality.

  • Page 84: Test Parameters For Oem Manufacturer

    TOBY-L1 and MPCI-L1 series - System Integration Manual Test parameters for OEM manufacturer Because of the testing done by u-blox (with 100% coverage), an OEM manufacturer does not need to repeat firmware tests or measurements of the module RF performance or tests over analog and digital interfaces in their production test.
  • Page 85 Follow instructions suggested in u-blox documentation. u-blox assumes no responsibilities for the inappropriate use of this feature. Figure 48 illustrates a typical test setup for such RF functional test. Wireless Wideband Antenna Antenna Application TOBY-L1 series Spectrum Processor MPCI-L1 series Analyzer Commands ANT1 Power...

  • Page 86: Connecting To Wireless Communication Test Set

    TOBY-L1 and MPCI-L1 series - System Integration Manual 5.2.3 Connecting to Wireless Communication Test Set Wireless Communication Test Sets as Base Station simulators can be helpful with the ability to make protocol, functional, throughput and RF measurements. To connect a TOBY-L1 or MPCI-L1 series modules to such a test set that can support the module’s signaling and RF specifications, the commands listed in Table 28 are required over the AT command user interface.

  • Page 87: Appendix

    TOBY-L1 and MPCI-L1 series - System Integration Manual Appendix A Glossary 3GPP 3rd Generation Partnership Project Analog to Digital Converter Application Processor ASIC Application-Specific Integrated Circuit AT Command Interpreter Software Subsystem, or attention CSFB Circuit Switched Fall-Back Direct Current Data Communication Equipment Display Data Channel interface Down-link (Reception) Discontinuous Reception...
  • Page 88 TOBY-L1 and MPCI-L1 series - System Integration Manual Low-Dropout Land Grid Array Low Noise Amplifier LPDDR Low Power Double Data Rate synchronous dynamic RAM memory Long Term Evolution Machine-to-Machine Not Applicable N.A. Not Available Over The Air Power Amplifier Pulse Code Modulation PCN / IN Product Change Notification / Information Note Personal Communications Service...

  • Page 89: Related Documents

    TOBY-L1 and MPCI-L1 series - System Integration Manual Related documents u-blox TOBY-L1 series Data Sheet, Docu No UBX-13000868 u-blox MPCI-L1 series Data Sheet, Docu No UBX-14001412 u-blox TOBY-L1 / MPCI-L1 series AT Commands Manual, Docu No UBX-13002211 Universal Serial Bus Revision 2.0 specification, http://www.usb.org/developers/docs/usb20_docs/ 3GPP TS 36.521-2 –...

  • Page 90: Contact

    TOBY-L1 and MPCI-L1 series - System Integration Manual Contact For complete contact information visit us at www.u-blox.com u-blox Offices North, Central and South America Headquarters Asia, Australia, Pacific Europe, Middle East, Africa u-blox America, Inc. u-blox Singapore Pte. Ltd. u-blox AG Phone: +1 703 483 3180 Phone:...
