TOBY-L2 and MPCI-L2 series
LTE/DC-HSPA+/EGPRS modules
System Integration Manual
Abstract
This document describes the features and the system integration of
TOBY-L2 and MPCI-L2 series multi-mode cellular modules.
These modules are a complete and cost efficient LTE/3G/2G solution
offering up to 150 Mb/s download and 50 Mb/s upload data rates,
covering up to six LTE bands, up to five WCDMA/DC-HSPA+ bands
and four GSM/EGPRS bands in the compact TOBY LGA form factor of
TOBY-L2 modules or in the industry standard PCI Express Mini Card
form factor of MPCI-L2 modules.
www.u-blox.com
UBX-13004618 - R07
TOBY-L2 series
MPCI-L2 series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPCI-L2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ublox MPCI-L2 Series

Summary of Contents for Ublox MPCI-L2 Series

  • Page 1 Abstract This document describes the features and the system integration of TOBY-L2 and MPCI-L2 series multi-mode cellular modules. These modules are a complete and cost efficient LTE/3G/2G solution offering up to 150 Mb/s download and 50 Mb/s upload data rates,...
  • Page 2 TOBY-L2 and MPCI-L2 series - System Integration Manual Document Information Title TOBY-L2 and MPCI-L2 series Subtitle LTE/DC-HSPA+/EGPRS modules Document type System Integration Manual Document number UBX-13004618 Revision and date 29-May-2015 Document status Advance Information Document status explanation Objective Specification Document contains target values. Revised and supplementary data will be published later.

  • Page 3: Preface

    Cellular Module. How to use this Manual The TOBY-L2 and MPCI-L2 series System Integration Manual provides the necessary information to successfully design and configure the u-blox cellular modules. This manual has a modular structure. It is not necessary to read it from the beginning to the end.

  • Page 4: Table Of Contents

    TOBY-L2 and MPCI-L2 series - System Integration Manual Contents Preface ..........................3 Contents ..........................4 System description ....................... 8 Overview .............................. 8 Architecture ............................10 1.2.1 Internal blocks ..........................11 Pin-out ............................... 12 1.3.1 TOBY-L2 series pin assignment ....................12 1.3.2...
  • Page 5 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.15.3 Jamming detection ........................58 1.15.4 IP modes of operation ......................... 59 1.15.5 Dual stack IPv4/IPv6 ........................59 1.15.6 TCP/IP and UDP/IP ........................59 1.15.7 FTP .............................. 59 1.15.8 HTTP ............................60 1.15.9...
  • Page 6 ESD guidelines ..........................127 2.15.1 ESD immunity test overview ...................... 127 2.15.2 ESD immunity test of TOBY-L2 and MPCI-L2 series reference designs ........128 2.15.3 ESD application circuits ......................128 2.16 Schematic for TOBY-L2 and MPCI-L2 series module integration ............ 130 2.16.1...
  • Page 7 TOBY-L2 and MPCI-L2 series - System Integration Manual 5.2.1 “Go/No go” tests for integrated devices ..................147 5.2.2 RF functional tests ........................147 Appendix ........................149 A Glossary ........................149 Migration between TOBY-L1 and TOBY-L2 ............151 Overview ............................151 Pin-out comparison between TOBY-L1 and TOBY-L2 ................

  • Page 8: System Description

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1 System description Overview TOBY-L2 and MPCI-L2 series comprises LTE/3G/2G multi-mode modules supporting up to six LTE bands, up to five UMTS/DC-HSPA+ bands and up to four GSM/(E)GPRS bands for voice and/or data transmission as following: ...
  • Page 9  HSUPA cat.6, up to 5.6 Mb/s UL Table 2: TOBY-L2 and MPCI-L2 series LTE, 3G and 2G characteristics summary HSDPA category 24 capable GPRS/EDGE multi-slot class determines the number of timeslots available for upload and download and thus the speed at which data can be transmitted and received, with higher classes typically allowing faster data transfer rates.

  • Page 10: Architecture

    Power Management Unit External Reset V_INT (I/O) Figure 1: TOBY-L2 series block diagram As described in the Figure 2, each MPCI-L2 series module integrates one TOBY-L2 series module:  The MPCI-L200 integrates a TOBY-L200 module  The MPCI-L210 integrates a TOBY-L210 module The TOBY-L2 module represents the core of the device, providing the related LTE/3G/2G modem and processing functionalities.

  • Page 11: Internal Blocks

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.2.1 Internal blocks As described in Figure 2, each MPCI-L2 series module integrates one TOBY-L2 series module, which consists of the following internal sections: RF, baseband and power management. RF section The RF section is composed of RF transceiver, PAs, LNAs, crystal oscillator, filters, duplexers and RF switches.

  • Page 12: Pin-Out

    TOBY-L2 and MPCI-L2 series - System Integration Manual Pin-out 1.3.1 TOBY-L2 series pin assignment Table 3 lists the pin-out of the TOBY-L2 series modules, with pins grouped by function. Function Pin Name Pin No Description Remarks Power VCC pins are internally connected each other.
  • Page 13 TOBY-L2 and MPCI-L2 series - System Integration Manual Function Pin Name Pin No Description Remarks VSIM VSIM = 1.8 V / 3 V output as per the connected SIM type. SIM supply output See section 1.8 for functional description. See section 2.5 for external circuit design-in.
  • Page 14 TOBY-L2 and MPCI-L2 series - System Integration Manual Function Pin Name Pin No Description Remarks UART UART data output Note: not supported by TOBY-L200-00S, TOBY-L210-00S. 1.8 V output, Circuit 104 (RXD) in ITU-T V.24, for AT command, data communication, FOAT.
  • Page 15 TOBY-L2 and MPCI-L2 series - System Integration Manual Function Pin Name Pin No Description Remarks C bus clock line Note: not supported by “00”, “01”, “50” product versions. 1.8 V open drain, for communication with u-blox GNSS receivers and other I2C-slave devices as an audio codec.
  • Page 16 TOBY-L2 and MPCI-L2 series - System Integration Manual Function Pin Name Pin No Description Remarks GPIO GPIO1 GPIO Note: not supported by “00”, “01”, “50” product versions. WWAN status indication set on “00”, “01” product versions. Wi-Fi enable function set on “50” product version.

  • Page 17: Mpci-L2 Series Pin Assignment

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.3.2 MPCI-L2 series pin assignment Table 4 lists the pin-out of the MPCI-L2 series modules, with pins grouped by function. Function Pin Name Pin No Description Remarks Power 3.3Vaux 3.3Vaux pins are internally connected each other.
  • Page 18 Internally not connected. Connected 13, 16, 17, 19, See section 1.14 for the description. 23, 25, 28, 30-33, 44-46, 47-49, 51 Table 4: MPCI-L2 series module pin definition, grouped by function UBX-13004618 - R07 Advance Information System description Page 18 of 158...

  • Page 19: Operating Modes

    TOBY-L2 and MPCI-L2 series - System Integration Manual Operating modes TOBY-L2 and MPCI-L2 series modules have several operating modes. The operating modes are defined in Table 5 and described in detail in Table 6, providing general guidelines for operation. General Status...
  • Page 20 RF Transmission/Reception is necessary. When a data connection is terminated, the module returns to the active-mode. Table 6: TOBY-L2 and MPCI-L2 series modules operating modes description Figure 3 describes the transition between the different operating modes. powered TOBY-L2: •...

  • Page 21: Supply Interfaces

    VSIM or UIM_PWR SIM interface supply. The current drawn by the TOBY-L2 and MPCI-L2 series modules through the VCC or 3.3Vaux pins can vary by several orders of magnitude depending on radio access technology, operation mode and state. It is important that the supply source is able to support both the high peak of current consumption during 2G transmission at maximum RF power level (as described in the section 1.5.1.2) and the high average current consumption during...
  • Page 22 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.5.1.2 VCC or 3.3Vaux current consumption in 2G connected-mode When a GSM call is established, the VCC or 3.3Vaux module current consumption is determined by the current consumption profile typical of the GSM transmitting and receiving bursts.
  • Page 23 TOBY-L2 and MPCI-L2 series - System Integration Manual When a GPRS connection is established, more than one slot can be used to transmit and/or more than one slot can be used to receive. The transmitted power depends on network conditions, which set the peak current consumption, but following the 3GPP specifications the maximum Tx RF power is reduced if more than one slot is used to transmit, so the maximum peak of current is not as high as can be in case of a 2G single-slot call.
  • Page 24 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.5.1.3 VCC or 3.3Vaux current consumption in 3G connected mode During a 3G connection, the module can transmit and receive continuously due to the Frequency Division Duplex (FDD) mode of operation with the Wideband Code Division Multiple Access (WCDMA).
  • Page 25 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.5.1.4 VCC or 3.3Vaux current consumption in LTE connected-mode During a LTE connection, the module can transmit and receive continuously due to LTE radio access technology. The current consumption is strictly dependent on the transmitted RF output power, which is always regulated by network commands.
  • Page 26 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.5.1.5 VCC or 3.3Vaux current consumption in cyclic idle/active mode (power saving enabled) The power saving configuration is by default disabled, but it can be enabled using the AT+UPSV command (see the u-blox AT Commands Manual [3]). When power saving is enabled, the module automatically enters the low power idle-mode whenever possible, reducing current consumption.
  • Page 27 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.5.1.6 VCC or 3.3Vaux current consumption in fixed active-mode (power saving disabled) When power saving is disabled, the module does not automatically enter the low power idle-mode whenever possible: the module remains in active-mode. Power saving configuration is by default disabled. It can also be disabled using the AT+UPSV command (see u-blox AT Commands Manual [3] for detail usage).

  • Page 28: Rtc Supply Input/Output (V_Bckp)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.5.2 RTC supply input/output (V_BCKP) The RTC supply V_BCKP pin is not available on MPCI-L2 series modules. The V_BCKP pin of TOBY-L2 series modules connects the supply for the Real Time Clock (RTC). A linear LDO regulator integrated in the Power Management Unit internally generates this supply, as shown in Figure 11, with low current capability (see the TOBY-L2 series Data Sheet [1]).

  • Page 29: Generic Digital Interfaces Supply Output (V_Int)

    1.5.3 Generic digital interfaces supply output (V_INT) The generic digital interfaces supply V_INT pin is not available on MPCI-L2 series modules. The V_INT output pin of the TOBY-L2 series modules is connected to an internal 1.8 V supply with current capability specified in the TOBY-L2 series Data Sheet [1].

  • Page 30: System Function Interfaces

    The PWR_ON input pin is not available on MPCI-L2 series modules. When the TOBY-L2 and MPCI-L2 series modules are in the not-powered mode (switched off, i.e. the VCC or 3.3Vaux module supply is not applied), they can be switched on as following: ...
  • Page 31 TOBY-L2 module. Before the TOBY-L2 and MPCI-L2 series module is fully ready to operate, the host application processor should not send any AT command over the AT communication interfaces (USB, UART) of the module.

  • Page 32: Module Power-Off

    The MPCI-L2 series modules do not switch off by the AT+CPWROFF command as the TOBY-L2 modules, but the AT+CPWROFF command causes a reset (reboot) of the module due to the MPCI-L2 module’s internal configuration: the command stores the actual parameter settings in the non-volatile memory of MPCI-L2 modules and performs a network detach, with a subsequent reset (reboot) of the module.
  • Page 33 ~5 s Figure 16: MPCI-L2 series power-off procedure description The duration of each phase in the TOBY-L2 and MPCI-L2 series modules’ switch-off routines can largely vary depending on the application / network settings and the concurrent module activities. UBX-13004618 - R07...

  • Page 34: Module Reset

    An abrupt hardware reset occurs on TOBY-L2 and MPCI-L2 series modules when a low level is applied on the RESET_N or PERST# input pin for a specific time period. In this case, the current parameter settings are not saved in the module’s non-volatile memory and a proper network detach is not performed.

  • Page 35: Antenna Interface

    ANT2 Figure 18: Description of the LTE Down-Link MIMO 2 x 2 radio technology supported by TOBY-L2 and MPCI-L2 series modules TOBY-L2 and MPCI-L2 series modules support the LTE MIMO 2 x 2 radio technology in the Down-Link path only (from the base station to the module): the ANT1 port is the only one RF interface that is used by the module to transmit the RF signal in the Up-Link path (from the module to the base station).
  • Page 36 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.7.1.1 Antenna RF interfaces requirements Table 8, Table 9 and Table 10 summarize the requirements for the antennas RF interfaces (ANT1 / ANT2). See section 2.4.1 for suggestions to properly design antennas circuits compliant with these requirements.
  • Page 37 TOBY-L2 and MPCI-L2 series - System Integration Manual Item Requirements Remarks Impedance 50  nominal characteristic impedance The impedance of the antenna RF connection must match the 50  impedance of the ANT2 port. Frequency Range See the TOBY-L2 series Data Sheet [1] and the...

  • Page 38: Antenna Detection Interface (Ant_Det)

    SIM interface 1.8.1 SIM interface TOBY-L2 and MPCI-L2 series modules provide high-speed SIM/ME interface including automatic detection and configuration of the voltage required by the connected SIM card or chip. Both 1.8 V and 3 V SIM types are supported. Activation and deactivation with automatic voltage switch from 1.8 V to 3 V are implemented, according to ISO-IEC 7816-3 specifications.

  • Page 39: Data Communication Interfaces

    1.9.1.1 USB features TOBY-L2 and MPCI-L2 series modules include a High-Speed USB 2.0 compliant interface with maximum data rate of 480 Mb/s, representing the main interface for transferring high speed data with a host application processor: the USB interface is available for AT commands, data communication, FW upgrade by means of the FOAT feature, FW upgrade by means of the u-blox EasyFlash tool and for diagnostic purpose.
  • Page 40 EndPoint Transfer: Bulk Figure 19: TOBY-L2 and MPCI-L2 series USB End-Points summary for the default USB profile configuration The USB of the modules can be configured by the AT+UUSBCONF command (for more details see the u-blox AT Commands Manual [3]) to select different sets of USB functions available in mutually exclusive way, selecting the active USB profile consisting of a specific set of functions with various capabilities and purposes, such as: ...
  • Page 41 Then, after a time period (roughly 20 s, depending on the host / device enumeration timings), the VID and PID are updated to the ones related to the USB profile selected by the AT+UUSBCONF command. For more details regarding the TOBY-L2 and MPCI-L2 series modules USB configurations and capabilities, see the u-blox AT Commands Manual [3], +UUSBCONF AT command.
  • Page 42 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.9.1.2 USB in Windows The USB drivers (INF files) are provided for Windows systems and should be installed properly by following the step-by-step instruction in EVK-L20 / EVK-L21 User Guide [4]. USB drivers are available for the following operating system platforms: ...

  • Page 43: Asynchronous Serial Interface (Uart)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.9.2 Asynchronous serial interface (UART) The UART interface is not available on MPCI-L2 series modules. The UART interface is not supported by TOBY-L200-00S and TOBY-L210-00S modules versions. The DTR, DSR and DCD signals are not supported by TOBY-L200-50S, TOBY-L210-50S modules versions.
  • Page 44 TOBY-L2 and MPCI-L2 series - System Integration Manual The following baud rates can be configured by AT command (see u-blox AT Commands Manual [3], +IPR):  9600 b/s  19200 b/s  38400 b/s  57600 b/s  115200 b/s, default value for “50” modules product version or when one-shot autobauding is disabled ...
  • Page 45 TOBY-L2 and MPCI-L2 series - System Integration Manual 1.9.2.2 UART interface configuration The UART interface of TOBY-L2 series modules is available as AT command interface with the default configuration described in Table 11 (for more details and information about further settings, see the u-blox AT Commands Manual [3]).
  • Page 46 TOBY-L2 and MPCI-L2 series - System Integration Manual CTS signal behavior The module hardware flow control output (CTS line) is set to the ON state (low level) at UART initialization. If the hardware flow control is enabled, as it is by default, the CTS line indicates when the UART interface is enabled (data can be sent and received).
  • Page 47 TOBY-L2 and MPCI-L2 series - System Integration Manual DSR signal behavior If AT&S1 is set, as it is by default, the DSR module output line is set by default to the OFF state (high level) at UART initialization. The DSR line is then set to the OFF state when the module is in command mode...
  • Page 48 TOBY-L2 and MPCI-L2 series - System Integration Manual RI signal behavior The RI module output line is set by default to the OFF state (high level) at UART initialization. The RI output line can notify an SMS arrival. When the SMS arrives, the RI line switches from OFF to ON for 1 s...
  • Page 49 TOBY-L2 and MPCI-L2 series - System Integration Manual AT+UPSV HW flow control RTS line DTR line Communication during idle-mode and wake up Enabled (AT&K3) ON or OFF Data sent by the DTE is correctly received by the module. Data sent by the module is correctly received by the DTE.
  • Page 50 TOBY-L2 and MPCI-L2 series - System Integration Manual AT+UPSV=0: power saving disabled, fixed active-mode The module does not enter low power idle-mode and the UART interface is enabled (data can be sent and received): the CTS line is always held in the ON state after UART initialization. This is the default configuration.
  • Page 51 TOBY-L2 and MPCI-L2 series - System Integration Manual AT+UPSV=2: power saving enabled and controlled by the RTS line This configuration can only be enabled with the module hardware flow control disabled (i.e. AT&K0 setting). The UART interface is immediately disabled after the DTE sets the RTS line to OFF.
  • Page 52 TOBY-L2 and MPCI-L2 series - System Integration Manual Wake up via data reception The UART wake up via data reception consists of a special configuration of the module TXD input line that causes the system wake-up when a low-to-high transition occurs on the TXD input line. In particular, the UART is enabled and the module switches from the low power idle-mode to active-mode within ~5 ms from the first character received: this is the system “wake up time”.
  • Page 53 TOBY-L2 and MPCI-L2 series - System Integration Manual The “wake-up via data reception” feature cannot be disabled. In command mode , if autobauding is enabled and the DTE does not implement HW flow control, the DTE must always send a character to the module before the “AT” prefix set at the beginning of each command line: the first character is ignored if the module is in active-mode, or it represents the wake-up character if the module is in idle-mode.

  • Page 54: Ddc (I C) Interface

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.9.3 DDC (I C) interface The I C bus compatible Display Data Channel interface is not available on the MPCI-L2 series modules, as ® AssistNow embedded GNSS positioning aiding, CellLocate positioning through cellular information and custom functions over GPIOs for the integration with u-blox positioning chips / modules.

  • Page 55: Secure Digital Input Output Interface (Sdio)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.9.4 Secure Digital Input Output interface (SDIO) Secure Digital Input Output interface is not available on MPCI-L2 series modules. Secure Digital Input Output interface is not supported by TOBY-L2 “00” and “01” product versions.

  • Page 56: General Purpose Input/Output

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.11 General Purpose Input/Output GPIOs are not supported by TOBY-L2 series modules “00”, “01” and “50” product versions, except for:  Wireless Wide Area Network status indication configured on GPIO1 of “00”, “01” product versions ...

  • Page 57: Mini Pcie Specific Signals (W_Disable#, Led_Wwan#)

    Pins internally not connected, marked as NC, are not available on TOBY-L2 series. MPCI-L2 series modules have pins internally not connected, marked as NC: they can be left unconnected or they can be connected on the application board according to any application requirement, given that none function is provided by the modules over these pins.

  • Page 58: System Features

    1.15 System features 1.15.1 Network indication Network status indication over GPIO1 is not available on MPCI-L2 series modules which include the LED_WWAN# active-low open drain output to provide the Wireless Wide Area Network status indication as specified by the PCI Express Mini Card Electromechanical Specification [15].

  • Page 59: Ip Modes Of Operation

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.15.4 IP modes of operation IP modes of operation refer to the TOBY-L2 and MPCI-L2 series modules configuration related to the network IP termination and network interfaces settings in general. IP modes of operation are the following: ...

  • Page 60: Http

    Embedded Transport Layer Security (TLS) / Secure Sockets Layer (SSL) protocols are not supported by the “00”, “01” and “50” product versions. TOBY-L2 and MPCI-L2 series modules provide the Transport Layer Security (TLS) / Secure Sockets Layer (SSL) encryption protocols to enable security over the FTP and HTTP protocols via AT commands, implementing Secure File Transfer Protocol (FTPS, i.e.
  • Page 61 TOBY-L2 and MPCI-L2 series - System Integration Manual ® Positioning through cellular information: CellLocate ® u-blox CellLocate enables the estimation of device position based on the parameters of the mobile network cells ® visible to the specific device. To estimate its position the u-blox cellular module sends the CellLocate server the parameters of network cells visible to it using a UDP connection.
  • Page 62 TOBY-L2 and MPCI-L2 series - System Integration Manual 3. If a new device reports the observation of Cell A CellLocate ® is able to provide the estimated position from the area of visibility 4. The visibility of multiple cells provides increased accuracy based on the intersection of areas of visibility.

  • Page 63: Wi-Fi Integration

    SIM used or the specific device. 1.15.12 Wi-Fi integration u-blox short range communication Wi-Fi modules integration is not available for MPCI-L2 series modules. u-blox short range communication Wi-Fi modules integration is not supported by the TOBY-L2 series modules “00” and “01” product versions.

  • Page 64: In-Band Modem (Ecall / Era-Glonass)

    In-band modem for eCall / ERA-GLONASS emergency applications is not supported by TOBY-L2 series modules “00”, “01”, and “50” product versions and by MPCI-L2 series modules. In-band Modem solution for eCall and ERA-GLONASS emergency call applications over cellular networks is implemented according to 3GPP TS 26.267 [16], BS EN 16062:2011 [17] and ETSI TS 122 101 [18] specifications.
  • Page 65 TOBY-L2 and MPCI-L2 series - System Integration Manual TOBY-L2 series modules, acting as an SAP client, can be connected to an SAP server by a completely wired connection, as shown in Figure 27. Device including SIM Device including TOBY-L2 Mobile...

  • Page 66: Smart Temperature Management

    TOBY-L2 and MPCI-L2 series - System Integration Manual 1.15.17 Smart temperature management Smart temperature management is not supported by “00”, “01”, and “50” product versions. Cellular modules – independent of the specific model – always have a well defined operating temperature range.
  • Page 67 TOBY-L2 and MPCI-L2 series - System Integration Manual Figure 30 shows the flow diagram implemented for the Smart Temperature Supervisor. IF STS enabled Feature enabled Feature disabled: (full logic or no action indication only) Read temperature <Ti<t Temperature is within normal...

  • Page 68: Power Saving

    A preset RTC alarm occurs (see u-blox AT Commands Manual [3], AT+CALA) For the definition and the description of TOBY-L2 and MPCI-L2 series modules operating modes, including the events forcing transitions between the different operating modes, see the section 1.4.

  • Page 69: Design-In

    2 Design-in Overview For an optimal integration of TOBY-L2 and MPCI-L2 series modules in the final application board follow the design guidelines stated in this section. Every application circuit must be properly designed to guarantee the correct functionality of the relative interface, however a number of points require high attention during the design of the application device.

  • Page 70: Supply Interfaces

    RF and thermal performance. TOBY-L2 and MPCI-L2 series modules must be sourced through the VCC or the 3.3Vaux pins with a proper DC power supply that should meet the following prerequisites to comply with the modules’ VCC or 3.3Vaux requirements summarized in Table 7.
  • Page 71 VCC or 3.3Vaux pins within the specified operating range and must be capable of delivering to VCC or 3.3Vaux pins the maximum peak / pulse current consumption during Tx burst at maximum Tx power specified in the TOBY-L2 series Data Sheet [1] or in the MPCI-L2 series Data Sheet [2]. ...
  • Page 72 TOBY-L2 and MPCI-L2 series - System Integration Manual Figure 32 and Table 14 show an example of a high reliability power supply circuit, where the module VCC or 3.3Vaux input is supplied by a step-down switching regulator capable of delivering maximum current with low output ripple and with fixed switching frequency in PWM mode operation greater than 1 MHz.
  • Page 73 TOBY-L2 and MPCI-L2 series - System Integration Manual Figure 33 and the components listed in Table 15 show an example of a low cost power supply circuit, where the VCC module supply is provided by a step-down switching regulator capable of delivering to VCC pins the specified maximum peak / pulse current, transforming a 12 V supply input.
  • Page 74 VCC or 3.3Vaux pins within the specified operating range and must be capable of delivering to VCC or 3.3Vaux pins the maximum peak / pulse current consumption during Tx burst at maximum Tx power specified in TOBY-L2 series Data Sheet [1] or in MPCI-L2 series Data Sheet [2]. ...
  • Page 75 TOBY-L2 and MPCI-L2 series - System Integration Manual Figure 35 and the components listed in Table 17 show an example of a low cost power supply circuit, where the VCC module supply is provided by an LDO linear regulator capable of delivering the specified highest peak / pulse current, with proper power handling capability.
  • Page 76 (when current consumption on the VCC or 3.3Vaux supply can rise up as specified in TOBY-L2 series Data Sheet [1] or in MPCI-L2 series Data Sheet [2]), place a bypass capacitor with large capacitance (at least 100 µF) and low ESR near the VCC pins, for example: ...
  • Page 77 TOBY-L2 and MPCI-L2 series - System Integration Manual TOBY-L2 series MPCI-L2 series 3.3Vaux 3.3Vaux 3.3Vaux 3.3Vaux 3.3Vaux Figure 36: Suggested schematic for the VCC / 3.3Vaux bypass capacitors to reduce ripple / noise on supply voltage profile Reference Description Part Number - Manufacturer...
  • Page 78 TOBY-L2 and MPCI-L2 series - System Integration Manual 2.2.1.7 Guidelines for external battery charging circuit TOBY-L2 modules do not have an on-board charging circuit. Figure 37 provides an example of a battery charger design, suitable for applications that are battery powered with a Li-Ion (or Li-Polymer) cell.
  • Page 79 TOBY-L2 and MPCI-L2 series - System Integration Manual 2.2.1.8 Guidelines for external battery charging and power path management circuit Application devices where both a permanent primary supply / charging source (e.g. ~12 V) and a rechargeable back-up battery (e.g. 3.7 V Li-Pol) are available at the same time as possible supply source should implement a suitable charger / regulator with integrated power path management function to supply the module and the whole device while simultaneously and independently charging the battery.
  • Page 80 TOBY-L2 and MPCI-L2 series - System Integration Manual Battery charging is managed in three phases:  Pre-charge constant current (active when the battery is deeply discharged): the battery is charged with a low current, set to 10% of the fast-charge current ...
  • Page 81 RF signal. This is more likely to happen with switching DC-DC converters, in which case it is better to select the highest operating frequency for the switcher and add a large L-C filter before connecting to the TOBY-L2 and MPCI-L2 series modules in the worst case ...

  • Page 82: Rtc Supply Output (V_Bckp)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.2.2 RTC supply output (V_BCKP) The RTC supply V_BCKP pin is not available on MPCI-L2 series modules. 2.2.2.1 Guidelines for V_BCKP circuit design TOBY-L2 series modules provide the V_BCKP RTC supply input/output, which can be mainly used to: ...
  • Page 83 TOBY-L2 and MPCI-L2 series - System Integration Manual If the RTC timing is not required when the VCC supply is removed, it is not needed to connect the V_BCKP pin to an external capacitor or battery. In this case the date and time are not updated when VCC is disconnected.

  • Page 84: Generic Digital Interfaces Supply Output (V_Int)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.2.3 Generic digital interfaces supply output (V_INT) The generic digital interfaces supply V_INT pin is not available on MPCI-L2 series modules. 2.2.3.1 Guidelines for V_INT circuit design TOBY-L2 series provide the V_INT generic digital interfaces 1.8 V supply output, which can be mainly used to: ...

  • Page 85: System Functions Interfaces

    TOBY-L2 and MPCI-L2 series - System Integration Manual System functions interfaces 2.3.1 Module power-on (PWR_ON) The PWR_ON input pin is not available on MPCI-L2 series modules. 2.3.1.1 Guidelines for PWR_ON circuit design TOBY-L2 series PWR_ON input is equipped with an internal active pull-up resistor to the VCC module supply as described in Figure 41: an external pull-up resistor is not required and should not be provided.

  • Page 86: Module Reset (Reset_N Or Perst#)

    Guidelines for RESET_N and PERST# circuit design The TOBY-L2 series RESET_N is equipped with an internal pull-up to the VCC supply and the MPCI-L2 series PERST# is equipped with an internal pull-up to the 3.3 V rail, as described in Figure 42. An external pull-up resistor is not required and should not be provided.

  • Page 87: Module Configuration Selection By Host Processor

    It is recommended to keep the connection line to RESET_N and PERST# pins as short as possible. 2.3.3 Module configuration selection by host processor The HOST_SELECT0 and HOST_SELECT1 pins are not available on MPCI-L2 series modules. 2.3.3.1 Guidelines for HOST_SELECTx circuit design The functionality of the HOST_SELECT0 and HOST_SELECT1 pins is not supported by the TOBY-L2 “00”,...

  • Page 88: Antenna Interface

    RF compliance of the device integrating TOBY-L2 and MPCI-L2 series modules with all the applicable required certification schemes depends on antennas radiating performance.
  • Page 89 TOBY-L2 and MPCI-L2 series - System Integration Manual Radiation performance depends on the whole PCB and antenna system design, including product mechanical design and usage. Antennas should be selected with optimal radiating performance in the operating bands according to the mechanical specifications of the PCB and the whole product.
  • Page 90 For applications requiring an internal integrated SMT antenna, it is suggested to use a U-FL-to-U.FL cable to provide RF path from the MPCI-L2 series module to PCB strip line or micro strip connected to antenna pads as shown in Figure 44. Take care that the PCB-to-RF-cable transition, strip line and antenna pads must be designed so that the characteristic impedance is as close as possible to 50 : see the following subsections for specific...
  • Page 91 TOBY-L2 and MPCI-L2 series - System Integration Manual Guidelines for RF transmission line design Any RF transmission line, such as the ones from the ANT1 and ANT2 pads up to the related antenna connector or up to the related internal antenna pad, must be designed so that the characteristic impedance is as close as possible to 50 .
  • Page 92 TOBY-L2 and MPCI-L2 series - System Integration Manual  the gap from the transmission line to the adjacent ground plane on the same layer of the transmission line (e.g. 500 µm in Figure 45, 400 µm in Figure 46) If the distance between the transmission line and the adjacent GND area (on the same layer) does not exceed 5 times the track width of the micro strip, use the “Coplanar Waveguide”...
  • Page 93 TOBY-L2 and MPCI-L2 series - System Integration Manual Guidelines for RF termination design RF terminations must provide a characteristic impedance of 50  as well as the RF transmission lines up to the RF terminations themselves, to match the characteristic impedance of the ANT1 / ANT2 ports of the modules.
  • Page 94 TOBY-L2 and MPCI-L2 series - System Integration Manual Examples of antennas Table 25 lists some examples of possible internal on-board surface-mount antennas. Manufacturer Part Number Product Name Description Taoglas PA.710.A Warrior GSM / WCDMA / LTE SMD Antenna 698..960 MHz, 1710..2170 MHz, 2300..2400 MHz, 2490..2690 MHz 40.0 x 6.0 x 5.0 mm...
  • Page 95 TOBY-L2 and MPCI-L2 series - System Integration Manual Table 27 lists some examples of possible external antennas. Manufacturer Part Number Product Name Description Taoglas GSA.8827.A.101111 Phoenix GSM / WCDMA / LTE adhesive-mount antenna with cable and SMA(M) 698..960 MHz, 1575.42 MHz, 1710..2170 MHz, 2490..2690 MHz 105 x 30 x 7.7 mm...

  • Page 96: Antenna Detection Interface (Ant_Det)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.4.2 Antenna detection interface (ANT_DET) Antenna detection (ANT_DET) is not available on MPCI-L2 series modules Antenna detection (ANT_DET) is not supported by TOBY-L2 ”00”, “01”, and “50” product versions 2.4.2.1 Guidelines for ANT_DET circuit design...
  • Page 97 TOBY-L2 and MPCI-L2 series - System Integration Manual The DC impedance at RF port for some antennas may be a DC open (e.g. linear monopole) or a DC short to reference GND (e.g. PIFA antenna). For those antennas, without the diagnostic circuit of Figure 48, the measured...

  • Page 98: Sim Interface

    SIM connector for the mechanical card presence detection are provided. Select a SIM connector providing 6+2 or 8+2 positions if the optional SIM detection feature (not available on MPCI-L2 series) is required by the custom application, otherwise a connector without integrated mechanical presence switch can be selected.
  • Page 99 A removable SIM card placed in a SIM card holder must be connected to the SIM card interface of TOBY-L2 and MPCI-L2 series modules as described in Figure 49, where the optional SIM detection feature is not implemented. Follow these guidelines to connect the module to a SIM connector without SIM presence detection: ...
  • Page 100 TOBY-L2 and MPCI-L2 series - System Integration Manual Guidelines for single SIM chip connection A solderable SIM chip (M2M UICC Form Factor) must be connected the SIM card interface of TOBY-L2 and MPCI-L2 series modules as described in Figure 50.
  • Page 101 TOBY-L2 and MPCI-L2 series - System Integration Manual Guidelines for single SIM card connection with detection A removable SIM card placed in a SIM card holder must be connected to the SIM card interface of TOBY-L2 modules as described in Figure 51, where the optional SIM card detection feature is implemented.
  • Page 102 Figure 52. TOBY-L2 and MPCI-L2 series modules do not support the usage of two SIM at the same time, but two SIM can be populated on the application board, providing a proper switch to connect only the first or only the second SIM at a time to the SIM interface of the modules, as described in Figure 52.
  • Page 103 TOBY-L2 and MPCI-L2 series - System Integration Manual FIRST SIM CARD TOBY-L2 series VPP (C6) 4PDT VCC (C1) Analog IO (C7) Switch CLK (C3) 1VSIM VSIM VSIM 2VSIM RST (C2) 1DAT SIM_IO GND (C5) 2DAT C2 C3 D1 D2 D3 D4...

  • Page 104: Guidelines For Sim Layout Design

    The layout of the SIM card interface lines (VSIM, SIM_CLK, SIM_IO, SIM_RST or UIM_PWR, UIM_DATA, UIM_CLK, UIM_RESET) may be critical if the SIM card is placed far away from the TOBY-L2 and MPCI-L2 series modules or in close proximity to the RF antenna: these two cases should be avoided or at least mitigated as described below.

  • Page 105: Data Communication Interfaces

    (for more details, see section 1.9.1.1). The VUSB_DET pin is not available on MPCI-L2 series modules. Routing the USB pins to a connector, they will be externally accessible on the application device. According to EMC/ESD requirements of the application, an additional ESD protection device with very low capacitance should be provided close to accessible point on the line connected to this pin, as described in Figure 53 and Table 33.
  • Page 106 TOBY-L2 and MPCI-L2 series - System Integration Manual If the USB interface pins are not used, they can be left unconnected on the application board, but it is recommended providing accessible test points directly connected to USB_D+ and USB_D- pins.

  • Page 107: Asynchronous Serial Interface (Uart)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.6.2 Asynchronous serial interface (UART) The UART interface is not available on MPCI-L2 series modules. 2.6.2.1 Guidelines for UART circuit design The UART interface is not supported by TOBY-L200-00S and TOBY-L210-00S product versions: all the UART pins should not be driven by any external device.
  • Page 108 TOBY-L2 and MPCI-L2 series - System Integration Manual Providing the TXD, RXD, RTS and CTS lines only (not using the complete V.24 link) If the functionality of the DSR, DCD, RI and DTR lines is not required in, or the lines are not available: ...
  • Page 109 TOBY-L2 and MPCI-L2 series - System Integration Manual Providing the TXD and RXD lines only (not using the complete V24 link) If the functionality of the CTS, RTS, DSR, DCD, RI and DTR lines is not required in the application, or the lines are not available, then: ...
  • Page 110 TOBY-L2 and MPCI-L2 series - System Integration Manual Additional considerations If a 3.0 V Application Processor (DTE) is used, the voltage scaling from any 3.0 V output of the DTE to the corresponding 1.8 V input of the module (DCE) can be implemented as an alternative low-cost solution, by means of an appropriate voltage divider.

  • Page 111: Ddc (I C) Interface

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.6.3 DDC (I C) interface The I C bus compatible Display Data Channel interface is not available on MPCI-L2 series modules. 2.6.3.1 Guidelines for DDC (I C) circuit design C bus function is not supported by TOBY-L2 “00”, “01”, and “50” product versions: the pins should not be driven by any external device.
  • Page 112 TOBY-L2 and MPCI-L2 series - System Integration Manual Connection with u-blox 1.8 V GNSS receivers Figure 62 shows an application circuit for connecting TOBY-L2 cellular modules to a u-blox 1.8 V GNSS receiver.  SDA / SCL pins of the TOBY-L2 cellular module are directly connected to the relative I C pins of the u-blox 1.8 V GNSS receiver, with appropriate pull-up resistors connected to the 1.8 V GNSS supply enabled after...
  • Page 113 TOBY-L2 and MPCI-L2 series - System Integration Manual Figure 63 illustrates an alternative application circuit solution in which the TOBY-L2 supplies a u-blox 1.8 V GNSS receiver. The V_INT 1.8 V regulated supply output of a TOBY-L2 module can be used as supply source for a u-blox 1.8 V GNSS receiver (u-blox 6 generation receiver or newer) instead of using an external voltage...
  • Page 114 TOBY-L2 and MPCI-L2 series - System Integration Manual Connection with u-blox 3.0 V GNSS receivers Figure 64 shows an application circuit for connecting TOBY-L2 cellular modules to a u-blox 3.0 V GNSS receiver:  As the SDA and SCL pins of the TOBY-L2 cellular module are not tolerant up to 3.0 V, the connection to the related I C pins of the u-blox 3.0 V GNSS receiver must be provided using a proper I...

  • Page 115: Secure Digital Input Output Interface (Sdio)

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.6.4 Secure Digital Input Output interface (SDIO) The SDIO Secure Digital Input Output interface is not available on MPCI-L2 series modules. 2.6.4.1 Guidelines for SDIO circuit design The functionality of the SDIO Secure Digital Input Output interface pins is not supported by TOBY-L2 “00”...
  • Page 116 TOBY-L2 and MPCI-L2 series - System Integration Manual TOBY-L2xx-50S ELLA-W1 series cellular module Wi-Fi module LDO regulator SHDNn SENSE LED_0 V_INT LDO regulator Wi-Fi SHDNn SENSE antenna Band-Pass filter ANT1 SDIO_D0 SD_D0 ANT2 SDIO_D1 SD_D1 SDIO_D2 SD_D2 SDIO_D3 SD_D3 SDIO_CLK...

  • Page 117: Audio Interface

    TOBY-L2 and MPCI-L2 series - System Integration Manual Audio interface 2.7.1 Digital audio interface The I S interface is not available on MPCI-L2 series modules. 2.7.1.1 Guidelines for digital audio circuit design The I S interface is not supported by TOBY-L2 “00”, “01”, and “50” product versions: the pins should not be driven by any external device.
  • Page 118 TOBY-L2 and MPCI-L2 series - System Integration Manual TOBY-L2 series (except ‘00’, ‘01’, ‘50’ versions) V_INT Audio Codec IRQn MICBIAS Microphone Connector EMI1 MICLP EMI2 MICLN I2S_TXD SDIN I2S_RXD SDOUT C12 C11 I2S_CLK BCLK MICGND Speaker I2S_WA LRCLK Connector EMI3...

  • Page 119: General Purpose Input/Output

    TOBY-L2 and MPCI-L2 series - System Integration Manual General Purpose Input/Output GPIOs are not supported by TOBY-L2 “00”, “01”, and “50” product versions, except for the WWAN status indication configured on GPIO1 of “00”, “01” product versions and the Wi-Fi enable function configured on GPIO1 of “50”...

  • Page 120: Mini Pcie Specific Signals (W_Disable#, Led_Wwan#)

    Guidelines for W_DISABLE# circuit design As described in Figure 68, the MPCI-L2 series modules W_DISABLE# wireless disable input is equipped with an internal pull-up to the 3.3Vaux supply: an external pull-up resistor is not required and should not be provided.

  • Page 121: Reserved Pins (Rsvd)

    2.9.1.2 Guidelines for LED_WWAN# circuit design As described in Figure 69 and Table 44, the MPCI-L2 series modules LED_WWAN# active-low open drain output can be directly connected to a system-mounted LED to provide the Wireless Wide Area Network status indication as specified by the PCI Express Mini Card Electromechanical Specification [15].

  • Page 122: Module Placement

    Provide enough clearance between the module and any external part. The heat dissipation during continuous transmission at maximum power can significantly raise the temperature of the application base-board below the TOBY-L2 and MPCI-L2 series modules: avoid placing temperature sensitive devices close to the module.

  • Page 123: Toby-L2 Series Module Footprint And Paste Mask

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.12 TOBY-L2 series module footprint and paste mask Figure 71 and Table 45 describe the suggested footprint (i.e. copper mask) layout for TOBY-L2 series modules. The proposed land pattern layout slightly reflects the modules’ pads layout, with most of the lateral pads designed wider on the application board (1.8 x 0.8 mm) than on the module (1.5 x 0.8 mm).

  • Page 124: Mpci-L2 Series Module Installation

    2.13 MPCI-L2 series module installation MPCI-L2 series modules are fully compliant with the 52-pin PCI Express Full-Mini Card Type F2 form factor, i.e., top-side and bottom-side keep-out areas, 50.95 mm nominal length, 30 mm nominal width, and all the other dimensions as defined by the PCI Express Mini Card Electromechanical Specification [15], except for the card thickness (which nominal value is 3.7 mm), as described in Figure 72.
  • Page 125 TOBY-L2 and MPCI-L2 series - System Integration Manual MPCI-L2 series modules are equipped with two Hirose U.FL-R-SMT RF receptacles for ANT1 / ANT2 ports, which require a suitable mated RF plug from the same connector series as the examples listed in Table 24.

  • Page 126: Thermal Guidelines

    During transmission at maximum RF power the TOBY-L2 and MPCI-L2 series modules generate thermal power that may exceed 3 W: this is an indicative value since the exact generated power strictly depends on operating condition such as the actual antenna return loss, the number of allocated TX resource blocks, the transmitting frequency band, etc.

  • Page 127: Esd Guidelines

    ESD sensitivity for each pin (as Human Body Model according to JESD22-A114F) is specified in TOBY-L2 series Data Sheet [1] or MPCI-L2 series Data Sheet [2]. Special precautions are required when handling the pins; for ESD handling guidelines see section 3.2.

  • Page 128: Esd Immunity Test Of Toby-L2 And Mpci-L2 Series Reference Designs

    Antenna interface The ANT1 and ANT2 ports of TOBY-L2 and MPCI-L2 series modules provide ESD immunity up to ±4 kV for direct Contact Discharge and up to ±8 kV for Air Discharge: no further precaution to ESD immunity test is needed, as implemented in the EMC / ESD approved reference design of TOBY-L2 and MPCI-L2 series modules.
  • Page 129 The antenna interface application circuit implemented in the EMC / ESD approved reference designs of TOBY-L2 and MPCI-L2 series modules is described in Figure 47 in case of antennas detection circuit not implemented, and is described in Figure 48 and Table 28 in case of antennas detection circuit implemented (section 2.4).

  • Page 130: Schematic For Toby-L2 And Mpci-L2 Series Module Integration

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.16 Schematic for TOBY-L2 and MPCI-L2 series module integration 2.16.1 Schematic for TOBY-L200-00S / TOBY-L210-00S Figure 75 is an example of a schematic diagram where a TOBY-L200-00S / TOBY-L210-00S module is integrated into an application board, using all the available interfaces and functions of the module.

  • Page 131: Schematic For Toby-L201-01S / Toby-L280-00S

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.16.2 Schematic for TOBY-L201-01S / TOBY-L280-00S Figure 76 is an example of a schematic diagram where a TOBY-L201-01S / TOBY-L280-00S module is integrated into an application board, using all the available interfaces and functions of the module.

  • Page 132: Schematic For Toby-L200-50S / Toby-L210-50S

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.16.3 Schematic for TOBY-L200-50S / TOBY-L210-50S Figure 77 is an example of a schematic diagram where a TOBY-L200-50S / TOBY-L210-50S module is integrated into an application board, using all the available interfaces and functions of the module.

  • Page 133: Schematic For Mpci-L2 Series

    GND (C5) 100nF 47pF 47pF 47pF 47pF WWAN Indicator LED_WWAN# Figure 78: Example of schematic diagram to integrate a MPCI-L2 series module in an application board, using all the interfaces UBX-13004618 - R07 Advance Information Design-in Page 133 of 158...

  • Page 134: Design-In Checklist

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.17 Design-in checklist This section provides a design-in checklist. 2.17.1 Schematic checklist The following are the most important points for a simple schematic check:  DC supply must provide a nominal voltage at VCC / 3.3Vaux pin within the operating range limits.

  • Page 135: Layout Checklist

    TOBY-L2 and MPCI-L2 series - System Integration Manual 2.17.2 Layout checklist The following are the most important points for a simple layout check:  Check 50  nominal characteristic impedance of the RF transmission line connected to the ANT1 and the ANT2 ports (antenna RF interfaces).

  • Page 136: Handling And Soldering

    The ESD sensitivity for each pin of TOBY-L2 and MPCI-L2 series modules (as Human Body Model according to JESD22-A114F) is specified in the TOBY-L2 series Data Sheet [1] or the MPCI-L2 series Data Sheet [2].

  • Page 137: Soldering

    TOBY-L2 and MPCI-L2 series - System Integration Manual Soldering 3.3.1 Soldering paste "No Clean" soldering paste is strongly recommended for TOBY-L2 series modules, as it does not require cleaning after the soldering process has taken place. The paste listed in the example below meets these criteria.

  • Page 138: Optical Inspection

    TOBY-L2 and MPCI-L2 series - System Integration Manual To avoid falling off, modules should be placed on the topside of the motherboard during soldering. The soldering temperature profile chosen at the factory depends on additional external factors like choice of soldering paste, size, thickness and properties of the base board, etc.

  • Page 139: Repeated Reflow Soldering

    TOBY-L2 and MPCI-L2 series - System Integration Manual 3.3.5 Repeated reflow soldering Only a single reflow soldering process is encouraged for boards with a module populated on it. 3.3.6 Wave soldering Boards with combined through-hole technology (THT) components and surface-mount technology (SMT) devices require wave soldering to solder the THT components.

  • Page 140: Approvals

    The required certification scheme approvals and relative testing specifications differ depending on the country or the region where the device that integrates TOBY-L2 and MPCI-L2 series modules must be deployed, on the relative vertical market of the device, on type, features and functionalities of the whole application device, and on the network operators where the device must operate.

  • Page 141: Federal Communications Commission And Industry Canada Notice

    The gain of the system antenna(s) used for the TOBY-L2 and MPCI-L2 series modules except for TOBY-L201 (i.e. the combined transmission line, connector, cable losses and radiating element gain) must not exceed 9.8 dBi (700 MHz, i.e.
  • Page 142 TOBY-L2 and MPCI-L2 series - System Integration Manual The gain of the system antenna(s) used for TOBY-L201 (i.e. the combined transmission line, connector, cable losses and radiating element gain) must not exceed 9.5 dBi ( LTE FDD-17 band), 9.9 dBi (LTE FDD-13 band), 9.7 dBi (LTE FDD-5 band), 6.8 dBi (LTE FDD-4 band), 8.5 dBi (LTE FDD-2 band), 9.7 dBi (UMTS FDD-5 band), 8.5 dBi (UMTS FDD-2 band) for mobile and fixed or mobile...

  • Page 143: Modifications

    Manufacturers of mobile or fixed devices incorporating the TOBY-L2 and MPCI-L2 series modules are authorized to use the FCC Grants and Industry Canada Certificates of the TOBY-L2 series modules for their own final products according to the conditions referenced in the certificates.
  • Page 144 TOBY-L2 and MPCI-L2 series - System Integration Manual Canada, avis d'Industrie Canada (IC) Cet appareil numérique de classe B est conforme aux normes canadiennes CAN ICES-3(B) / NMB-3(B) et CNR-210. Son fonctionnement est soumis aux deux conditions suivantes: cet appareil ne doit pas causer d'interférence cet appareil doit accepter toute interférence, notamment les interférences qui peuvent...

  • Page 145: R&Tted And European Conformance Ce Mark

    TOBY-L2 and MPCI-L2 series - System Integration Manual R&TTED and European Conformance CE mark The modules have been evaluated against the essential requirements of the 1999/5/EC Directive. In order to satisfy the essential requirements of the 1999/5/EC Directive, the modules are compliant with the following standards: ...

  • Page 146: Product Testing

    TOBY-L2 and MPCI-L2 series - System Integration Manual 5 Product testing u-blox in-series production test u-blox focuses on high quality for its products. All units produced are fully tested automatically in production line. Stringent quality control process has been implemented in the production line. Defective units are analyzed in detail to improve the production quality.

  • Page 147: Test Parameters For Oem Manufacturer

    TOBY-L2 and MPCI-L2 series - System Integration Manual Test parameters for OEM manufacturer Because of the testing done by u-blox (with 100% coverage), an OEM manufacturer does not need to repeat firmware tests or measurements of the module RF performance or tests over analog and digital interfaces in their production test.
  • Page 148 TOBY-L2 and MPCI-L2 series - System Integration Manual This feature allows the measurement of the transmitter and receiver power levels to check component assembly related to the module antenna interface and to check other device interfaces from which depends the RF performance.

  • Page 149: Appendix

    TOBY-L2 and MPCI-L2 series - System Integration Manual Appendix A Glossary 3GPP 3rd Generation Partnership Project 8-PSK 8 Phase-Shift Keying modulation 16QAM 16-state Quadrature Amplitude Modulation 64QAM 64-state Quadrature Amplitude Modulation Abstract Control Model Analog to Digital Converter Application Processor...
  • Page 150 TOBY-L2 and MPCI-L2 series - System Integration Manual Internet Protocol Low-Dropout Land Grid Array Low Noise Amplifier LPDDR Low Power Double Data Rate synchronous dynamic RAM memory Long Term Evolution Machine-to-Machine MBIM Mobile Broadband Interface Model MIMO Multi-Input Multi-Output Not Applicable N.A.

  • Page 151: B Migration Between Toby-L1 And Toby-L2

    TOBY-L2 and MPCI-L2 series - System Integration Manual B Migration between TOBY-L1 and TOBY-L2 B.1 Overview TOBY-L1 and TOBY-L2 series cellular modules have exactly the same TOBY form factor (35.6 x 24.8 mm LGA) with exactly the same 152-pin layout as described in Figure 82, so that the modules can be alternatively mounted on a single application board using exactly the same copper mask, solder mask and paste mask.
  • Page 152 TOBY-L2 and MPCI-L2 series - System Integration Manual Table 49 summarizes the interfaces provided: TOBY-L2 series modules make available additional interfaces over pins remarked as reserved on TOBY-L1 series modules (highlighted in blue in Figure 82). Module Radio Access Technology...

  • Page 153: Pin-Out Comparison Between Toby-L1 And Toby-L2

    TOBY-L2 and MPCI-L2 series - System Integration Manual B.2 Pin-out comparison between TOBY-L1 and TOBY-L2 TOBY-L1 TOBY-L2 Pin No Pin Name Description Pin Name Description Remarks for migration RSVD Reserved RSVD Reserved Ground Ground V_BCKP RTC Supply Output V_BCKP RTC Supply Input/Output RTC back-up: No ...
  • Page 154 TOBY-L2 and MPCI-L2 series - System Integration Manual TOBY-L1 TOBY-L2 Pin No Pin Name Description Pin Name Description Remarks for migration RSVD Reserved C Clock Output Reserved  I2C RSVD Reserved C Data I/O Reserved  I2C SIM_CLK SIM Clock Output...

  • Page 155: Schematic For Toby-L1 And Toby-L2 Integration

    TOBY-L2 and MPCI-L2 series - System Integration Manual B.3 Schematic for TOBY-L1 and TOBY-L2 integration Figure 85 shows an example schematic diagram where a TOBY-L1 series module (“00” product version) or a TOBY-L2 series module (“00”, “01” or “50” product versions) can be integrated into the same application board, using all the available interfaces and functions of the module.

  • Page 156: Related Documents

    TOBY-L2 and MPCI-L2 series - System Integration Manual Related documents u-blox TOBY-L2 series Data Sheet, Docu No UBX-13004573 u-blox MPCI-L2 series Data Sheet, Docu No UBX-13004749 u-blox AT Commands Manual, Docu No UBX-13002752 u-blox EVK-L20 / EVK-L21 User Guide, Docu No UBX-14000422 u-blox Firmware Update Application Note, Docu No UBX-13001845 Universal Serial Bus Revision 2.0 specification, http://www.usb.org/developers/docs/usb20_docs/...

  • Page 157: Revision History

    TOBY-L2 and MPCI-L2 series - System Integration Manual Revision history Revision Date Name Status / Comments 20-Dec-2013 sses Initial release for TOBY-L2 series 21-Mar-2014 sses Initial release including MPCI-L2 series UART and GPIOs remarked as not supported by TOBY-L2x0-00S 23-Jul-2014...

  • Page 158: Contact

    TOBY-L2 and MPCI-L2 series - System Integration Manual Contact For complete contact information visit us at http://www.u-blox.com/ u-blox Offices North, Central and South America Headquarters Asia, Australia, Pacific Europe, Middle East, Africa u-blox America, Inc. u-blox Singapore Pte. Ltd. u-blox AG...
