- Page 1 HSD820H3PRH Pressurised IP PTZ dome camera with multistream H.264; 30x zoom...
- Page 2 Any brand names mentioned in this manual are registered trademarks of their respective owners. Liability Siqura accepts no liability for claims from third parties arising from improper use other than that stated in this manual. Although considerable care has been taken to ensure a correct and suitably comprehensive description of all relevant product components, this manual may nonetheless contain errors and inaccuracies.
-
Page 3: Table Of Contents
Contents About this manual ..................Safety and compliance ................Safety ....................Cautions ..................... Compliance ..................Product description ................... Product overview ................. Package contents ................. Connect the camera .................. Cable requirements ................Connect cables ..................Connect to network ................Establish a network connection .............. System compatibility ................ -
Page 4: About This Manual
About this manual What's in this manual This manual gives you the information you need to install the HSD820H3PRH camera. It tells: ● How to mount the camera ● How to connect the camera ● How to power the camera ●... -
Page 5: Safety And Compliance
Failure to comply with any precaution, warning, or instruction noted in the manual is in violation of the standards of design, manufacture, and intended use of the module. Siqura assumes no liability for the customer's failure to comply with any of these safety requirements. -
Page 6: Cautions
European Union (EU) to enact the Directive on the Restriction of the use of certain Hazardous Substances (RoHS) (2002/95/EC). Siqura offers products that comply with the EU’s RoHS Directive. The full version of the Siqura RoHS statement can be viewed at www.siqura.com. -
Page 7: Compliance
Make sure that the power source is appropriate before you plug in and operate the unit. Use the unit under conditions where the temperature remains within the range given in the Technical Specifications of this product. You can download the HSD820H3PRH datasheet at www.siqura.com. -
Page 8: Product Description
Product description The HSD820H3PRH high-speed pressurised IP dome camera is designed to deliver superb performance and durability with a pressurised housing. Pressurisation eliminates the effects of moisture, dirt, and pollution on valuable camera equipment. In This Chapter 3.1 Product overview....................8 3.2 Package contents....................8... -
Page 9: Connect The Camera
Connect the camera This chapter describes how to connect power, network and alarm cables to the camera. In This Chapter 4.1 Cable requirements....................9 4.2 Connect cables....................... 9 4.3 Connect to network....................10 4.4 Establish a network connection................10 4.5 System compatibility..................... 11 Cable requirements For operation, the camera requires a video and cable harness, as described below. -
Page 10: Connect To Network
The webpages of the HSD820H3PRH provide a convenient way of accessing its settings. You can log on to the web interface of the HSD820H3PRH from a PC which is on the same subnet as the unit. Follow the steps below to open communication with the HSD820H3PRH and configure its network settings. -
Page 11: System Compatibility
Step 2: Access the unit Using a standard web browser you can now log on to the web server of the HSD820H3PRH. Step 3: Change the network settings of the unit The Network page enables you to make the network addressing of the unit compatible with the network it will be added to. -
Page 12: Pressurise The Camera
Pressurise the camera The HSD820H3PRH is not pressurised at the factory. Complete the steps below to pressurise the camera before you install it. Step 1 Set the gauge or regulator from 10 to 20 psi (.7 to 1.4 bar). Step 2 Place the air chuck on the tank valve and begin filling until the pressure relief valve opens. -
Page 13: Dome Installation
6.5 Corner mount....................... 17 6.6 Pole mount......................18 Dome dimensions The HSD820H3PRH dome dimensions are 366 x 285 x Ø285 mm (14.4 x 11.2 x Ø11.2 in). Installation scenarios Choose your installation scenario from the list below for complete instructions for performing that installation. -
Page 14: Ceiling Mount
Make sure the camera cannot move at all in its bracket after installation. Any movement of the camera in its bracket can compromise positional accuracy. Ceiling mount There is one ceiling mounting option for the HSD820H3PRH outdoor dome camera: ● Ceiling mounting with a straight tube 6.3.1 Ceiling mounting with a straight tube The only ceiling mount for the HSD820H3PRH is the straight tube mount. -
Page 15: Wall Mount
Connect the cables to the dome camera. Then attach the dome to the outdoor tube adaptor and fix them with the supplied screw. Wall mount There are two types of wall mounts for the HSD820H3PRH dome camera. ● Mounting with a mini wall mount, as shown in the section Mini wall mount. -
Page 16: Wall Box Mounting
Wall box mount and other equipped items (optional accessory) ● Gooseneck tube (optional accessory) ● Screws and screw anchors (not supplied) ● Indoor tube adapter for the HSD820H3PRH (optional accessory) ● Waterproof boot (supplied with the indoor tube adapter) Tools needed ● Drill ●... -
Page 17: Corner Mount
Wall box mounting: wall box mount + gooseneck tube + waterproof boot + indoor tube adapter Corner mount With the corner standard mounting plate and gooseneck tube/mini wall mount, the HSD820H3PRH can be mounted onto the corner or a wall. Items needed ● Dome camera ●... -
Page 18: Pole Mount
Corner wall mounting: corner standard mounting plate + gooseneck tube/ mini wall mount + indoor tube adapter + waterproof boot Pole mount There are two ways to mount the HSD820H3PRH cameras on a pole: ● Using a thin/wide direct mount as described in the section Pole thin/wide direct mounting. -
Page 19: Pole Thin/Wide Direct Mounting
Items needed ● Dome camera ● Gooseneck tube and other equipped items (optional accessory) ● Indoor tube adapter for the HSD820H3PRH (optional accessory) ● Waterproof boot (supplied with the indoor tube adapter) ● Pole thin direct mounting (optional accessory) ●... -
Page 20: Pole Thin/Wide Box Mounting
Items needed ● Dome camera ● Gooseneck tube and other equipped items (optional accessory) ● Indoor tube adapter for the HSD820H3PRH (optional accessory) ● Waterproof boot (supplied with the indoor tube adapter) ● Pole wide box (optional accessory) ● Stainless steel straps (optional accessory) Tools needed ●...
