FLIR SCOUT TK User Manual page 9

3.1.5 SNAPSHOT BUTTON
The snapshot button is used to capture images and to record
video. Up to 1000 pictures and up to 4 hours of recorded video
can be stored in the camera's internal memory at one time.
The Gallery (accessible via the user menu) can be used to view
captured images and recordings. Note: Recordings cannot be
played back in the photo gallery, the first frame is displayed in
the gallery. See User Menu section for details.
3.1.5.1 TAKING A PICTURE
Perform a short press of the snapshot button to capture a
single image. The camera icon will be displayed briefly.
If the snapshot button is pressed before the previous image
has been saved, the new snapshot image is buffered. The
snapshot buffer can hold up to six images at a time. When the
snapshot buffer is full, a "Please wait..." warning is displayed.
Snapshot Buffer Full Message
The FLIR SCOUT TK has internal storage for up to 1000
images. When the image storage space is exhausted, a
"Gallery full" warning is displayed.
Image Storage Full Message
info@FLIR-Direct.ca
FLIR-DIRECT
U S E R M A N U A L #
3.1.4.2 RECORDING VIDEO
To record a video, press and hold the snapshot button. A
movie camera icon and elapsed time counter will be shown
while a video is recording.
To end recording and save the video to the camera's internal
storage, press the snapshot button.
Recording icon with elapsed time counter
The FLIR SCOUT TK has internal storage for up to 4 hours of
video. When the video storage space is exhausted, a "Video
media full" warning is displayed.
Recording Capacity Exceeded
3.2 BATTERY METER
The following image explains the battery meter when
operating on battery or external power.
4204190 - Rev 1
Snapshot button
