Summary of Contents for FLIR ARMASIGHT
- Page 1 SPARK ® ARMASIGHT by FLIR Night Vision Monocular U S E R M A N U A L...
- Page 2 © 2018 FLIR Systems, Inc. All rights reserved worldwide. No parts of this manual, in whole or in part, may be copied, photocopied, translated, or transmitted by any electronic medium or in machine-readable form without the prior written permission of FLIR Systems, Inc.
- Page 3 Business users should contact their supplier or refer to their purchase contract. IMPORTANT INSTRUCTIONS AND NOTICES TO THE USER: Modification of this device without the express authorization of FLIR Commercial Systems, Inc. may void the user’s authority under FCC rules to operate this device.
-
Page 4: Table Of Contents
4. PREVENTIVE MAINTENANCE AND TROUBLESHOOTING 4.1 Preventive Maintenance Checks and Services 4.2 Troubleshooting 4.3 Identification of Operational Defects 4.4 Maintenance APPENDIX A. Spark List of Spare Parts SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 5: Safety Summary
– If you inhale or swallow any phosphor screen material, drink a lot of water, induce vomiting, and seek medical attention as soon as possible. SPARK ARMASIGHT by FLIR U S E R M A N U A L... - Page 6 • The Spark is not a weapon sight. However, it can be used in conjunction with a collimator dot sight or laser aiming device. • For the purpose of returning defective components, retain all packaging materials. SPARK ARMASIGHT by FLIR U S E R M A N U A L...
-
Page 7: Introduction
WARRANTY INFORMATION For warranty information and customer support visit www.armasight.com/customer-support 1.2.2 PRODUCT REGISTRATION In order to validate the warranty on your product, the Customer must complete and submit FLIR Outdoor & Tactical Systems’ PRODUCT REGISTRATION FORM on our website (www.armasight.com/customer- support). -
Page 8: Description And Data
– The equipment will not “see” through dense smoke. SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 9: Specifications
38 x 21 x 7.5 Swing Arm #37* 49 x 46 x 64 3x Afocal Lens* Dia 61 x 73 5x Afocal Lens* Dia 78 x 90 * Optional SPARK ARMASIGHT by FLIR U S E R M A N U A L... - Page 10 Storage Temperature -50 to +70°C Humidity 95%, 25°C to 40°C for 48 hr Illumination Required Natural night illumination (overcast starlight to moonlight) Environmental Rating Water and fog-resistant SPARK ARMASIGHT by FLIR U S E R M A N U A L...
-
Page 11: Standard Components
FIGURE 2-2. SPARK STANDARD COMPONENTS TABLE 2-6. SPARK STANDARD COMPONENTS ITEM NO. DESCRIPTION QUANTITY Night Vision Monocular Lens Cap Eye-cup CR123A Lithium Battery Operation and Maintenance Manual Carrying Case SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 12: Optional Equipment
Swing Arm #172 ANHM000172 Quick Release Picatinny Mount Adapter #26/ #142 ANAM000004 IR850-XLR Detachable Long-Range Infrared Illuminator w/Dovetail to Weaver Transfer Piece #21, Rechargeable ANKIXLR017 Battery, and Charger SPARK ARMASIGHT by FLIR U S E R M A N U A L... - Page 13 TABLE 2-7. CONTINUED IMAGE DESCRIPTION PART NO. IR850-XLR Doubler ANAF18XLRM Extended Rail Adapter #85 ANAM000045 Universal Camera Adapter #45 ANAM000006 Hard Shipping/Storage Case #101 ANHC000001 SPARK ARMASIGHT by FLIR U S E R M A N U A L...
-
Page 14: Key Features
• Adaptable for use with cameras • Compatibility with most weapons, IR laser aiming/ illuminating devices, reflex sights, and scopes • Water and fog-resistant • Limited two-year warranty SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 15: Operating Instructions
2. Loosen the screw (A). While pushing down on the button (B), insert the Spark rail into the guide (C) of the goggle kit bracket. Tighten the screw (A). SPARK ARMASIGHT by FLIR U S E R M A N U A L... - Page 16 4. Put on the helmet with the Spark attached. 5. Push the button (F) and move the unit along the slide-rail (G) until the most comfortable position is reached. SPARK ARMASIGHT by FLIR U S E R M A N U A L...
- Page 17 2. Install the QRM on the weapon rail by inserting the stop (not shown in Figure 3-4) into one of transverse slots of the weapon rail. SPARK ARMASIGHT by FLIR U S E R M A N U A L...
- Page 18 To mount an IR illuminator to the Spark, use the optional Dovetail to Weaver Transfer Piece. Perform the following steps (refer to Figure 3-5): FIGURE 3-5. MOUNTING AN IR ILLUMINATOR TO THE SPARK SPARK ARMASIGHT by FLIR U S E R M A N U A L...
- Page 19 2. Loosen the nut (G), and turn the adapter around between the two fixing devices. Retighten the nut (G). 3. Mount the adapter to the other Spark rail located on the opposite side of the unit. SPARK ARMASIGHT by FLIR U S E R M A N U A L...
-
Page 20: Universal Camera Adapter Application
(E and F). 6. To focus the image, loosen the screw (G) and adjust the distance between the monocular and the camera’s eyepiece. Tighten the screw (G). SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 21: Controls
(Figure 3-9, D) A RED glow indicates that the IR illuminator is operating. CAUTION: DO NOT over-adjust the controls by forcing them past their stopping points. SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 22: Operating Procedures
However, the light can be detected by other NVDs. NOTE: The IR illuminator is designed to provide additional illumination (when needed) while viewing scenes or targets from a short distance (up to 3m). SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 23: Storage
2. Secure the cap over the objective lens. 3. Remove the battery. 4. Place the Spark and accessories in the appropriate locations in the case, and close the cover. SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 24: Preventive Maintenance And Troubleshooting
Lens Cap Inspect for cracked, torn, or missing lens caps. Cap is torn or cut. Cup is not secured to the housing of the lens. SPARK ARMASIGHT by FLIR U S E R M A N U A L... - Page 25 Turn the unit OFF. Verify that the green glow fades from the eyepieces. Remove the battery. Return the unit and all accessories to the soft carrying case. SPARK ARMASIGHT by FLIR U S E R M A N U A L...
-
Page 26: Troubleshooting
Operational defects relate to the reliability of the intensifier, and are an indication of instability. If identified, the user will need to return the Spark immediately. Operational defects include shading, edge glow, flashing, flickering, and intermittent operation. SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 27: Cosmetic Blemishes
(e.g., 5:00 toward the outside, 2:30 near the center, or 1:00 midway). SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 28: Maintenance
CAUTION: The Spark is a precision electron-optical instrument, and must be handled carefully at all times to prevent damage to the device’s body or mechanisms. SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 29: Cleaning Procedures
Clean optional lenses as detailed in items 4 and 5 above (except for the demist shield). 4.4.3 BATTERY REMOVAL AND REPLACEMENT Refer to Part 3.1.1 for battery installation procedures. No special tools are required to replace the battery. V12-20171127 SPARK ARMASIGHT by FLIR U S E R M A N U A L... -
Page 30: Appendix
Lens Cap ASSPKLC Objective Lens Assembly ASSPKOLA Eyepiece Assembly ASSPKEPA Eyecup ASSPKECA Function Switch ASSPKFS Rail ASSPKPR Operation and Maintenance Manual ASSPKOMM Soft Carry Case ASSPKSCC SPARK ARMASIGHT by FLIR U S E R M A N U A L... - Page 31 SPARK ARMASIGHT by FLIR U S E R M A N U A L...
- Page 32 Equipment described herein is subject to US export regulations and may require a license prior to export. Diversion contrary to US law is prohibited. Imagery for illustration purposes only. Specifications are subject to change without notice. ©2018 FLIR Systems, Inc. All rights reserved. 05/07/2018...
