SECTION 4. USER MENU

4.1 USER MENU

To access the user menu press the power button while the
camera is operational. The user menu screen will be displayed
User Menu
The following items are available in the user menu:
• Battery: Turns the battery meter on/off in the display.
• Date/Time: Turns the date/time on/off in the display.
• 24 Hour: Changes the time display between 12 hour (AM/PM)
and 24 hour mode.
• Buttons: Enables/disables on-screen button display for navigation.
• User-selectable auto power off. The options are 5 min (default),
10 min, 20 min, or never.
• Set Clock: Used to set the date and time.
• About: Displays the camera's software version and serial number.
• Gallery: Accesses the camera's snapshot and video browser.
While in the user menu the buttons have the
following functionality:
BUTTON
Exits the user menu
Moves up through the
menu by one increment
Selects Current Item
through the menu
P
by one increment
info@FLIR-Direct.ca
SHORT PRESS LONG PRESS
Turns Power OFF
Quickly moves up
through the menu
N/A
Moves down
Quickly moves down
through the menu
FLIR-DIRECT
U S E R M A N U A L #
4.1.1 BATTERY INDICATOR
This selection is used to toggle the battery indicator on/off
in the display.
Battery Indicator icon on/off
4.1.2 DATE/TIME
This selection is used to toggle the date and time on/off
in the display.
Date & Time Stamp On/Off
4.1.3 TWENTY-FOUR HOUR
When the date/time stamp is enabled in the display, this
option toggles the time display between 12 hour (AM/PM)
and 24 hour mode.
24-Hour Clock Enabled
