FLIR SCOUT TK User Manual page 11

4.1.4 BUTTONS
The user can enable/disable the reference button actions from
the display. The button functions shown on the screen match
the actions generated by pressing the camera's buttons.
On-Screen button functionality
4.1.5 AUTO POWER OFF (APO)
The user can set the amount of time that the camera can be active
without any user interaction prior to shutting off. The options are 5
minutes (Default), 10 minutes, 20 minutes, and never.
Set length of time for auto shutoff
4.1.6 SET THE CLOCK
Pressing the snapshot button with the Clock option highlighted
will bring up the set clock dialogue box.
info@FLIR-Direct.ca
Buttons
FLIR-DIRECT
U S E R M A N U A L #
4.1.6 SET THE CLOCK continued
The button actions listed below can be used to set the
date and time:
BUTTON
P
4.1.7 ABOUT
Pressing the snapshot button with the About option highlighted
will bring up the About dialogue box. This displays the software
loaded into the camera as well as the serial numbers of the
camera and sensor. Press any button to exit.
Access information about your specific camera
The only software that has the ability to be updated by the
end user is the "Camera" software. See Software Update
section for details. The about dialogue box provides the
following information.
ITEM
Camera: VX.XX.X
Sensor: VX.X.XX
Battery: VX.XX.X
Loader: VX.XX.X
Camera SN: XXXXXX
Sensor SN: XXXXXX
SOC: MA21XX
4204190 - Rev 1
SHORT PRESS
Exits the set clock
Turns Power OFF
dialog box
Increases the value of Quickly increases the
the highlighted item
by one increment
Moves to the next item
Decreases the value of Quickly decreases the
the highlighted item
by one increment
DESCRIPTION
Current version of camera's software
Current version of Lepton core software
Current version of battery management software
Current version of system bootloader
Scout TK's serial number
Lepton core's serial number
Processor Type
.ca
1.800.561.8187
LONG PRESS
value of the
highlighted item
N/A
value of the
highlighted item
11
