Summary of Contents for FLIR Scout Pro
- Page 1 User´s manual FLIR Scout Pro...
- Page 2 9.2.2 Infrared lens..............12 Updating the camera................ 13 10.1 Update via USB cable with the FLIR Camera Updater ..... 13 10.1.1 Install the FLIR Camera Updater........13 10.1.2 Connect the camera ............. 13 10.1.3 Update notifications ............13 Disposal of electronic waste ............. 14 Disclaimers ..................
- Page 3 Table of contents 12.4 Quality assurance ..............15 12.5 Third-party licenses..............15 12.6 Usage statistics ..............15 12.7 Copyright ................15 #T810643; r. AB/101018/101018; en-US...
- Page 4 If you do not obey these Cautions, damage to the equipment can occur. Protect the camera and accessories from dirt, dust, impacts, and liquids. Only use the accessories and spare parts that FLIR provides. Do not disassemble the camera. Do not use a damaged camera, or accessories.
- Page 5 Do not store a battery/camera longer than 1 month in a discharged state. Do not store a battery/camera for more than 1 year without recharge. 1.4 Declaration of conformity The full text of the Declaration of conformity is available at the following internet address: https://support.flir.com/resources/dnan. #T810643; r. AB/101018/101018; en-US...
- Page 6 To register the camera, go to http://support.flir.com/camreg. To access the registration form, you must log in to your FLIR account or register for a new account. You also need the serial number of your camera. The serial number is dis- played on the camera body.
- Page 7 4. The FLIR Scout Pro camera is ready to use. Note To get the most out of your camera, we strongly recommend to download the app for the FLIR Scout Pro camera. See section 8.1 Connect the camera to the app. #T810643; r. AB/101018/101018; en-US...
- Page 8 Camera parts 1. Option 2. Left/Right 3. Trigger 4. Power 5. Diopter 6. USB-C port 1. Connectivity switch 2. Tripod mount 3. Serial number #T810643; r. AB/101018/101018; en-US...
- Page 9 Camera user interface 5.1 Main toolbar 1. Zoom 2. Brightness 3. Palettes 5.1.1 Menu system • Zoom: ◦ Press the Option button to display the menu. Zoom is selected by default as the first option. ◦ Adjust the zoom level with the Left/Right button. •...
- Page 10 Camera user interface 5.3 Status icons and indicators Charging Battery state GPS on GPS off Menu: Zoom Menu: Brightness Menu: Palettes Option symbol Memory full Trigger symbol USB connection Connectivity on Connectivity off Showing passkey Phone connected #T810643; r. AB/101018/101018; en-US...
- Page 11 6.2.1 Power on To power on the FLIR Scout Pro camera, press the Power button for 1 second. 6.2.2 Power off To power off the FLIR Scout Pro camera, press and hold the Power button until the screen turns off. 6.2.3 Inactivity After 30 minutes of inactivity the camera goes into sleep mode.
- Page 12 Basic operation 6.5 File transfer To transfer the files via a USB cable, do the following: 1. Connect the camera with a computer, using a USB cable. 2. Power on the camera. 3. Transfer the files to the computer using a drag-and-drop operation. To transfer files from the camera with the app, see section 8.2 Transfer the files via the app.
- Page 13 Palettes The camera supports the following palettes: • White Hot: White Hot displays warmer objects in white and cooler objects in black. Grayscale palettes offer simplicity for scenes with a wide temperature span and gen- erate images with realistic details. The versatility of White Hot makes it appealing for use in shifting landscapes and urban areas.
- Page 14 4. Place the camera close to the mobile device. 5. Start the FLIR Scout Pro app on the mobile device. 6. The FLIR Scout Pro app guides you how to connect the camera with the mobile device. 8.2 Transfer the files via the app 1.
- Page 15 Maintenance and cleaning 9.1 Calibration We recommend that you send in the camera for calibration once a year. Contact your lo- cal sales office for instructions on where to send the camera. 9.2 Clean the camera 9.2.1 Camera housing, cables, and other items Use one of these liquids: •...
- Page 16 Camera Updater The FLIR Camera Updater is a Windows application used to update the camera. To update your camera, you must log in to your FLIR account or sign up for a new ac- count. You must also register the camera.
- Page 17 Disposal of electronic waste Waste of Electrical and Electronic Equipment (WEEE) poses a risk to human health and the environment when not disposed of properly. This product should not be discarded as unsorted waste but must be sent to separate collection facilities for recovery and recy- cling.
- Page 18 12.7 Copyright © 2024 FLIR Systems, Inc. All rights reserved worldwide. No parts of the software in- cluding source code may be reproduced, transmitted, transcribed or translated into any language or computer language in any form or by any means, electronic, magnetic, opti- cal, manual or otherwise, without the prior written permission of FLIR Systems.
- Page 19 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T810643...
