Led Explanation - TP-Link Archer VR600v User Manual

Chapter 1
Name
Power
DSL
Internet
WLAN 2.4GHz
WLAN 5GHz
LAN
USB
Phone
Note:
1. If the DSL LED is off, please check your internet connection first. Refer to
about how to make internet connection correctly. If you have already made a right connection, please contact your ISP to make
sure your internet service is available now.
2. If the Internet LED is off, please check your DSL LED first. If your DSL LED is also off, please refer to
ON, please check your internet configuration. You may need to check this part of information with your ISP and make sure
everything have been input correctly.

LED Explanation

Status
On System initialization is complete.
The system is initializing or the firmware is being
Flashing upgraded. Do not disconnect or power off the modem
router.
Power is off. Please ensure that the power adapter is
Off
connected correctly.
On DSL synchronization is complete.
Flashing DSL synchronization is in progress.
DSL synchronization failed. Please refer to
Off
troubleshooting.
The network is available with a successful internet
On
connection.
There is no successful internet connection or the
Off modem router is operating in Bridge mode. Please refer
to Note 2
On The wireless 2.4GHz/5GHz band is working properly.
Flashing WPS connection is in progress (about 2 minutes).
Off The wireless 2.4GHz/5GHz band is disabled.
On At least one LAN port is connected.
Off No LAN port is connected.
On The USB device is ready to use.
Flashing The USB device is being identified.
Off No USB device is plugged into the USB port.
On The phone is off-hook or DECT handset is busy.
Flashing The phone is ringing or DECT handset is registering.
Off The phone is on-hook.
Get to Know Your Modem Router
Indication
for troubleshooting.
Connect Your Modem Router
Note 1 for
for more information
Note 1. If your DSL LED is
