Icom IC-F2610 Service Manual page 4

SECTION 1
Mesurement method
Frequency coverage
Number of channels
Type of emission
Operating temperature range
Power supply voltage
TX max. power
Current drain
max. audio
(approx.)
RX
stand-by
Antenna connector
Dimensions (proj. not included)
Weight
Output power
Modulation system
Max. freqequency deviation
Frequency error
Spurious emissions
Adjacent channel power
Audio frequency response
Audio harmonic distortion
Residual modulation
(with CCITT filter)
Limitting
Microphone connector
Intermediate frequency
Sensitivity
Squelch sencitivity
Adjcent channel selectivity
Spurious response
Intermoduration
Audio frequency response
Hum and noise
(with CCITT filter)
Audio output power
External SP connector
All stated specifications are subject to change without notice or obligation.
SPECIFICATIONS
ETS 300 086
440–490 MHz
×
128 (16 ch 8 banks)
16K0F3E (25 kHz; Wide)
8K50F3E (12.5 kHz; Narrow)
–20˚C to +55˚C
13.2 V DC (negative ground)
8.0 A
1.2 A
700 mA
SO-239 (50 Ω)
× ×
150(W) 50(H) 180(D) mm
1.5 kg
25 W
Variable reactance frequency modulation
±5.0 kHz (Wide)
±2.5 kHz (Narrow)
±1.5 kHz
0.25 µW
70 dB (Wide)
60 dB (Narrow)
+2 dB to –5 dB of 6 dB/octave
range from 300 Hz to 3000 Hz (Wide)/2550 Hz (Narrow)
5 % (40 % Dev.)
45 dB minimum: 55 dB typical (Wide)
40 dB minimum: 50 dB typical (Narrow)
70–100 % of modulation
8-pin modular (600 Ω)
1st: 30.875 MHz
2nd: 455 kHz
–2 dBµV emf (at 20 dB SINAD)
–4 dBµV emf (Threshold)
70 dB (Wide)
60 dB (Narrow)
70 dB
70 dB typical
+2 dB to –5 dB of 6 dB/octave
range from 300 Hz to 3000 Hz (Wide)/2550 Hz (Narrow)
45 dB minimum: 55 dB typical (Wide)
40 dB minimum: 50 dB typical (Narrow)
3.5 W at 10% distortion with a 4 Ω load
2-conductor 3.5 (d) mm (
1 - 1
")/4 Ω
1
⁄
8
