3. Assembly Instruction

In this part, we will talk about the parts of M1 and how to install M1.

3.1 Double check the spare parts inside the package

Please check the package of M1 and make sure that all parts are complete. The spare parts of M1are listed as follows, if any of
them is missing, please contact the local agent or us directly.
1 Main body
2 Handlebar grip
3 Handlebar stem
4 Short handlebar
5 Charger
6 Main body of short handlebar(Optional)
7 Screw cap(Optional)
3.2 Assembling M1
Step 1: put the handlebar stem into the adapter at main body and tighten it up with screws as follows.
Step 2: put the handlebar grip into the adapter of the handlebar stem and tighten it up with 4 M5 screws as follows.
Step 3: press the power-open button behind the main body of M1 to turn it on.
8 Screw bag ( 3 hex screws )(Optional)
9 Front bag
10 Tool and screws bag (which contains of erecting tools and 10 screws)
11 Two remote keys
12 M1 Product Manual, tutorial video and warranty
13 Certification of quality
