S7106

Version 1.0
Copyright
Copyright © 2017 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
®
TYAN
is a trademark of MiTAC International Corporation.
®
®
Intel
is a trademark of Intel
Corporation.
AMI, AMI BIOS are trademarks of AMI Technologies.
®
®
Microsoft
, Windows
are trademarks of Microsoft Corporation.
®
Winbond
is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
®
warranty, relating to sale and/or use of TYAN
products including liability or
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.
1
http://www.tyan.com

Advertisement

Table of Contents
loading

Related Manuals for TYAN S7106

Summary of Contents for TYAN S7106

  • Page 1: S7106

    Corporation and has been reviewed for accuracy and reliability prior to printing. MiTAC assumes no liability whatsoever, and disclaims any express or implied ® warranty, relating to sale and/or use of TYAN products including liability or warranties relating to fitness for a particular purpose or merchantability. MiTAC retains the right to make changes to product descriptions and/or specifications at any time, without notice.

  • Page 2: Table Of Contents

    Contents S7106 ....................... 1 Before you begin… ................3 Chapter 1: Instruction ................4 1.1 Congratulations ................4 1.2 Hardware Specifications..............4 1.3 Software Specifications ..............9 Chapter 2: Board Installation ............... 10 2.1 Board Image ................11 2.2 Block Diagram ................13 2.3 Motherboard Mechanical Drawing ..........

  • Page 3: Before You Begin

    S7106 Motherboard x 1 SATA Single Cable x 2 Rear IO shielding x 3 CPU clip for Narrow Non-Fabric CPU Carrier x 2 1 x S7106 Quick Installation Guide ® 1 x TYAN Driver CD M.2 Screw kit x1 IMPORTANT NOTE: Sales samples may not come with any of the accessories listed above.

  • Page 4: Chapter 1: Instruction

    3DS* DDR4 memory. Leveraging advanced technology ® from Intel , the S7106 is capable of offering scalable 32 and 64-bit computing, high- bandwidth memory design, and lightning-fast PCI-E bus implementation. The S7106 not only empowers you in today‟s demanding IT environment but also offers a smooth path for future application upgradeability.

  • Page 5: Expansion Slots

    (2) ports (1 at rear, 1 via cable) (2) D-Sub ports (1 at rear, 1 via Input /Output cable) (2) GbE ports, (1) Dedicated for RJ-45 IPMI Front Panel (1) 2x12-pin SSI front panel header SATA (2) SATA-III connectors + (3) Mini- http://www.tyan.com...
  • Page 6 CE (DoC) Operating Temp. 10° C ~ 35° C (50° F~ 95° F) Non-operating - 40° C ~ 70° C (-40° F ~ 158° F) Operating Environment Temp. In/Non-operating 90%, non-condensing at 35° C Humidity RoHS RoHS 6/6 Compliant http://www.tyan.com...

  • Page 7: Sata Controller

    Please refer to our Intel OS Operating System OS supported list supported list. Motherboard (1) S7106 Motherboard (1) Web User's manual, (1) Quick Package Contains Manual Installation Guide Installation CD (1) TYAN installation CD S7106GM2NR-L2 Specifications Socket Type / Q'ty...
  • Page 8 Please refer to our TPM supported TPM (Optional) TPM Support list. Chipset Aspeed AST2500 Total (5) 4-pin headers System Monitoring Monitors temperature for CPU & Temperature memory & system environment Monitors voltage for CPU, memory, Voltage chipset & power supply http://www.tyan.com...

  • Page 9: Software Specifications

    (1) Web User's manual, (1) Quick Package Contains Manual Installation Guide Installation CD (1) TYAN installation CD 1.3 Software Specifications For the latest AST2500 User‟s Guide and OS (operation system) support, please visit the Tyan‟s Web site at http://www.tyan.com for the latest information http://www.tyan.com...

  • Page 10: Chapter 2: Board Installation

    Caution! To avoid damaging the motherboard and associated components, do not use torque force greater than 7kgf/cm (6.09 lb/in) on each mounting screw for motherboard installation. Do not apply power to the board if it has been damaged. http://www.tyan.com...

  • Page 11: Board Image

    2.1 Board Image S7106GM2NR http://www.tyan.com...
  • Page 12 S7106GM2NR-L2 This picture is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the above picture. http://www.tyan.com...

  • Page 13: Block Diagram

    2.2 Block Diagram S7106 Block Diagram http://www.tyan.com...

  • Page 14: Motherboard Mechanical Drawing

    2.3 Motherboard Mechanical Drawing http://www.tyan.com...

  • Page 15: Board Parts, Jumpers And Connectors

    The board you receive may not look exactly like the above diagram. The DIMM slot numbers shown above can be used as a reference when reviewing the DIMM population guidelines shown later in the manual. For the latest board revision, please visit our web site at http://www.tyan.com. http://www.tyan.com...

  • Page 16: Motherboard Components

    29. SSI 8-pin CPU1 Power Connector (PW2) 11. Rear ID LED (ID_LED1) 30. SSI 8-pin CPU0 Power Connector (PW1) 31. CPU0 PVCCP POWER OK LED 12. TYAN Module Header (DBG_HD1) (P0_PG_LED1) 13. Front Panel USB3.0 Header (USB3_FPIO1) 32. SYS_FAN 1 Header (SYS_FAN_1) 14.
  • Page 17 CPU0 Memory Slot (P0_MC0_DIM_CH_A0) CPU1 Memory Slot (P1_MC0_DIM_CH_A0) CPU0 Memory Slot (P0_MC1_DIM_CH_D0) CPU1 Memory Slot (P1_MC1_DIM_CH_D0) CPU0 Memory Slot (P0_MC1_DIM_CH_E1) CPU1 Memory Slot (P1_MC1_DIM_CH_E1) CPU0 Memory Slot (P0_MC1_DIM_CH_E0) CPU1 Memory Slot (P1_MC1_DIM_CH_E0) CPU0 Memory Slot (P0_MC1_DIM_CH_F0) CPU1 Memory Slot (P1_MC1_DIM_CH_F0) http://www.tyan.com...
  • Page 18 Connects to the Serial ATA ready drives via the Serial ATA cable. TYPEA_USB3: Vertical (Type_A) USB3.0 Connector Signal Signal USB2.0_DATA_N USB2.0_DATA_P USB3.0_RX_N USB3.0_RX_P USB3.0_TX_N USB3.0_TX_P ID LED_BTN1: Rear IO IDLED Button Signal Signal FP_IDLED_BTN_N FPIO_VGA3: VGA Header Signal Signal VGA2_5V HD_VGA_R HD_VGA_G HD_VGA_B HD_VGA_DAT VGA_HD_HS VGA_HD_CLK HD_VGA_VS http://www.tyan.com...
  • Page 19 DBG_HD1: TYAN Module Header Signal Signal P3V3 FRAME_N LAD0 LAD1 PLT_RST_N LAD2 LAD3 CLK_33M DBG_SERIRQ DBG_PRES_N VCC3_AUX TPM_ADDR_MB PCH_TPM_PP_EN USB3_FPIO1: Front USB3.0 Header Signal Signal P0_RX_N P0_RX_P P0_TX_N P0_TX_P P0_N P0_P OC_N P1_P P1_N P1_TX_P P1_TX_N P1_RX_P P1_RX_N J26: Internal USB2.0 Header...
  • Page 20 J51: PCH_SATA_RAID_KEY (HW Key for Intel VROC – NVMe only) Signal LAN1_LED1_FP+ LAN1_LINK_ACT# FPIO1: Front Panel Connector Signal Signal FP_PW_LED_PW FP_PWER (VCC3_Aux) FP_ID_LED_PW FP_PW_LED_GND FP_ID_LED_N HDD_LED_PW BMC_HW_FAULT_N HDD_ACT_LED_N BMC_SYS_FAULT_N FP_PWR_BTN_N LAN0_LED_P LAN0_LED_N FP_RST_BTN_JP_N FP_SMB_DAT FP_SMB_CLK FP_IDLED_BTN_N FP_INTRUSION_N SYS_Air_Inlet LAN1_LED_P FP_NMI_BTN_N LAN1_LED_N http://www.tyan.com...
  • Page 21 Note: A 4-pin fan is required for fan support 4pin Control Clear_BTN1: RTC reset Button for clear CMOS Signal RST_N RST_N PWR_BTN1: POWER Button Signal PWR_BTN1 PWR_BTN1 RST_BTN1: Reset Button Signal FP_RST_BTN_N FP_RST_BTN_N http://www.tyan.com...
  • Page 22 2-3: BMC COMSOLE Port5 J119: BMC COM Port debug Jumper Signal Signal BMC_COM2_TXD TXD_2 BMC_COM5_TXD 1-2: BMC COM Port2(Default) 2-3: BMC COMSOLE Port5 J125: PSU Throttling Jumper Signal Signal PSU_SMB_ALERT_BUFF_N_R VCC3_Aux 1-2: Normal Mode(Default) 2-3: Enable PSU Throttling Function http://www.tyan.com...
  • Page 23 PIN C4 SATA6G_TX_P1 PIN C5 PIN C6 SATA6G_TX_N1 PIN C7 PIN C8 SATA6G_TX_P3 SATA6G_TX_N3 PIN C9 PIN D1 PIN D2 PIN D3 SM_CLK PIN D4 PIN D5 SATA6G_TX_P0 SATA6G_TX_N0 PIN D6 PIN D7 SATA6G_TX_P2 PIN D8 PIN D9 SATA6G_TX_N2 http://www.tyan.com...

  • Page 24: Led Definitions

    The LED lights up when the Green power of CPU1 is normally. Signal + VCC3_AUX Rear ID ID_LED1 State Description Green Signal + VCC3_AUX HW Sensor IPMI_LED1 Alert LED State Description HW Sensor status is normal HW Sensor status is abnormal. http://www.tyan.com...

  • Page 25: Installing The Processor And Heatsink

    2.6 Installing the Processor and Heatsink The types of processors supported by the S7106 are listed in the 1.2 Hardware Specifications section on page 4. Check our website at http://www.tyan.com ® the latest list of validated Intel processors for this specific motherboard.
  • Page 26 Then place the heatsink onto the top of the CPU socket. Align the heatsink by the guide pins and make sure the gold arrow is located in the correct direction. Then place the heatsink onto the top of the processor. http://www.tyan.com...
  • Page 27 To secure the heatsink, use a Security T30 Security Torx to tighten the screws in a sequential order (1->2->3->4). When dissembling the heatsink, loosen the screws in reverse order (4->3->2->1). http://www.tyan.com...

  • Page 28: Tips On Installing Motherboard In Chassis

    Be especially careful to look for extra stand-offs. If there are any stand-offs present that are not aligned with a mounting hole on the motherboard, it will likely short components on the back of the motherboard when installed. This will cause malfunction and/or damage to your motherboard. http://www.tyan.com...
  • Page 29 Some chassis include plastic studs instead of metal. Although the plastic studs are usable, MiTAC recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed. http://www.tyan.com...

  • Page 30: Installing The Memory

    2.8 Installing the Memory Before installing memory, ensure that the memory you have is compatible with the motherboard and processor. Check the TYAN Web site at http://www.tyan.com details of the type of memory recommended for your motherboard.  Support (16)DDR4 288-pin DIMM slots, ...
  • Page 31 4. Dual-rank DIMMs are recommended over single-rank DIMMs. 5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if populating only a single DIMM per channel. 6. Always install with CPU0 Socket and DIMM_0 Slot first, following the alphabetical order. http://www.tyan.com...
  • Page 32 4. Dual-rank DIMMs are recommended over single-rank DIMMs. 5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if populating only a single DIMM per channel. 6. Always install with CPU0 Socket and DIMM_0 Slot first, following the alphabetical order. http://www.tyan.com...
  • Page 33 Intel Xeon Skylake Scalable Processors Families Support NOTE 1: 1DPC => One dimm per channel NOTE 2: 2DPC => Two dimm per channel  Physical Ranks are used to calculate DIMM Capacity.  Supported DRAM Densities are 4Gb, 8Gb. http://www.tyan.com...

  • Page 34: Memory Installation Procedure

    Memory Installation Procedure Follow these instructions to install memory modules into the S7106. Unlock a DIMM socket by Press the retaining clip outwardly in the following illustration. Align the memory module with the socket，such that the DIMM NOTCH match the KEY SLOT on the socket.

  • Page 35: Attaching Drive Cables

    The following illustrates how to make a SATA Cable connection. If you are in need of SATA/SAS cables or power adapters please contact your local sales representative. 1. SATA drive cable connection 2. SATA drive power connection 3. SATA cable motherboard connector 4. SATA drive power adapter http://www.tyan.com...

  • Page 36: Installing Add-In Cards

    Doing so allows air to circulate within the chassis more easily, thus improving cooling for all installed devices. NOTE: You must always unplug the power connector from the motherboard before performing system hardware changes to avoid damaging the board or expansion device. http://www.tyan.com...

  • Page 37: Connecting External Devices

    1Gbps LAN Link/Activity LED Scheme Left LED Right LED Description (Link/Activity) (Speed) No Link Link Green 10 Mbps Active Blinking Green Link Green Solid Green 100 Mbps Active Blinking Green Solid Green Link Green Solid Amber 1Gbps Active Blinking Green Solid Amber http://www.tyan.com...

  • Page 38: Installing The Power Supply

    2.12 Installing the Power Supply There are Three (3) power connectors on your S7106 motherboard. The S7106 supports EPS 12V power supply. PWR1: ATX 24-Pin Power Connector Signal Signal +3.3V_1 +3.3V_4 +3.3V_2 -12V COM_1 COM_4 +5V_1 PS-ON# COM_2 COM_5 +5V_2...

  • Page 39: Chapter 3: Bios Setup

    Exit current menu <F1> General help <F2> Previous values <F3> Load the Optimal default configuration values of the menu <F4> Save and exit <K> Scroll help area upwards <M> Scroll help area downwards <PgUp> / <PgDn> Move cursor to next/previous page http://www.tyan.com...
  • Page 40 BIOS menus are continually changing due to continual BIOS updates over the product lifespan of the motherboard. The BIOS menus provided are current as of the date when this manual was written. Please visit TYAN‟s website at http://www.tyan.com for information on BIOS updates available for this specific motherboard.

  • Page 41: Main Menu

    BIOS Information It displays BIOS related information. Platform Information It displays Platform information. Memory Information This displays the total memory size. System Language Choose the system default language System Date Adjust the system date. MM (Months): DD (Days): YYYY (Years) http://www.tyan.com...
  • Page 42 System Time Adjust the system clock. HH (24 hours format): MM (Minutes): SS (Seconds) http://www.tyan.com...

  • Page 43: Advanced Menu

    Intel® Virtual RAID on CPU This formset allows the user to manage Intel® Virtual RAID on CPU Trusted Computing Trusted Computing settings. ACPI Settings System ACPI Parameters. Onboard Device Configuration Onboard Device and Function Configuration. Hardware Health Configuration Hardware Health Configuration http://www.tyan.com...
  • Page 44 Serial Port Console Redirection Option ROM Dispatch Policy Option ROM Dispatch Policy PCI Subsystem Settings PCI, PCI-X and PCI Express Settings Network Stack Configuration Network Stack Settings CSM Configuration CSM Configuration, Enable/Disable Option ROM execution setting, etc USB Configuration USB Configuration Parameters. http://www.tyan.com...
  • Page 45 3.3.1 iSCSI Configuration iSCSI Name The worldwide unique name of iSCSI Initiator. Only IQN format is accepted. Range is from 4 to 223. http://www.tyan.com...
  • Page 46 3.3.2 Intel(R) Virtual RAID on CPU http://www.tyan.com...
  • Page 47 3.3.3 Trusted Computing Security Device Support Enable or disable BIOS support for security device. O.S. will not show Security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Enabled / Disabled http://www.tyan.com...
  • Page 48 3.3.4 ACPI Settings Enable ACPI Auto Configuration Enable or disable BIOS ACPI Auto Configuration. Disabled / Enabled Enable Hibernation Enables or disables System ability to Hibernate (OS/S4 Sleep State). This option may not be effective with some OS. Disabled / Enabled http://www.tyan.com...
  • Page 49 Onboard Lan I210 Enable/Disable Onboard Lan I210 Disabled / Enabled Chassis Intrusion detect Enabled: When a chassis open event is detected, the BIOS will record the event. Disabled / Enabled NMI Button Enable or disable NMI button. Disabled / Enabled http://www.tyan.com...
  • Page 50 PWM Minimal Duty Cycle Duty Cycle control range 15% Duty Cycle / 30% Duty Cycle / 45% Duty Cycle BMC Alert Beep Enable/Disable BMC Alert Beep. On / Off PMBus support PMBus Support Disabled / Enabled http://www.tyan.com...
  • Page 51 3.3.5.1 Sensor Data Register Monitoring When you enter the Sensor Data Register Monitoring submenu, you will see the following dialog window pop out. Please wait 8~10 seconds. NOTE 1: SDR can not be modified. Read only. http://www.tyan.com...
  • Page 52 http://www.tyan.com...
  • Page 53 http://www.tyan.com...
  • Page 54 3.3.7 PCIe Slot Configuration Internal OCP Slot Select OCP Slot Bifurcation X16 / x8x8 / x4x4x4x4 OCP I/O Slot Select OCP Bifurcation Load Optrom for PCIE Slot X16 / x8x8 / x4x4x4x4 http://www.tyan.com...
  • Page 55 3.3.8 AST2500 Super IO Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA) Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMA) http://www.tyan.com...
  • Page 56 / IO=3F8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=3E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; / IO=2E8h, IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; http://www.tyan.com...
  • Page 57 Wake system from S5 Enable or disable system wake on alarm event. Select Fixed time, system will wake on the hr::min::sec specified. Select dynamic time, system will wake on the current time+ increase minute(s) Disabled / Fixed time / Dynamic time http://www.tyan.com...
  • Page 58 Console Redirection Settings The settings specify how the host computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. NOTE: Console Redirection Settings menu only appear when Console Redirection was set to [Enabled]. http://www.tyan.com...
  • Page 59 1‟s in the data bits is odd. Mark: parity bit is always 1. Space: parity bit is always 0. Mark and Space parity do not allow for error detection. None / Even / Odd / Mark / Space http://www.tyan.com...
  • Page 60 VT100 / LINUX / XTERMR6 / SCO / ESCN / VT400 Redirection After BIOS POST The settings specify if BootLoader is selected than Legacy console redirection is disabled before booting to Legacy OS. Default value is always enable means Legacy. Always Enable / Bootloader http://www.tyan.com...
  • Page 61 3.3.10.2 Legacy Console Redirection Settings Legacy Serial Redirected Port Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages COM1 http://www.tyan.com...
  • Page 62 VT-UTF8 / VT100 / VT100+ / ANSI Bits per Second Select serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. 115200 / 9600 / 19200 / 38400 / 57600 http://www.tyan.com...
  • Page 63 „stop‟ signal can be sent to stop the data flow. Once the buffers are empty, a „start‟ signal can be sent to restart the flow. Hardware flow control uses two wires to send start/stop signal. None / Hardware RTS/CTS Data Bits / Parity / Stop Bits Read only. http://www.tyan.com...
  • Page 64 3.3.11 Option ROM Dispatch Subsystem OnBoard sSATA Controller Onboard Device has: UEFI Legacy Embedded ROM(s). VIDx8086:DIOxA1D2 @ s0(Bx0) Dx11/ Fx5 Disabled / Enabled OnBoard SATA Controller Onboard Device has: UEFI Legacy Embedded ROM(s). VIDx8086:DIOxA182 @ s0(Bx0) Dx17/ Fx0 Disabled / Enabled http://www.tyan.com...
  • Page 65 Enable or Disable Option ROM execution for selected Slot. Disabled / Enabled Riser-R Down Empty Enable or Disable Option ROM execution for selected Slot. Disabled / Enabled Riser-R Middle Empty Enable or Disable Option ROM execution for selected Slot. Disabled / Enabled http://www.tyan.com...
  • Page 66 Enables or Disables 64bit capable Devices to be decoded in Above 4G Address Space(Only if System supports 64 bit PCI decoding). Enabled / Disabled SR-IOV Support If system has SR-IOV capable PCIe devices, this option Enable or Disable Single root IO virtualization Support Enabled / Disabled http://www.tyan.com...
  • Page 67 3.3.13 Network Stack Configuration Network Stack Enable / Disable UEFI Network Stack. Disabled / Enabled http://www.tyan.com...
  • Page 68 Do not launch / UEFI / legacy / Video Controls the execution of UEFI and legacy PXE OpROM Do not launch / UEFI / legacy Other PCI devices Determines OpRom execution policy for devices other than network, storage, or video legacy / UEFI http://www.tyan.com...
  • Page 69 USB Mass Storage Driver Support Enable/Disable USB Mass Storage Driver Support. Disabled / Enabled Port 60/64 Emulation Enable I/O port 60h/64h emulation support. This should be enabled for the complete USB keyboard legacy support for non-USB aware OSes. Disabled / Enabled http://www.tyan.com...
  • Page 70 Maximum time the device will take before it properly reports itself to the Host Controller. AUTO uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. Auto / Manual http://www.tyan.com...

  • Page 71: Platform Configuration Menu

    3.4 Platform Configuration Menu PCH Configuration Displays and provides option to change the PCH Settings. Miscellaneous Configuration Miscellaneous Configuration Server ME Configuration Configure Server ME technology Parameters http://www.tyan.com...
  • Page 72 Enable/Disable Intel(R) IO Controller Hub devices PCI Express Configuration PCI Express Configuration settings PCH SATA Configuration SATA devices and settings PCH sSATA Configuration sSATA devices and settings USB Configuration USB Configuration Settings PCH DFX Configuration PCH DFX Configuration Options http://www.tyan.com...
  • Page 73 3.4.1.1 PCH Devices Configuration PCH state after G3 Select S0/S5 for ACPI state after a G3 S0 /S5 / Leave power state unchanged http://www.tyan.com...
  • Page 74 3.4.1.2 PCI Express Configuration PCI Express Root Port 1/2/3/4/5/6/7/8/9/10/11/12/13/14/15/16/17/18/19/20 PCI Express Root Port Settings http://www.tyan.com...
  • Page 75 Disabled / L1.1 / L1.2 / L1.1 & L1.2 PCIe Speed PCI Express Root Port Completion Timer TO settings Auto / Gen1 / Gen2 / Gen3 Max Payload Size PCIE Max Payload Size Selection. MPL 128B / MPL 256B http://www.tyan.com...
  • Page 76 3.4.1.3 PCH SATA Configuration Submenu http://www.tyan.com...
  • Page 77 Indentify the SATA port is connected to Solid State Drive or Hard Disk Drive AHCI / RAID SATA Port 0/1/2/3/4/5/6/7 Port 0/1/2/3/4/5/6/7 Disabled / Enabled Hot Plug Enable/Disable SATA Ports Hot Plug Support. Disabled / Enabled Configure as eSATA Configures port as External SATA (eSATA) Disabled / Enabled http://www.tyan.com...
  • Page 78 Spin Up Device AHCI Supports Staggered Spin-up Disabled / Enabled SATA Device Type Indentify the SATA port is connected to Solid State Drive or Hard Disk Drive Hard Disk Drive / Solid State Drive http://www.tyan.com...
  • Page 79 3.4.1.4 PCH sSATA Configuration Submenu http://www.tyan.com...
  • Page 80 Otherwise all drives spin up at boot. Disabled / Enabled sSATA Device Type Indentify the SATA port is connected to Solid State Drive or Hard Disk Drive Hard Disk Drive / Solid State Drive http://www.tyan.com...
  • Page 81 USB Configuration Submenu XHCI Idle L1 Enabled XHCI Idle L1. Disabled to workaround USB3 hot plug will fail after 1 hot plug removal. Please put the system to G3 for the new settings to take effect. Disable / Enabled http://www.tyan.com...
  • Page 82 Enables/Disables ADR on Host Partition Reset Enabled / Disabled Enable/Disable ADR Timer Held-off for DEBUG PURPOSES ONLY! Enabled / Held-off ADR timer expire time Select proper ADR timer value: 25uS,50uS,100uS or 0. 25 uS / 50 uS / 100 uS / 0 uS http://www.tyan.com...
  • Page 83 Select proper ADR timer multiplier: x1,8,24,40,56,64,72,80,88,96. x1 / x8 / x24 / x40 / x56 / x64 / x72 / x80 / x88 /x96 3.4.2 Miscellaneous Configuration Submenu Active Video Select active Video type Auto / Onboard Device / PCIE Device http://www.tyan.com...
  • Page 84 3.4.3 Server ME Configuration Submenu Read Only http://www.tyan.com...

  • Page 85: Socket Configuration

    Displays and provides option to change the UPI Settings Memory Configuration Displays and provides option to change the Memory Settings IIO Configuration Displays and provides option to change the IIO Settings Advance Power Management Configuration Displays and provides option to change the Power Management Settings http://www.tyan.com...
  • Page 86 This should be enabled in order to boot legacy OSes that cannot support CPUs with extended CPUID functions. Disabled / Enable Execute Disable Bit When disabled, forces the XD feature flag to always return 0. Disabled / Enabled Enable Intel(R) TXT Enables Intel(R) TXT Disabled / Enabled http://www.tyan.com...
  • Page 87 MLC Streamer Prefetcher (MSR 1A4h Bit [0]) Disabled / Enabled Adjacent Cache Prefetch MLC Spatial Prefetcher (MSR 1A4h Bit [1]) Disabled / Enabled Extended APIC Enable/disable extended APIC support Disabled / Enabled AES-NI Enable/disable AES-NI support Disabled / Enabled 3.5.2 Common RefCode Configuration Submenu http://www.tyan.com...
  • Page 88 Per stack mmioh resource assignments are multiples of the granularity where 1 unit Per stack is the default allocation. 1G / 4G / 16G / 64G / 256G / 1024G Numa Enable or Disable non uniform Memory Access. (NUMA) Enabled / Disabled http://www.tyan.com...
  • Page 89 3.5.3 UPI Configuration Submenu UPI General Configuration Displays and provides option to change the UPI General Settings http://www.tyan.com...
  • Page 90 Enable – Set the c_L0p_en, Disable – Reset it, Auto – Auto decides based on Si Compatibility Disable/Enable/Auto Link L1 Enable Enable – Set the c_L1_en, Disable – Reset it, Auto – Auto decides based on Si Compatibility Disable/Enable/Auto http://www.tyan.com...
  • Page 91 3.5.3.2 UPI Status Configuration Submenu http://www.tyan.com...
  • Page 92 Enable – Enables DDR ECC Support. Disable – Disables this feature. Auto – Sets it to MRC default setting; current default is Enable. Disabled / Enabled Memory Topology Displays memory topology with Dimm population information Memory RAS Configuration Displays and provides option to change the Memory Ras Settings http://www.tyan.com...
  • Page 93 3.5.4.1 Memory Topology Configuration Submenu http://www.tyan.com...
  • Page 94 Partial mirror mode will enable the required size of memory to be mirrored. If rank sparing is enabled partial mirroring will not take effect. Mirror Enable will disable XPT Prefetch. Disabled / Enabled Memory Rank Sparing Enable/Disable Memory Rank Sparing Disabled / Enabled http://www.tyan.com...
  • Page 95 Enable/Disable Patrol Scrub Disabled / Enabled 3.5.5 IIO Configuration Socket0 Configuration Socket 0 Configuration Socket1 Configuration Socket 1 Configuration Intel® VT for Directed I/O (VT-d) Press <Enter> to bring up the Intel® VT for Directed I/O (VT-d) Configuration menu. http://www.tyan.com...
  • Page 96 PCIe ACPI Hot Plug Enable/Disable PCIe ACPI Hot Plug globally, or allow per-port control. When Disabled, MSI is generated on HP event. When Enabled, _HPGPE message is generated. Disabled / Enabled PCIe Access Control Services Enable/Disable Access Control Service Disabled / Enabled http://www.tyan.com...
  • Page 97 Select PCIe port Bifuncation for selected slot (s) X4x4x4x4 / X4x4x8 / x8x4x4 / x8x8 /x16 / Auto IOU2 (IIO PCIe Br3) Selects PCIe port Bifuncation for selected slot (s) X4x4x4x4 / X4x4x8 / x8x4x4 / x8x8 / x16 / Auto http://www.tyan.com...
  • Page 98 Selects PCIe port Bifurcation for selected slot (s) X4x4x4x4 / X4x4x8 / x8x4x4 / x8x8 / x16 / Auto IOU2 (IIO PCIe Br3) Selects PCIe port Bifuncation for selected slot (s) X4x4x4x4 / X4x4x8 / x8x4x4 / x8x8 /x16 / Auto http://www.tyan.com...
  • Page 99 3.5.5.2 Intel® VT for Directed I/O (VT-d) Submenu Intel® VT for Directed I/O (VT-d) Enable/Disable Intel® Virtualization Technology for Directed I/O (VT-d) by reporting the I/O device assignment to VMM through DMAR ACPI Tables. Disabled / Enabled http://www.tyan.com...
  • Page 100 3.5.5.3 Intel® VMD technology Submenu http://www.tyan.com...
  • Page 101 3.5.5.3.1 Intel® VMD for Volume Management Device on Socket 0/1 Submenu VMD Config for PStack 0/1/2 ® Intel VMD for Volume Management D Enable/Disable Intel® Volume Management Device Technology in this Stack. Disabled / Enabled http://www.tyan.com...
  • Page 102 Advance Power Management Configuration CPU P State Control P State Control Configuration Sub Menu, include Turbo, XE and etc. Hardware PM State Control Hardware P-State setting CPU C State Control CPU C State setting Package C State Control Package C State setting http://www.tyan.com...
  • Page 103 Max Performance / Max Efficient / Set by Intel Node Energy Efficient Turbo Energy Efficient Turbo Disable, MSR 0x1FC [19] Disabled / Enabled Turbo Mode Enable/Disable processor Turbo Mode (requires EMTTM enabled too). Disabled / Enabled CPU Flex Ratio Override Enable/Disable CPU Flex Ratio Programming Disabled / Enabled http://www.tyan.com...
  • Page 104 Disable: Hardware choose a P-state based on OS Request (Legacy P-States) Native Mode: Hardware choose a P-state based on OS guidance Out of Band Mode: Hardware autonomously choose a P-state (No OS guidance) Disable / Native Mode / Out of Band Mode / Native Mode with No Legacy Support http://www.tyan.com...
  • Page 105 Auto / Enable / Disable Enhanced Halt State (C1E) Enables the Enhanced C1E state of the CPU, takes effect after reboot Enabled / Disabled OS ACPI Cx Report CC3/CC6 to OS ACPI C2 or ACPI C3 ACPI C2 / ACPI C3 http://www.tyan.com...
  • Page 106 3.5.6.4 Package C State Control Submenu Package C State Control Package C State Limit C0/C1 state / C2 state / C6(non Retention) state / C6(Retention) state / No Limit / Auto http://www.tyan.com...

  • Page 107: Server Management

    OS Watchdog Timer If enabled, starts a BIOS timer which can only be shut off by management Software after the OS loads. Helps determine that the OS successfully loaded or follows the OS Boot Watchdog Timer policy. Disabled / Enabled http://www.tyan.com...
  • Page 108 Not available if OS Boot Watchdog Timer is disabled. Do Nothing / Reset / Power Down / Power Cycle BMC Logo Enable or Disable BMC logo Disabled / Enabled System Event Log Press<Enter> to change the SEL event log configuration. BMC network configuration Configure BMC network parameters http://www.tyan.com...
  • Page 109 Choose options for reactions to a full SEL. Do Nothing / Erase Immediately Log EFI Status Codes Disable the logging of EFI Status Codes or log only error code or only progress code or both. Both / Disabled / Error Code / Progress Code http://www.tyan.com...
  • Page 110 3.6.2 BMC Network Configuration Submenu http://www.tyan.com...
  • Page 111 BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Unspecified / Static / DynamicBmcDhcp / DynamicBmcNonDhcp Management Port 2 Enable/Disable BMC Share NIC Disabled / Enabled IPV6 Support Enable or Disable LAN1 IPV6 Support Disabled / Enabled http://www.tyan.com...

  • Page 112: Security

    3.7 Security Administrator Password Set Administrator Password. User Password Set User Password. Secure Boot Customizable Secure Boot settings Security Frozen Mode Enable or disable HDD security freeze lock. Disable to support secure erase function. Disabled / Enabled http://www.tyan.com...
  • Page 113 System mode is User/Deployed, and CSM function is disabled Enabled / Disabled Secure Boot Mode Secure Boot mode selector. ‟Custom‟ mode enables users to change Image execution policy and manage secure boot keys. Standard / Custom Key Management Enables experienced users to modify Secure Boot variables http://www.tyan.com...
  • Page 114 Allow the image to run in Secure Boot mode. Enroll SHA256 hash of the binary into Autorized Signature Database (db) Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256,384,512 2. Authenticated UEFI Variable http://www.tyan.com...
  • Page 115 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed, Test Authorized TimeStamps Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) http://www.tyan.com...
  • Page 116 Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER encoded) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHA256,384,512 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed, Test http://www.tyan.com...

  • Page 117: Boot

    Off / On Quiet Boot Enable or disable Quiet Boot option. Disabled / Enabled Endless Boot Enabled or Disabled Endless boot Disabled / Enabled Wait for “ESC” if Error Wait for ESC stop when BIOS has error appeared. Disabled / Enabled http://www.tyan.com...
  • Page 118 Boot Option Priorities Boot Option #1 Sets the system boot order. Device Name / Disabled Delete Boot Option Remove an EFI boot option from the boot order http://www.tyan.com...
  • Page 119 3.8.1 Delete Boot Option Configuration Delete Boot Option Sets the system boot order. Device Name / Select one to Delete http://www.tyan.com...

  • Page 120: Save & Exit

    Reset system setup without saving any changes. Save Changes Save changes done so far to any of the setup options. Discard Changes Discard changes done so far to any of the setup options. Restore Defaults Restore/Load Default values for all the setup options. http://www.tyan.com...
  • Page 121 Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. Boot Override Device Name http://www.tyan.com...

  • Page 122: Chapter 4: Diagnostics

    BIOS flash failure, you must contact your dealer for a replacement BIOS. There are no exceptions. TYAN does not have a policy for replacing BIOS chips directly with end users. In no event will TYAN be held responsible for damages done by the end user.

  • Page 123: Amibios Post Code (Aptio)

    South Bridge initialization before microcode loading 0x05 OEM initialization before microcode loading 0x06 Microcode loading 0x07 AP initialization after microcode loading 0x08 North Bridge initialization after microcode loading 0x09 South Bridge initialization after microcode loading 0x0A OEM initialization after microcode loading 0x0B Cache initialization http://www.tyan.com...
  • Page 124 Memory initialization. Configuring memory 0x2F Memory initialization (other) 0x30 Reserved for ASL (see ASL Status Codes section below) 0x31 Memory Installed 0x32 CPU post-memory initialization is started. 0x33 CPU post-memory initialization. Cache initialization CPU post-memory initialization. Application Processor(s) (AP) 0x34 initialization http://www.tyan.com...
  • Page 125 S3 Resume Progress Codes 0xE0 S3 Resume is started (S3 Resume PPI is called by the DXE IPL). 0xE1 S3 Boot Script execution 0xE2 Video repost 0xE3 OS S3 wake vector call 0xE4 – 0xE7 Reserved for future AMI progress codes http://www.tyan.com...
  • Page 126 DXEIPL was not found. DXE Core Firmware Volume was not found. Recovery failed S3 Resume failed Reset PPI is not available. DXE Phase Status Code Description 0x60 DXE Core is started. 0x61 NVRAM initialization 0x62 Installation of the South Bridge Runtime Services http://www.tyan.com...
  • Page 127 PCI Bus Hot Plug Controller initialization 0x94 PCI Bus Enumeration 0x95 PCI BUS Request Resources 0x96 PCI Bus Assign Resources 0x97 Console output devices connect 0x98 Console Input devices connect 0x99 Super IO initialization 0x9A USB initialization is started. http://www.tyan.com...
  • Page 128 0xC0 – 0xCF OEM BDS initialization codes DXE Error Codes 0xD0 CPU initialization error 0xD1 North Bridge initialization error 0xD2 South Bridge initialization error 0xD3 Some of the Architectural Protocols are not available 0xD4 PCI resource allocation error. Out of Resources http://www.tyan.com...
  • Page 129 System is waking up from the S3 sleep state. 0x40 System is waking up from the S4 sleep state. System has transitioned into ACPI mode. Interrupt controller is in 0xAC APIC mode. System has transitioned into ACPI mode. Interrupt controller is in 0xAA APIC mode. http://www.tyan.com...

  • Page 130: Appendix I: Fan And Temp Sensors

    (rpm) Temp Sensor: SYS_Air_Outlet (RT3),and MB_Air_Inlet (RT2). They detect the system temperature around. NOTE: The system temperature is measured in a scale defined by Intel, not in Fahrenheit or Celsius. http://www.tyan.com...
  • Page 131 BIOS Temp Sensor Name Explanation: http://www.tyan.com...
  • Page 132 http://www.tyan.com...
  • Page 133 Fan speed of SYS_FAN_2 SYS_FAN_3 Fan speed of SYS_FAN_3 SYS_FAN_4 Fan speed of SYS_FAN_4 SYS_FAN_5 Fan speed of SYS_FAN_5 SYS_FAN_6 Fan speed of SYS_FAN_6 SYS_FAN_7 Fan speed of SYS_FAN_7 SYS_FAN_8 Fan speed of SYS_FAN_8 SYS_FAN_9 Fan speed of SYS_FAN_9 http://www.tyan.com...
  • Page 134 SYS_FAN_10 Fan speed of SYS_FAN_10 SYS_FAN_11 Fan speed of SYS_FAN_11 SYS_FAN_12 Fan speed of SYS_FAN_12 http://www.tyan.com...
  • Page 135 NOTE http://www.tyan.com...

  • Page 136: Glossary

    (reading to or writing from a disk drive a single time is much faster than doing so repeatedly) there is the possibility of losing your data should the system crash. Information in a buffer is temporarily stored, not permanently saved. http://www.tyan.com...
  • Page 137 (like soundcards or keyboards) to access the main memory without involving the CPU. This frees up CPU resources for other tasks. As with IRQs, it is vital that you do not double up devices on a single line. Plug-n-Play devices will take care of this for you. http://www.tyan.com...
  • Page 138 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep ® up with changes in the BIOS programs without having to buy a new chip. TYAN ‟s BIOS updates can be found at http://www.tyan.com...
  • Page 139 PXE (Preboot Execution Environment): one of four components that together make up the Wired for Management 2.0 baseline specification. PXE was designed to define a standard set of preboot protocol services within a client with the goal of allowing networked-based booting to boot using industry standard protocols. http://www.tyan.com...
  • Page 140 NVIDIA s (graphics communications processing units) and NVIDIA MCPs (media and processors). application Depending on the , NVIDIA SLI can deliver as much as two times the performance of a single GPU configuration. http://www.tyan.com...
  • Page 141 CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.tyan.com...

  • Page 142: Technical Support

    "TYAN's tech support is some of the most impressive we've seen, with great response time and exceptional organization in general" - Anandtech.com Help Resources: 1. See the beep codes section of this manual.
  • Page 143 (RMA) number. The RMA number Should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. ® TYAN will pay to have the board shipped back to you. Notice for the USA Compliance Information Statement (Declaration of...
