Delphi DEA610 Owner's Manual page 9

Figure 4: Swipe to Down action presents up screen.
The next to the bottom screen is presented once the system senses a Swipe
to Up action.
Figure 5: Swipe to Up action presents down screen.
Home screen & Navigation buttons
The installed application icons are presented at the home screen. The home
screen is distributed in a main screen and subsequent home screens.
Owner´s Manual DEA600 Radio
Each of the home screens present 6 application icons maximum plus the
Audio widget. The number of the subsequent home screens is relative to the
number of installed applications. Each subsequent home screen is added to
the right of the main home screen or next to the right of the last subsequent
home screen.
In the case the last subsequent home screen is reached and a swipe to the
left action is performed the system presents the main home screen. If a
swipe to right action is perfor med from the main home screen the system
presents the last subsequent home screen.
An indicator identifies which home screen is displayed. The screen indicator
is placed below the top bar of the home screen.
Each application icon in the home screen work as the application activation
soft key.
At the top bar of each of the home screens the next information is presented
all the time if available:
•
Clock
•
Alarm
•
Warning icons
•
Weather infor mation
When the system is turned OFF but IGN and Battery are connected, the
clock view is kept small as illustrated on Figure 6Figure 6Figure
Figure 6: Clock view in OFF power mode.
6.
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita,
Sin subrayado, Color de fuente:
Automático
9 | P a g e
