Sirius Xm; Radio Source - Delphi DEA610 Owner's Manual

Figure 32: The WX radio source screen.

Sirius XM

In the case the Sirius XM source is selected the system displays the current
tuned channel number and name.
The system present the next control softkeys as par t of the Sirius XM
interface.
1. Category Browse control / Indicator
2. Scan Live
3. Direct Tuning
4. Buffer Indicator Bar
5. Replay Control
6. Jump to Live Control
7. Tune Scan Control
8. Channel Browsing
9. Presets (Smart Favorites)
The Sirius XM user interface screen is illustrated in
33Figure 33.
Owner´s Manual DEA600 Radio
The channel number in the screen works as a softkey.
In the case the channel art is not available it's replaced by the Sirius XM
logo.
The system activate the Scan function in the case the Scan option is
selected.
The system displays up to 18 presets memories in a tab divider manner at
the bottom of the screen interface. To save stations in to preset follow the
Figure 33Figure
AM-FM instructions.
The system display a pop-up sub menu in the case the Menu button is
selected while in this screen.
Figure 33: The Sirius XM user interface screen.
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita,
Sin subrayado, Color de fuente:
Automático
24 | P a g e
