The User Defined Virtual Gauges Priorities does not modify the Default
Virtual Gauges Priorities.
Gauge Population
Automatic arrangement is used to identify available gauges.
The population of the gauges for the Automatic arrangement is depending
on the priority preset selected.
The priority preset is configurable through the Settings menu of the Virtual
gauges app.
Automatic Populat ion
The Virtual Gauges are populated by adding gauges if the relative vehicle
information is available. The Virtual Gauges app adds available gauges
following the priority established.
The actual Virtual Gauges page from the Virtual Gauges app page is
highlighted, allowing the user to differentiate it from the disabled pages and
from the ac tive pages that are not selected as the actual page.
The Standard Priority list of gauges have a higher priority than the Optional
Gauges, even if a given gauge from the Optional gauges shares a priority
level with a gauge from the Standard Priority gauges.
If not Available information for a specific Gauge is received from the vehicle
information bus is received the related Gauge is hidden. Some virtual
gauges show a specific icon in the case of a not available gauge.
The Virtual Gauges app pages for gauges population are disabled if there
are no gauges in the page. The disabled Virtual Gauges app pages are
displayed in an opaque manner.
The active Virtual Gauges app pages are displayed in c lear way which
allows the user to differentiate between the actual page and disabled pages.
As the optional virtual gauges become available, they starts to be
accommodated from the last active gauge displayed filling the available slots
in all the pages in an incremental order and following the preset priority.
Owner´s Manual DEA600 Radio
The Virtual Gauges app does not allow the user to select the disabled gauge
pages until they become available.
Each time a Virtual Gauges app page is filled with gauges, the Virtual
Gauges app activate the subsequent page, in an incremental order, to
continue placing the ac tive virtual gauges.
Priority presets
Priority Preset 1
Engine Oil Temperature
Main Trans Oil Temperature
Manifold Pressure (Boost)
DPF Status
Fuel Economy
Percent Torque
Percent Horsepower
Idle Time
Idle Fuel
Fuel Usage Rate
Drive Axle #1 (front) Oil Temperature
Drive Axle #2 (rear) Oil Temperature
Drive Axle #3 (center) Oil Temperature
Air Filter Restriction Pressure
Fuel Filter Restriction/Fuel Pressure Gauge
Ammeter
Air Suspension Pressure 1
Tractor Brake Application
Pusher Axle #1 Pressure
PTO Hour Meter
Priority Preset 2
Engine Oil Temperature
Main Trans Oil Temperature
Manifold Pressure (Boost)
DPF Status
Fuel Economy
Percent Torque
Gauge Priority
Page One
Page One
Page One
Page One
Page One
Page One
NA
NA
NA
NA
2
3
4
6
7
1
5
N/A – In Cluster
8
9
Gauge Prior ity
Page One
Page One
Page One
Page One
Page One
Page One
