Front Auxiliary - Delphi DEA610 Owner's Manual

To load a disc:
1. Turn the vehic le on.
2. Inser t a disc into the slot, label side up. The player pulls it in the
rest of the way. If the disc is damaged or improperly loaded, there
is an error on the screen and the disc ejects.
3. Press "Eject" to eject a disc from the CD player. If the disc is not
removed within a short period of time, it is automatically pulled back
into the player.
Playing an Audio CD
1. After the CD is inserted, the mode is changed to CD mode, unless
any mode with a higher priority is active (I.E. phone call, video,
reverse mute....).
2. To control and browse the selected media source refer to sections
Media Sources and Media Audio Control Softkey for fur ther
information.
Error Messages
If "Disc Error" message is displayed and/or the disc comes out, it could be
for one of the following reasons:
•
The disc has an invalid or unknown format.
•
The disc is very hot. Try the disc again when the temperature
returns to normal.
•
The road is very rough. Try the disc again when the road is
smoother.
•
The disc is bent.
•
The disc is dir ty, scratched, wet, or upside down.
•
The air is very humid. Try the disc again later.
•
There was a problem while burning the disc.
•
The label is caught in the CD player.
•
If the disc is not playing correctly, for any other reason, try a known
good CD.
•
If any error continues, contact your dealer.
For MP3 Files
•
Bit rates: 32, 40, 48, 56, 64, 80, 96, 112, 124, 160, 192, 224, 256,
320 kbps for MPEG-1 Audio Layer 3.
Owner´s Manual DEA600 Radio
•
Sampling frequencies: 32, 44.1 and 48 kHz for MPEG-1 Audio
Layer 3.
•
Maximum number of folders: Eight folders with 255 files per folder.
•
Maximum of 1,000 files on a disc.
•
M3U and PLS playlist versions supported.
•
Recorded on a CD-R or CD-RW with a maximum capacity of 700
MB.
For Unprotected WMA Files
•
Versions: 1, 2, 7, 8, 9 and 9.1.
•
Bit rates: 32 - 320 kbps.
•
Sampling frequencies: 32 - 48 kHz.
Special Considerations
Root Directory:
The root directory is treated as a folder. All files contained directly under the
root directory are accessed prior to any root directory folders.
Empty Folders:
If a root directory or folder is empty or contains only folders, the player
advances to the next folder in the file structure that contains a compressed
audio file. The empty folder(s) are not displayed or numbered.

Front Auxiliary

Front auxiliary input is active when a jack connector is inserted.
After the connector is inserted, the mode is changed to Front Aux mode,
unless any mode with a higher priority is active (I.E. phone call, video,
reverse mute....).
This operation is not available while the system is in standby power mode.
In front auxiliary mode, you can play an external device such as an iPod
MP3 player via the auxiliary input jack on the front of the receiver.
To use an external device simply connect the device via the auxiliary input
jack.
®
or
21 | P a g e
