Percent Horsepower
Idle Time
Idle Fuel
Preset Gauges Interaction
The active gauges in the General Settings screen of the Vir tual Gauges app
are able to move their positions by selecting a gauge and dragging it to a
new desired position.
When selecting a gauge and dragging it to a new position in the General
settings screen of the Virtual Gauges app, as the gauge moves it snap to the
closest gauge slot, even if the slot is occupied with other gauge, to show the
user there the new position of the gauge will be when the user deselect the
gauge.
While a gauge is being moved and starts snapping in other gauge slots in
the General Settings screen of the Virtual Gauges app, the non- moving
gauges re-position to give space to the dragged gauge.
The re-positioning of the non-selected gauges from the General Settings
screen of the Vir tual Gauges app shall be according the following rules:
•
Gauges in the preceding slots will shift back one position until the
position where the selected gauge was originally is reached.
•
Gauges in slots after where the selected gauge snaps will remain
unaffected.
Once the user stops pressing the screen, all the gauges moved and the
gauge selected keep their new positions.
Only one gauge can be moved at a time to re-positioned in the General
Settings screen of the Virtual Gauges app.
While moving a gauge of position in the General Settings screen of the
Virtual Gauges app, if the user moves the gauge to one of the sides of the
screen, the Vir tual gauges app switch to the next/previous page, depending
on the side. In this case, right side is related with the next page and the left
side is related with the previous page.
Owner´s Manual DEA600 Radio
The page movement when a gauge is moved to one of the sides of the
N/A
N/A screen in the General Settings screen in the Virtual Gauges app while the
N/A gauge is being moved of position has the following restrictions:
•
The page switching shall be restricted to the active pages
•
If the gauge is moved to the left side of the screen while in the first
page no action shall be performed
•
If the gauge is moved to the right side of the screen while in the last
active page no action is perfor med
Reset to Default Screen
If the Reset to Default Soft key from the General Settings of the Virtual
Gauges app is depressed, the Virtual Gauges app shall restore the gauge
priority list to the Default Virtual Gauges priorities, updating also the position
of the gauges in the Settings Screen and in the Virtual Gauges app.
When short pressed, prior to reset to the Default Virtual Gauges priorities the
Virtual Gauges app displays the following Pup-up warning.
82Figure 82
OK and Cancel act as a soft keys in the Pop-up warning.
as reference.
Figure 82 Reset configuration Pop-up
Figure 82Figure
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita
Con formato: Fuente:
(Predeterminado) Arial, 9 pto, Negrita,
Sin subrayado, Color de fuente:
Automático
