- Page 1 MANUAL ENGLISH Digital Flex Strip RGB Ordercode: 42773 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Digital Flex Strip RGB Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Connection with the mains............................4 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Features ..................................6 Overview ..................................6 Installation ................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec Digital Flex Strip RGB RGBW controller ... - Page 4 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Digital Flex Strip RGB Operating Determinations • This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. • The minimum distance between light output and the illuminated surface must be bigger than 1 meter. -
Page 6: Return Procedure
Digital Flex Strip RGB Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 7: Description Of The Device
Digital Flex Strip RGB Description of the device Features The Showtec Digital Flex Strip RGB is a LED strip with high output and great effects. Power supply: DC 12V 2A power adapter Power consumption: 26W Light source: 5050 RGB LEDs ... -
Page 8: Installation
Digital Flex Strip RGB Installation Remove all packing materials from the Digital Flex Strip RGB. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 9: Set Up And Operation
Digital Flex Strip RGB Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. -
Page 10: Ic Settings
Digital Flex Strip RGB IC Settings With this menu it is possible to (de)activate particular LED sections of the Digital Flex Strip. 01) Press the button to enter IC settings. 02) Press the buttons to activate/deactivate LED sections. Color Modes... -
Page 11: Auto
Digital Flex Strip RGB Auto 01) Press the button to start the auto program. 02) Press the buttons to set the auto program speed. Flash 01) Press the button to start the flash effect. 02) Press the buttons to set the flash speed. -
Page 12: Maintenance
04) The electric power supply cables must not show any damages or material fatigue. The Digital Flex Strip RGB requires almost no maintenance. However, you should keep the unit clean. Otherwise, the device’s light output will be significantly reduced. Disconnect the mains power supply, and then wipe the LED strip with a cloth. -
Page 13: Product Specifications
Digital Flex Strip RGB Product Specifications Model: Showtec Digital Flex Strip RGB Power supply: DC 12V 2A power adapter Power consumption: Dimensions: 5000 x 10 mm (LxW) Weight: 0,4 kg Electro-mechanical effects: Light source: 5050 RGB LEDs PCB: White, 12 mm wide Beam angle: 120°... -
Page 14: Notes
Digital Flex Strip RGB Notes Ordercode: 42773... - Page 15 Digital Flex Strip RGB Ordercode: 42773...
- Page 16 ©2016 Showtec...
