- Page 1 LED Flamelight ORDERCODE 43030...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
- Page 3 Showtec Showtec LED Flamelight Product Guide ™ Warning..…...................……………………………………………………….. Safety-instructions………………………………………………………………………………………………………… Operating Determinations…….……………………………………………………………………………………….. Rigging…………………………….……………………………………………………………………………………….. Description..…................……….…………………………………………….. Features and Overview …………..……………………...….……………….………….……….……….……………. Backside……………………………….…………………...…...….……………….…………………...………………… Installation................…...………………………………………….………..…. Set Up and Operation..............……..……………………………………………… Stand-alone..……..……………………………………………………………………………….……………………..… DMX Dip Switch Setting……….……..………………………………………………………………………….…….…. Channels…………………..………..……………………………………………………………………………….. Maintenance...................………..………….…….………………………….. Changing the Fuse................…………………….………………………..…... Troubleshooting................………………….………………….………………... Product Specifications..............……………….…….………………………………...
-
Page 4: Safety Instructions
WARNING CAUTION! Keep this device away from rain and moisture! indoor use only! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this device has to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. -
Page 5: Operating Determinations
The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature. If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. -
Page 6: Description Of The Device
Description of the device Features LED Flamelight is a LED system from Showtec. • 29 pcs 1 Watt LEDs (16 Red, 10 Yellow, 3 Blue) • Stand-alone mode • DMX-512 • DMX Channels: 4 channels (Red, Yellow, Blue, Dimmer) •... -
Page 7: Installation
Installation Remove all packing materials from the Flamelight. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty. -
Page 8: Dmx Channels
Addresses on the Showtec LED Flamelight are set by flipping the appropriate DMX dip switches. You need to know that DMX address settings are the sum of the dip switch values. A standard DMX address for a Showtec LED Flamelight, which has 4 channels is as follow: Example... -
Page 9: Maintenance
3. If all of the above appears to be O.K., plug the unit in again. 4. If you are unable to determine the cause of the problem, do not open the LED Flamelight, as this may damage the unit and the warranty will become void. -
Page 10: Product Specification
Product Specification Model: Showtec LED Flamelight Voltage : AC 230V-50Hz (CE) Power: 120W Fuse: 250V / T500mA DMX Input : 3-pin XLR Male connector DMX Output : 3-pin XLR Female connector 29 pcs 1 Watt LEDs (16 Red, 10 Yellow, 3 Blue)
