LIGHTS
LIGHTS MENU DESCRIPTION
To access the lights menu, press the
main menu screen.
Thur 05/09/09 - 16:07 0W
Downstairs area Downstairs area
ON
Upstairs area
ON
5
Attic Attic
ON
Laundry Laundry
ON
1 Areas available.
2 Scroll through the screen (only when there are
more than 4 programmed areas).
3 Lights scheduling menu.
4 Switch off all lights in the corresponding area.
5 Switch on all lights in the corresponding area.
Thur 05/09/09 - 16:07 0W
Downstairs area
ON
Upstairs area Upstairs area
ON
Attic Attic
ON
Laundry Laundry
ON
1 One or more lights in the area are on.
2 All lights in the area are on.
3 All lights in the area are off.

LIGHT CONTROL

icon on the
The lights within various areas may be controlled
individually.
Press the relevant icon in the lights menu (e.g.
Upstairs area).
1
OFF
OFF
2
OFF
3
OFF 7
4
1 Area displayed.
2 Light with dimmer (press and hold to adjust the
3 Light off.
4 Light ON/OFF.
5 Light scheduling menu.
1
6 Timed light (press to adjust the active time period),
OFF
7 Switch light on.
2
OFF
3
OFF
OFF
7
Thur 05/09/09 - 16:07 0W
Upstairs area
Bedroom 1
ON
Bedside table Bedside table
ON
Stairs Stairs
ON
intensity).
see below.
Thur 05/09/09 - 16:07 0W
0:12
1
2
OFF
3
4
OFF
T
5
OFF
6
