Shutter Control - Comelit PLANUX MANAGER Manual

SHUTTERS MENU DESCRIPTION
To access the Shutters menu, press the
the main menu screen.
Thur 05/09/09 - 16:07 0W
Downstairs area Downstairs area
Upstairs area
5
Attic Attic
Laundry Laundry
1 Areas available.
2 Scroll through the screen (only when there are
more than 4 programmed areas).
3 Shutter scheduling menu.
4 Close all shutters in the corresponding area.
5 Open all shutters in the corresponding area.
Thur 05/09/09 - 16:07 0W
Downstairs area
Upstairs area Upstairs area
Attic Attic
Laundry Laundry
1 One or more shutters in the area are moving.
2 All shutters in the area are moving.
3 All shutters in the area are stationary.

SHUTTER CONTROL

The shutters within various areas may be controlled
icon on
individually.
Press the relevant icon in the shutters menu (e.g.
Upstairs area).
1
2
5
3
4
1 Area displayed.
2 Close shutters.
3 Shutter scheduling menu.
4 Shutters available.
5 Open shutter.
1
2
3
16
Thur 05/09/09 - 16:07 0W
Upstairs area
Bedroom 1
Bedroom 2 Bedroom 2
Bathroom Bathroom
SHUTTERS
1
2
3
4
