ALARM
ACTIVATING THE ALARM FOR AN AREA
Access the Alarms menu.
Press the icon corresponding to one of the available areas.
Thur 05/09/09 - 16:07 0W
Downstairs area Downstairs area
Upstairs area
External area
Garage
Enter the password and press the
Thur 05/09/09 - 16:07 0W
ENTER
PASSWORD
icon to confirm.
2 3
1
4 5 6
8 9
7
C 0
Thur 05/09/09 - 16:07 0W
Partial 1
Partial 2
5
Total
4
1 Instant arming mode.
2 Delayed arming mode.
3 Zones menu.
4 Deactivation of all alarms / memory reset for the
selected area.
5 Selected area status.
Press the icon corresponding to the arming mode
(Instant or Delayed). Part arming 1, Part arming 2 and
Delayed arming can only be activated if programmed
in the control panel.
Thur 05/09/09 - 16:07 0W
Partial 1
1
Partial 2
2
Total
1 Active zone.
2 Inactive zones.
