ALARMS MENU DESCRIPTION
To access the Alarms menu, press the
main menu screen.
Thur 05/09/09 - 16:07 0W
Downstairs area Downstairs area
5
Upstairs area
4
External area
3
Garage
1 Areas available.
2 Scroll through the screen (only when there are
more than 4 programmed areas).
3 Alarm settings menu.
4 Full anti-intrusion system arming.
5 Full anti-intrusion system disarming / alarm
memory reset.
AREA STATUS LEGEND
icon on the
Piano giorno
1
Piano giorno Piano giorno
2
Piano giorno Piano giorno
3
4
Piano giorno Piano giorno
1 Alarm not active.
1
2 Part zone 1 active.
3 Part zone 2 active.
4 Part zones 1 and 2 active.
5 All area zones active.
2
6 Area not ready for arming.
7 Alarm memory.
8 Area in alarm status.
54
ALARM
Piano giorno Piano giorno
5
1 1
Piano giorno
6
2 2 Piano giorno
7
Piano giorno
P P 8
T T
