LOADS MENU DESCRIPTION
To access the Loads menu, press the
main menu screen.
Thur 05/09/09 - 16:07 0W
Downstairs area Downstairs area
ON
Upstairs area
ON
5
Attic Attic
ON
Laundry Laundry
ON
1 Areas available.
2 Scroll through the screen (only when there are
more than 4 programmed areas).
3 Load scheduling menu.
4 Switch off all loads in the corresponding area.
5 Switch on all loads in the corresponding area.
Gio 05/09/09 - 16:07 0W
Downstairs area
ON
Upstairs area Upstairs area
ON
Attic Attic
ON
Laundry Laundry
ON
1 One or more loads in the area are on.
2 All loads in the area are on.
3 All loads in the area are off.
icon on the
The loads within various areas may be controlled
individually.
Press the relevant icon in the loads menu (e.g.
Upstairs area).
1
OFF
OFF
2
OFF
3
OFF 6
4
1 Area displayed.
2 Load ON/OFF.
3 Load off.
4 Load scheduling menu.
5 Timed load.
1
6 Load on (press to adjust the active time period),
OFF
2
OFF
3
OFF
OFF
12

LOAD CONTROL

Thur 05/09/09 - 16:07 0W
Upstairs area
Bedside outlet
ON
TV outlet TV outlet
ON
5
see below.
Thur 05/09/09 - 16:07 0W
LOADS
OFF
T
OFF
0:12
1
2
3
4
