LED and Beeper Indications

User Environment
Operating Temperature 0° to 50° C (32° to 122° F)
Storage Temperature
Humidity
Drop Specifications
Ambient Light
Immunity
Contaminants Spray/
rain Dust/particulates
ESD Level
Regulatory
LED and Beeper Indications
The reader's beeper sounds and its top multi-colour LED illu-
minates to indicate various functions or errors on the reader.
An optional "Green Spot" also performs useful functions. The
following tables list these indications. One exception to the
behaviors listed in the tables is that the reader's functions are
programmable, and so may or may not be turned on. For
example, certain indications such as the power-up beep can
be disabled using programming bar code labels.
Indicator
Power-up
Beep
22
-40° to 70 °C (-40° to 158° F)
Operating: 0% to 95% relative humidity,
non-condensing
Scanner withstands 18 drops from 1.5
meters (5.0 feet) to concrete
Up to 86,000 Lux
IEC 529-IP42
(IP52 QD2430-E model only)
16 KV
SEE REGULATORY ADDENDUM
Description
The reader is in
the process of
powering-up.
LED
Reader beeps
four times at
highest fre-
quency and vol-
ume upon
power-up.
QuickScan™ QD2430
Beeper
