Dynojet power commander v Installation Instructions Manual page 3

FIG.A
FIG.B
FIG.C
I11-009 www.powercommander.com
1 Remove both side panels by pulling out the split cotter pins and pivoting the
panels rearward out of the hinge points.
2 With the side panels removed, remove the torx head screw securing the hood
to the cowling on both sides of the snowmobile.
3 Unscrew the two torx screws underneath the front of the snowmobile.
These screws are recessed above the skid plate and accessible through two
access holes.
2012 Arctic Cat 1100 Turbo PCV - 3
