Control panel

1 On/off indicator
2 Programme marker
3 Indicators
4 Delay start button
5 Start/cancel button
6 Programme knob
1) When the salt container and/or the rinse aid dispenser are empty, the related indicators do not come on while a washing programme
operates.
Programme knob and on/off indicator
To activate the appliance and set a washing programme
• Align the programme marker that is on the knob with a
washing programme. Refer to 'Washing programmes'.
The on/off indicator comes on.
To deactivate the appliance
• Align the programme marker with the on/off indicator.
The on/off indicator goes off.
4
End indicator. It comes on in these conditions:
• When the washing programme is completed.
• When you adjust the level of the water softener.
• When there is a malfunction of the appliance.
Salt indicator. It comes on when it is necessary to fill the salt container.
1)
After you fill the container, the salt indicator can stay on for some hours. This does not have an
unwanted effect on the operation of the appliance.
Rinse aid indicator. It comes on when it is necessary to fill the rinse aid dispenser.
1
Indicators
Delay start button
Press this button to delay the start of the washing pro-
gramme of three hours. Refer to 'Select and start a wash-
ing programme'.
Start/cancel button
Use this button for these operations:
• To start the washing programme. Refer to 'Select and
start a washing programme'.
2
6
5 4 3
