HOW TO ADJUST THE DRIVE BELT
If the pedals slip while you are pedaling, the drive
belt may need to be adjusted.
66
To adjust the drive belt, first press the power switch
to the off position and unplug the power cord.
Next, locate the access hole in the underside of the
Right Shield (12). Insert a hex key into the access
hole, and tighten the Idler Adjustment Screw (not
12
Access
shown) slightly.
Hole
Then, plug in the power cord and press the power
switch to the reset position. Pedal the exercise bike
for a moment. Repeat these actions, if necessary,
until the pedals no longer slip while you are pedaling.
