8. Tip: Avoid pinching the Main Wire (68) during
this step.
Locate the Post Knob (47) near the front of the
Frame (2). Loosen the Post Knob, and then pull
it outward.
Next, insert the Handlebar Post (6) into the
Frame (2), and release the Post Knob (47) into
one of the adjustment holes in the Handlebar
Post. Make sure that the Post Knob is in an
adjustment hole. Then, tighten the Post Knob.
9. Have a second person hold the Handlebar (7)
near the Handlebar Carriage (105).
Locate the remaining wire tie in the Handlebar
Carriage (105). Tie the indicated end of the wire
tie to the two wires on the Handlebar (7).
Next, pull the other end of the wire tie until the
two wires are routed through the Handlebar
Carriage (105). Then, untie and discard the wire
tie.
8
Avoid pinching the
Main Wire (68)
2
47
9
7
Wire Tie
10
6
68
105
