Components, S-Video and Composite Video. However, the
HT3000 HOST system features an excellent video decoder
and de-interlacer, and therefore, even inferior quality signals
will produce extremely pleasing images.
Failure to observe the above warnings may cause the
fibre optic cable to break. It is appreciated that it is
not always practical or convenient but due to the frag-
ile nature of fibre optic cables we highly recommend
to test the cable prior to and after installation. Also it
is good practice to examine the cable between fixes
and making good just in case other trades haven't
7 NETWORK FUNCTIONS (RJ45 connector)
NETWORK FUNCTIONS (RJ45 connector)
The HT3000 HOST system has a 10/100 Mbit Ethernet in-
terface located on the HOST system connector panel to
connect the projector to a LAN network or to the Internet.
The network connection can be used to remotely control
the projector from any workstation with access to the net-
work by sending TCP/IP protocol commands.
Additionally, by suitably configuring the network specifica-
tions, you can receive e-mail notifications on the operating
status of the HT3000 HOST system.
Configuring network functions by OSD (network setup):
The "Network configuration" option in the "Setup" menu is
displayed only when no signal is being displayed.
Network Setting
IP Configuration
Email Configuration
IP: 172.031.127.045
This menu screen permits you to:
1. access the menu for setting the projector's network ad-
dress;
2. access the menu for entering the e-mail address for re-
ceiving notifications on the projector status.
The projector's current IP address and MAC address (phys-
ical address) are displayed at the bottom of the screen.
N.B. The system is delivered with default factory settings,
in which the dynamic IP address (DHCP) is active. If the
network to which the projector is connected has no DHCP
server, the current IP address displayed on screen may not
be valid.
Downloaded From projector-manual.com Sim2 Manuals
MAC: 00:00:00:00:00:00
8
accidentally damaged the cable. All cables are fully
tested prior to shipping. SIM2 cannot be held respon-
sible for damage caused to property or incurred costs
as a result of a malfunctioning cable.
TYPE OF IP ADDRESS
This screen permits you to select the type of IP address to
be assigned:
1. Static IP: the IP address, network SUBNET and GATE-
WAY must be entered manually.
2. Dynamic IP (DHCP): choose this option if you want the
projector IP address to be automatically assigned by the
network DHCP server (in most networks the DHCP server
is a router).
REMOTE CONTROL
In order to control the projector by TCP/IP protocol, you
must specify the TCP port to which the connection must
IP Address Mode
Static IP
IP Address:
Subnet Mask:
Gateway:
DHCP Host Name :
Web interface
Port: 08080
Password: XXXX
Remote Control
Port 1: 10001
Port 2: 30704
Apply Settings
Factory Settings
be made (called TCP socket). Choose the port number and
set "Port 1".
If you want to establish a connection with the projector via
the Internet, the port chosen for remote connection must
be accessible from outside (usually a Virtual Server is cre-
ated in the network router to make the projector's IP ad-
dress accessible from a Personal Computer connected to
the Internet).
HT3000 HOST
Dinamic IP (DHCP)
172.031.127.055
255.255.000.000
172.031.045.115
sim2prj
