Price Computing Scale
User Manual
14key & 16key
©EXCELL PRECISION CO., LTD. 2014. All rights reserved worldwide.
The information contained herein is the property of EXCELL PRECISION CO., LTD. and is
supplied without liability for errors or omissions. No part may be reproduced or used
except as authorized by contract or other written permission. The copyright and the
foregoing restriction on reproduction and use extend to all media in which the information
may be embodied.
Advertisement
Table of Contents
Related Manuals for Excell 14key
Summary of Contents for Excell 14key
-
Page 1: User Manual
14key & 16key ©EXCELL PRECISION CO., LTD. 2014. All rights reserved worldwide. The information contained herein is the property of EXCELL PRECISION CO., LTD. and is supplied without liability for errors or omissions. No part may be reproduced or used except as authorized by contract or other written permission. -
Page 3: Table Of Contents
EXCELL PRECISION CO., LTD. TABLE OF CONTENTS INSTRUCTION FOR USE ...................... 2 PREPARATION BEFORE USING................... 2 CHAPTER 1 PRODUCT INSTRUCTION................3 1-1 I ......................... 4 NTRODUCTION 1-2 E ......................4 RROR ESSAGES 1-3 S ......................4 CREEN ISPLAY 1-4 P ....................... -
Page 4: Instruction For Use
EXCELL PRECISION CO., LTD. Thank you for purchasing Price Computing Scale. In order to operate smoothly, to last the durability, and to reduce the chance of breakdown for this product, please read this Manual carefully. Instruction for Use 1. In order to prevent the scale from dust and static electricity, please fix the dustproof cover on the scale with double-sided adhesive. - Page 5 EXCELL PRECISION CO., LTD. Due to the storage battery adopt the advanced free-maintaining technique, customers need not to replenish electrolyte. The scale should be recharged every 3 months to prevent failure of the internal rechargeable battery. 1. The battery should be charged for 8~10 hours.
-
Page 6: Chapter 1 Product Instruction
EXCELL PRECISION CO., LTD. Chapter 1 Product Instruction 1-1 Introduction 1. High performance A/D converter 0.3 uv/D high sensitivity zero point adjustable range -5mV~ +5mV • • Sampling speed 15 tines/second use range -4mV ~ +4mV • • load cell stimulate power source 5V DC non-linear scale 0.01% full scale... -
Page 7: Power Supply
EXCELL PRECISION CO., LTD. 2. Unit Price 6 digits in total display the unit price of objects on platter. The decimal point floats two digits. 3. Total Price 6 digits in total display the total price of the objects on platter or the accumulation. -
Page 8: Chapter 2 Keyboard Function
EXCELL PRECISION CO., LTD. Chapter 2 Keyboard Function 10 ~ 9 : Number key. Press the keys to input the numbers (0 ~ 9) and to set unit price. : Press the key to clear the old unit price and then input the new one if you 、0C0... -
Page 9: Chapter 3 Operation Instruction
EXCELL PRECISION CO., LTD. Chapter 3 Operation Instruction 3-1 Internal Value Display Mode Press Z key, when the display show “ ” ,then, press CE key immediately (1C1 for 16 key). The display will show internal value. Press 0 to exit the internal value mode and return to the weighing mode. -
Page 10: G Value Adjustment
EXCELL PRECISION CO., LTD. 3-4 G Value Adjustment Steps: Press 0 key and do not release, and then power on to enter int G value adjustion mode. Press T key to search the historic G value data. Press Z key to set and confirm G value. (→0← for 16 key) Press 0 ~ 9 key to input the value. -
Page 11: Preset Tare Operating Mode
EXCELL PRECISION CO., LTD. 3-5-2 Preset tare Operating mode The scale should be empty, and press number key to input the preset tare value you want, For example, if you want preset tare 1.00kg, you should input 100 It shows as follows:... -
Page 12: 16Key 50Preset Settings
EXCELL PRECISION CO., LTD. 3-5-3 16KEY 50PRESET settings Preset PLU setting mode. 1. Hold PLUkey until it shows as follows: (Unit Price shows 0 and flickers ) Weight Unit Price Total P nr. Both the scale is empty and there is weight on are ok 2. -
Page 13: Chapter 4 Function Setting
EXCELL PRECISION CO., LTD. Chapter 4 Function Setting Press Z key and do not release to enter function setting mode. (for 14 key) Press F key and do not release to enter function setting mode. (for 16 key) WEIGHT UNIT PRICE... -
Page 14: F1 ⇒ Rs-232 Baud Rate
EXCELL PRECISION CO., LTD. 4-1 F1 ⇒ RS-232 Baud Rate Weight Unit Price Total Price Using 0 , 1 , 2 , 3 keys to choose 0,1,2,3 in order 0 ⇒ 9600 bits/second 1 ⇒ 4800 bits/second 2 ⇒ 2400 bits/second 3 ⇒... -
Page 15: F2 ⇒ Transmission Mode ( Rs-232 )
EXCELL PRECISION CO., LTD. 4-2 F2 ⇒ Transmission Mode ( RS-232 ) Weight Unit Price Total Price Press number key 0 , 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 to choose 0,1,2,3,4,5,6,7,8 in order 1 ⇒... - Page 16 EXCELL PRECISION CO., LTD. RS232 DATA FORMAT When F2 setting is “1” or “2” (1) Weight unit is g. 10 11 12 13 14 15 16 17 ± HEAD HEAD DATA UNIT CR (2) Weight unit is kg/lb 10 11 12 13 14 15 16 17 18 kg/lb ±...
- Page 17 EXCELL PRECISION CO., LTD. Example of Transmission: Data format for RS-232 continuous transmission are as below. 1. The gross weight (+0.876 kg) shown as below, after stable: (under no tare or pre-tare mode) 0D 0A HEAD HEAD DATA UNIT 2. The net weight (-1.568lb) shows as below, after unstable: (under tare or pre-tare mode)
-
Page 18: Appendix 1 7-Segment Display Characters
EXCELL PRECISION CO., LTD. Appendix 1 7-Segment Display Characters Number Display Letter Display Letter Display ℃ ZSME100000117 01008044...
