Operation Manual
TOURNO compact 95
TOURNO compact 115
WD
TOURNO compact 95
4
WD
TOURNO compact 115
4
TOURNO 696.01-01
Original Operation Manual English
Models
TOURNO de Luxe 95
TOURNO de Luxe 115
TOURNO de Luxe 95
TOURNO de Luxe 115
WD
4
WD
4
Machine no.
As of 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOURNO de Luxe 95 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cramer TOURNO de Luxe 95

  • Page 1 Operation Manual Machine no. Models TOURNO compact 95 TOURNO de Luxe 95 TOURNO compact 115 TOURNO de Luxe 115 TOURNO compact 95 TOURNO de Luxe 95 TOURNO compact 115 TOURNO de Luxe 115 TOURNO 696.01-01 As of 2014 Original Operation Manual English...
  • Page 2: Table Of Contents

    Contents Important information .......................... 3 General ..........................3 Symbols ..........................3 Limitation of liability ........................ 3 Copyright ..........................3 Warranty ..........................3 Safety ..............................4 Use in compliance with intended purpose................4 Possible misuse ........................4 General sources of risks ......................4 2.3.1 Use and operation ....................
  • Page 3: Important Information

    Important information Symbols We are pleased that you have selected a machine from Cramer GmbH in Germany. DANGER ! Please read this Operation Manual before you use the This symbol cautions against an immediate machine for the first time and observe the notes and threat resulting in serious injuries or death if safety instructions.
  • Page 4: Safety

    Safety Use in compliance with intended purpose 2.3.3 Risks from motor operation • Do not touch any parts of the motor during or after The machine is approved as a mulching mower for mowing and mulching of grass areas. operation. Significant risk of burning by hot surfaces. •...
  • Page 5: Staff And Operator Qualification

    Staff and operator qualification 2.10 Environmental protection • Persons with physical, sensory or mental handicaps or • Oils, fuels, greases and filters shall be disposed of properly and separately in accordance with legal persons with insufficient experience or knowledge must regulations.
  • Page 6: Technical Data

    Technical data Models Tourno compact Tourno de luxe Machine data Motor Briggs & Stratton Honda GXV 502 ccm AVS* INTEK OHV 688 ccm 2-cylinder 12.8 kW / 17.4 PS / 3600 rpm 14.9 kW / 20.3 PS / 3300 rpm Power output Generator 9 Ampere...
  • Page 7: Design And Function

    Design and function 4.1 Brief description On the TOURNO model, the mowing mechanism is mounted in the front section. For better road adhesion and traction, the machine has a front-wheel drive and a double-axle drive for the four wheel drive version, respectively. The machine has an articulated steering via the rear wheels.
  • Page 8: Displays And Operating Elements

    4.3 Displays and operating elements Operating panel Ignition lock Put the ignition key into the ignition lock and turn it. O → Machine inopera+ve 1 → Machine in opera+on (motor is running) Throttle with choke Push throttle to the desired position. Choke Full throttle Idle...
  • Page 9 Motor-gear connection You may move the machine manually by setting the lever for the motor- gear connection as follows: Drive via motor Motor is decoupled, manual pushing is possible. The lever is located behind the left front wheel. On the all-wheel drive version only, there is a second lever behind the left rear wheel.
  • Page 10 Note! Do not transfer the machine with lowered front device. Receiver points The TOURNO model has two receiver points to mount Cramer accessory devices. Receiver point for trailer devices Receiver point for front devices TOURNO 696.01-01...
  • Page 11: Functions

    Opening the motor cover The motor cover can be lifted as follows: First tilt the driver's seat forward. Then unlock the motor cover using the twist handle and lift up the cover 4.4 Functions Tilt mower upward Overview ATTENTION ! Risk of entrapment when adjusting Lower the mowing mechanism to the ground.
  • Page 12 Lift the mowing mechanism with the pedal and engage it in the pedal lock. 10. Only now should you pull the mowing mechanism forward. 11. The guide pin is now in the fork. 12. Swivel up the mowing mechanism. TOURNO 696.01-01 12 of 26 As of 2014 Original Operation Manual English...
  • Page 13 13. Protect the mechanism from falling back down again by inserting the removed bolt and spring clip in the holes. Swivelling back the mowing mechanism 1. Remove the bolt and spring clip (from step 13). Caution! Always use one hand to hold up the upper end of the mowing mechanism. 2.
  • Page 14 Adjustment rod for inclination setting For optimum mulching, the mowing mechanism should be inclined forward. B1: Release the catch spring from the adjustment rod and pull it slightly upward. B2: Remove the catch spring from its fixture. B3: For setting, loosen the adjustment rod bolt on one side.
  • Page 15 V-belt tensioning Readjusting the mowing mechanism 1. Loosen the lock nut (2). 2. Loosen the nut (1). 3. The belt can be tensioned by adjusting the tensioning screw (3). 4. Secure: first tighten the nut (1), then the lock nut (2). TOURNO 696.01-01 15 of 26 As of 2014...
  • Page 16: Working Position And Areas Of Risk

    • Do not expose it to aggressive materials. • Clean machine with a soft brush before start up. First commissioning (first inspection of the machine) after installation Installation and first commissioning shall be performed by your authorized Cramer dealer. Safety Assembly...
  • Page 17: Operation

    Operation Activities prior to use • Remove any obstacles (toys, stones, etc.) • Top up with petrol. Start and stop Basic prerequisites for switching on the machine 1. Occupy the driver's seat 2. Raise the mowing mechanism 3. Start the machine Indicator lamps lit.
  • Page 18: Normal Operation

    Normal operation Risks when mowing on slopes Tips for driving on slopes WARNING ! • Never drive sideways to the slope. Risk of tipping over! Risk of injuries by highly flammable • Always drive up and down the line of fall. •...
  • Page 19: Maintenance

    Maintenance Safety Maintenance work 7.2.1 Machine cleaning DANGER ! The machine should be cleaned regularly so that damage to Risk of injury by inappropriately the paint coating or plastic components can be detected. performed maintenance work! Please observe the notes listed for cleaning in order to avoid damage to the electronics.
  • Page 20: Troubleshooting

    Troubleshooting Safety Service address Procedure for failures and accidents Please contact your sales consultant in case of failures, Initiate emergency stop (leave working position). problems or otherwise. Please always indicate the machine Stop the machine. serial no. in inquiries. (Please refer to nameplate on the Determine the failure cause.
  • Page 21: Assembling The Mowing Mechanism

    Assembling the mowing mechanism Overview Receiver point for carrier Fork Hole for bolt with spring clip Hole for deflection rod V-belt fixture Mower 95 Deflection rod for lifting mower Lever for V-belt tensioning Hole for bolt with spring clip Star handle screw Guide pins Allen screws Cover...
  • Page 22 A1: Assembling the swivel frame Remove the two Allen screws from the swivel frame Place the swivel frame vertically onto the receiver point from above Lower the swivel frame Insert the two Allen screws back into the same holes (the screw heads must be on the inside).
  • Page 23 A2: Hooking up the mowing mechanism Loosen the two star handle screws and remove the V-belt guard from the mowing mechanism Push the mowing mechanism under the swivel arm. 10. Raise the mowing mechanism at the back and push the steel tongue into the rectangular opening in the machine.
  • Page 24 12. The lever of the V-belt tensioner is set to slack. 13. Place the V-belt onto the belt pulley. A2: Setting the mowing mechanism 14. Shift the lever of the V-belt tensioner. The V-belt is tensioned in this position. 15. The basic tension must be increased if necessary.
  • Page 25 16. Set the height to position 1. 17. The inclination of the entire mowing mechanism must now be set. See also Section 4.4 Functions, Adjustment rod for inclination setting. 18. The V-belt guard is attached again at the original location using the two star handle screws.
  • Page 26: Eu Declaration Of Conformity Pursuant To Machine Directive 2006/42/Ec Annex Ii 1-A

    EU Declaration of conformity pursuant to machine directive 2006/42/EC Annex II 1-A The manufacturer / distributor Cramer GmbH Reimersstr. 36 D-26789 Leer herewith declares, that the following product Manufacturer: Cramer GmbH Reimersstr. 36 D-26789 Leer Product designation: Mulching mower Make:...
