  • Page 1 MX-22 & MX-24 LED-Backlit Display User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information FCC Declaimers ............................4 WEEE ............................... 5 EMC Information ............................6 Precautions Notice ............................... 9 Cautions When Setting Up ........................10 Cautions When Using ..........................11 Cleaning and Maintenance ........................11 Notice for the LCD Display ........................12 Chapter 1: Product Description 1.1 Package Contents ..........................

  • Page 3: Fcc Declaimers

    Chapter 6: Appendix 6.1 Warning Messages ..........................48 6.2 Troubleshooting ..........................49 6.3 Transporting the LCD Display ......................51 Chapter 7: Specifications 7.1 Display Specifications ........................52 7.2 Display Dimensions ..........................53 7.2.1 MX-22 Dimensions ........................53 7.2.2 MX-24 Dimensions ........................53...

  • Page 4: Safety Information

    SAFETY INFORMATION FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to compl with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Weee

    SAFETY INFORMATION WEEE Information for users applicable in European Union countries. The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources.

  • Page 6: Emc Information

    Guidance and manufacturer’s declaration – electromagnetic emissions The MX-22 and MX-24 is intended for use in the electromagnetic environment specified below. The customer or the user of the MX-22 and MX-24 should assure that it is used in such an environment. Not Life-supporting Medical Equipment.
  • Page 7 Guidance and manufacturer’s declaration – electromagnetic immunity The MX-22 and MX-24 is intended for use in the electromagnetic environment specified below. The customer or the user of The MX-22 and MX-24 should assure that it is used in such an environment. Not Life-supporting Medical Equipment.
  • Page 8 Recommended separation distances between portable and mobile RF communications equipment and the MX-22 and MX-24 The MX-22 and MX-24 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the MX-22 and MX-24 can help prevent...

  • Page 9: Precautions

    PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symbols used in this manual This icon indicates the existence ISO 7010-M002: Follow instructions of a potential hazard that could for use result in personal injury or damage to the product. This icon indicates important This icon indicates complies with the operating and servicing...

  • Page 10: Cautions When Setting Up

    PRECAUTIONS Cautions When Setting Up Do not place the LCD display near heat sources, such as a heater, exhaust vent, or in direct sunlight. Do not cover or block the ventilation holes in the housing. Place the LCD display on a stable area. Do not place the LCD display where it may subject to vibration or shock.

  • Page 11: Cleaning And Maintenance

    This may result in scratching the surface of the glass. AG Neovo for consultations and solutions to help ensure a most Do not attempt to service the LCD display yourself, refer to qualified service personnel.
  • Page 12 This is acceptable and is not considered a failure. The intended use of the MX-22,MX-24 is to serve as a LCD monitor for integration with the hospital system. It is designed for general purpose for adults using at hospital environment,continuous operation. For displaying and viewing of images for reference.
  • Page 13 PRECAUTIONS Notice for the LCD Display Use a power cord that matches the voltage of the power outlet, which has been approved and complies with the safety standard of your particular country. The single device output analog signals through ADC element (Analog DigitalConvert) conversion to become a digital signal and the video signal is via Video Decorder conversion.

  • Page 14: Chapter 1: Product Description

    Must use only the supplied power adapter: ♦ Adaptor Technology MX-22 & MX-24 Model no.: ATM065-P120 Quick Start Guide Rating: 12V/5A MX-22 & MX-24 LED-Backlit Display MX-22/MX-24_Quick Guide_V010 ♦ Adaptor Technology www.agneovo.com Model no.: ATM065T-P120 Rating: 12V/5A Power cord VGA cable ♦...

  • Page 15: Wall Mounting Installation Preparation

    75mm other horizontal surface overhead are strongly advised to contact AG Neovo for consultations and solutions to help ensure a most pleasurable and fulfilling display 1.2.2 Removing the Base Stand experience.

  • Page 16: Lcd Display Overview

    PRODUCT DESCRIPTION 1.3 LCD Display Overview 1.3.1 Front View and Keypad Buttons Display screen Hot Key: PIP Select The LCD display screen is protected by NeoV Optical Glass. • Press repeatedly to select PIP option. • During OSD menu selection, press to move up a menu or submenu.

  • Page 17: Rear View

    PRODUCT DESCRIPTION 1.3.2 Rear View DC IN HDMI DisplayPort AUDIO IN DC power input DisplayPort connector Use to connect the power cord. Use to connect a PC using a DisplayPort cable for digital input signal. DVI connector VGA connector Use to connect a PC using a DVI cable Use to connect a PC using a VGA cable for for digital input signal.

  • Page 18: Chapter 2: Making Connections

    CHAPTER 2: MAKING CONNECTIONS Chapter 2: Making Connections 2.1 Connecting the Power Connect the power cord to the power adapter. Connect the power adapter to the DC power input at the rear of the LCD display. Connect the power cord plug to a power outlet or a power supply. DC IN Caution: ♦...

  • Page 19: Connecting Input Source Signals

    MAKING CONNECTIONS 2.2 Connecting Input Source Signals 2.2.1 Connecting a Computer Using VGA Cables Connect one end of a VGA cable to the VGA connector of the LCD display and the other end to the VGA connector of the computer. Using DVI Cables Connect one end of a DVI cable to the DVI connector of the LCD display and the other end to the DVI connector of the computer.

  • Page 20: Using Displayport Cables

    MAKING CONNECTIONS Using DisplayPort Cables Connect one end of a DisplayPort cable to the DisplayPort connector of the LCD display and the other end to the DisplayPort connector of the computer. DisplayPort Using Audio Cables Connect one end of an audio cable to the audio port at the rear of the LCD display and the other end to the audio out port of the computer.

  • Page 21: Connecting A Video Device

    MAKING CONNECTIONS 2.2.2 Connecting a Video Device Using HDMI Cables Connect one end of an HDMI cable to the HDMI connector of the LCD display and the other end to the HDMI connector of your device. HDMI...

  • Page 22: Chapter 3: Using The Lcd Display

    CHAPTER 3: USING THE LCD DISPLAY Chapter 3: Using the LCD Display 3.1 Turning on the Power Note: ♦ The LCD display still consumes POWER button power as long as the power LED indicator cord is connected to the power outlet.

  • Page 23: Adjusting The Volume

    USING THE LCD DISPLAY 3.3 Adjusting the Volume VOLUME buttons Touch the button to call out the volume bar. Touch the button to increase volume or the button to decrease volume. To mute the audio, set the volume to 0. 3.4 Locking the OSD Menu Lock the OSD menu to protect the LCD display from unauthorised users or from accidentally pressing the keypad.

  • Page 24: Using Picture-In-Picture (Pip)

    USING THE LCD DISPLAY 3.5 Using Picture-in-Picture (PIP) The Picture-in-Picture (PIP) feature allows viewing of more than one input source signal on the LCD display. 3.5.1 PIP Options Touch the button repeatedly to enable and scroll among the PIP options. Options are as follows: •...

  • Page 25: Pip Swap

    USING THE LCD DISPLAY 3.5.2 PIP Swap The main and the sub source signals set in PIP Setting can be easily swapped using the keypad. Note: Sub source ♦ PIP Swap can only be executed Main source if PIP is enabled, see page 40. Touch the button to swap the main source and the sub source signals.

  • Page 26: Chapter 4: On Screen Display Menu

    CHAPTER 4: ON SCREEN DISPLAY MENU 4.1 Using the OSD Menu Operation Display the main menu screen. Touch 1 9 2 0 x 1 0 8 0 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R...
  • Page 27 ON SCREEN DISPLAY MENU Operation Select the submenu item. Touch the button. 0 x 1 0 8 0 6 0 H z B R I G H T N E S S R I G H T N E S S C O N T R A S T O L O U R T E M P .

  • Page 28: Osd Menu Tree

    ON SCREEN DISPLAY MENU 4.2 OSD Menu Tree 1 9 2 0 x 1 0 8 0 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R T E M P .
  • Page 29 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 4. ASPECT RATIO • ASPECT RATIO See page 38. • H. ZOOM • V. ZOOM • OVERSCAN 5. PIP SETTING • PIP See page 39. • MAIN SOURCE • SUB SOURCE • SUB PICTURE SIZE •...
  • Page 30 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 12. LANGUAGE Select the OSD language: EN / FR / DE / ES / IT / PY / RO / PL / CS / NL / 简中 / 繁中 13. INFORMATION Displays settings information such as Input, Resolution, Horizontal Frequency, Vertical Frequency, Timing Mode, and Firmware Version.

  • Page 31: Chapter 5: Adjusting The Lcd Display

    CHAPTER 5: ADJUSTING THE LCD DISPLAY 5.1 BRIGHTNESS 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z B R I G H T N E S S B R I G H T N E S S 2.
  • Page 32 ADJUSTING THE LCD DISPLAY Original Setting High Setting Low Setting BRIGHTNESS CONTRAST BLACK LEVEL...

  • Page 33: Colour Temp

    ADJUSTING THE LCD DISPLAY 5.2 COLOUR TEMP. 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z N E U T R A L W A R M B R I G H T N E S S 2.

  • Page 34: Image Setting

    ADJUSTING THE LCD DISPLAY 5.3 IMAGE SETTING 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z S H A R P N E S S B R I G H T N E S S 2.
  • Page 35 ADJUSTING THE LCD DISPLAY Item Function Operation Range Adjusts black and white levels for video. FULL Touch the button to LIMIT select the setting. Note: This menu option is only available if the input source is HDMI. Signal source from PC - PC signal at a full range (Grayscale 0-255) state: COLOUR RANGE Monitor OSD colour range: Full Monitor OSD colour range: Limit...
  • Page 36 ADJUSTING THE LCD DISPLAY Item Function Operation Range H. POSITION Moves the screen image to the left (Horizontal Position) or right. V. POSITION Moves the screen image up or down. (Vertical Position) Adjusts the phase timing to Touch the button to synchronise with the video signal.

  • Page 37: Aspect Ratio

    ADJUSTING THE LCD DISPLAY 5.4 ASPECT RATIO 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z A S P E C T R A T I O F U L L B R I G H T N E S S 2.

  • Page 38: Pip Setting

    ADJUSTING THE LCD DISPLAY 5.5 PIP SETTING 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z P I P O F F B R I G H T N E S S 2.
  • Page 39 ADJUSTING THE LCD DISPLAY Note: Any input signal may be set as the main or the sub source signal. However, some input signals are not supported to be paired together as the main and the sub source signals. Refer to the following table for compatibility options. Table 5.1 PIP Compatibility Table Main Source Input Source...

  • Page 40: Anti-Burn-In

    ADJUSTING THE LCD DISPLAY 5.6 ANTI-BURN-IN 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z E N A B L E O F F B R I G H T N E S S 2.

  • Page 41: Osd Setting

    ADJUSTING THE LCD DISPLAY 5.7 OSD SETTING 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z T R A N S P A R E N C Y B R I G H T N E S S 2.

  • Page 42: Audio Setting

    ADJUSTING THE LCD DISPLAY 5.8 AUDIO SETTING 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z V O L U M E B R I G H T N E S S 2.

  • Page 43: System

    ADJUSTING THE LCD DISPLAY 5.9 SYSTEM 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z P O W E R S A V I N G O F F B R I G H T N E S S 2.
  • Page 44 Note: This menu option is only available if the input source is HDMI. Enables or disables the logo feature. If the setting is set to ON, the AG Neovo LOGO logo is briefly displayed after the display is powered on.

  • Page 45: Eco Smart

    ADJUSTING THE LCD DISPLAY 5.10 ECO SMART With the built-in EcoSmart sensor, users can enable the Eco Smart feature to automatically adjust the LCD screen brightness according to the ambient light. This feature comforts the eyes and helps optimise energy efficiency.

  • Page 46: Input Select

    ADJUSTING THE LCD DISPLAY 5.11 INPUT SELECT 1. Touch to call out the OSD window. 1 9 2 0 x 1 0 8 0 6 0 H z V G A D V I B R I G H T N E S S 2.

  • Page 47: Chapter 6: Appendix

    CHAPTER 6: APPENDIX 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh rate of • Change the resolution or the the graphics card of the computer refresh rate of the graphics I N P U T S I G N A L O U T O F R A N G E is set too high.

  • Page 48: Troubleshooting

    APPENDIX 6.2 Troubleshooting Problem Possible Cause and Solution No picture. • Check if the LCD display is turned ON. • Check if the power cord is properly connected to the LCD display. • LED indicator is OFF. • Check if the power cord is plugged into the power outlet. •...
  • Page 49 APPENDIX Problem Possible Cause and Solution Mist formed inside the • This happens due to humid weather conditions. This is a normal glass surface. occurrence. The mist will disappear after a few days or as soon as the weather stabilizes. Faint shadows from a •...

  • Page 50: Transporting The Lcd Display

    APPENDIX 6.3 Transporting the LCD Display To transport the LCD display for repair or shipment, place the display in its original packaging carton. Put all the accessories in the box (if necessary). Place the two foam cushions on each side of the LCD display for protection. Place the LCD display down in the box.

  • Page 51: Chapter 7: Specifications

    CHAPTER 7: SPECIFICATIONS 7.1 Display Specifications MX-22 MX-24 Panel Panel Size 21.5” 23.6” Max. Resolution 1920 x 1080 Pixel Pitch 0.24825 mm 0.2715 mm Brightness 250 cd/m 300 cd/m Contrast Ratio 2,000,000:1 (DCR) Viewing Angle (H/V) 170°/160° (Typical) Display Colour 16.7M...

  • Page 52: Display Dimensions

    562.4(outline dimens ion) 227.4 227.4 538.55 522.3(opening dimension) 16.25 16.25 (M4xL10) x8 281.2 277.4 137.4 137.4 227.4 AG Neovo Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan. Copyright © 2017 AG Neovo. All rights reserved. MX-22/MX-24_UM_V010...
