Table 13: DANL frequencies of interest
RSA306 center
frequency
100 kHz
1 MHz
10 MHz
20 MHz
22 MHz
100 MHz
500 MHz
1 GHz
1.5 GHz
2.0 GHz
2.5 GHz
3.0 GHz
3.5 GHz
4.0 GHz
4.5 GHz
5.0 GHz
5.5 GHz
6.0 GHz
6.2 GHz
RSA306 Specifications and Performance Verification
Marker noise
level
Specification
< –130 dBm/Hz
< –130 dBm/Hz
< –130 dBm/Hz
< –130 dBm/Hz
< –160 dBm/Hz
< –160 dBm/Hz
< –160 dBm/Hz
< –160 dBm/Hz
< –158 dBm/Hz
< –158 dBm/Hz
< –155 dBm/Hz
< –155 dBm/Hz
< –155 dBm/Hz
< –155 dBm/Hz
< –150 dBm/Hz
< –150 dBm/Hz
< –150 dBm/Hz
< –150 dBm/Hz
< –150 dBm/Hz
Performance verification
30
