General

General Fronius Datamanager 2.0 is a network-compatible datalogger which combines the func-
tionality of the Fronius Com Card, the Fronius Datalogger Web, the Fronius Power Control
Card, and the Fronius Modbus Card on one plug-in card.
Fronius Datamanager 2.0 website provides a quick overview of the photovoltaic system.
The website can be accessed with a web browser via a direct connection or on the internet,
if properly configured.
Fronius Datamanager 2.0 is equipped with an easy-to-configure system monitoring feature
with an automatic alarm. The alarm can be signaled via SMS or e-mail.
When connected to Fronius Solar.service, real-time photovoltaic system data as well as
archived data can be saved to a PC and analyzed. You can also make settings to all de-
vices in Fronius Solar Net.
When connected to Fronius Solar.web, the real-time and archived data of a photovoltaic
system can be easily accessed via the internet or the Fronius Solar.web App. No difficult
configuration is required. Data is sent automatically from Fronius Datamanager 2.0 to Fro-
nius Solar.web.
Available Ver- Fronius Datamanager 2.0 is available in the following versions:
sions of Fronius
Datamanager 2.0 -
-
-
Provided that the inverter is not fitted as standard with Fronius Datamanager 2.0, existing
inverters can be upgraded with the Fronius Datamanager 2.0 plug-in card.
Fronius Datamanager Box 2.0 is designed for inverters without plug-in card slots.
Applicable DAT- The Fronius Datamanager 2.0 plug-in card installed in the inverter or the separate Fronius
COM Compo- Datamanager Box 2.0 can be operated with the following DATCOM components:
nents
without Fronius Com Card function
(for Fronius Galvo Fronius Symo, and Fronius Primo inverters)
with Fronius Com Card function
(for Fronius IG, Fronius IG Plus, Fronius IG Plus V,
Fronius IG Plus A, Fronius CL, Fronius CL USA, Fronius IG 300–500 inverters)
in external housing with Fronius Solar Net IN and Fronius Solar Net OUT connection
sockets
(Fronius Datamanager Box 2.0, e.g. for inverters without plug-in card slots or for pho-
tovoltaic systems with a separate Fronius Datamanager 2.0)
- up to 100 x Fronius inverters
(incl. the inverter in which Fronius Datamanager 2.0 is installed)
- up to 10 x Fronius Sensor Card or Fronius Sensor Box
- up to 10 x Fronius Public Display Card or Fronius Public Display Box
- up to 1 x Fronius Interface Card or Fronius Interface Box
- up to 200 x Fronius String Control
