8. Functions and operation
- COLOR: You can select up to 16 PRIVACY color.
- RETURN : Select this to save the PRIVACY menu setting and return to the SPECIAL
menu.
(6) SYNC
In areas where the supply is at 60Hz, you can synchronize
the output phase of multiple cameras using the power
synchronization function (Line-Lock) without using a
synchronization signal generator.
.... Note
5PE
r
R~
~-
+.
r ~; ~
~
r
~"~
E
.J
~ ,,~"!3::: .J
-
~
L'"
:1'.
" He
~ ~
, . r
~,.
. . .
-
"'''-,,-~
. .Jf: >-"
~
t'
~r· ~'2'" ~ .J
• When using AC power at 60Hz frequency, you c an use the L/L type synchronization.
• When the power is DC 12V, the SYNC. menu is fixed to the 'INT' mode.
(7) LANGUAGE
You can se lect the menu language according to you
requiremen ts.
- ENGLISH / KOREAN / JAPANESE / CHI NESE1,2
(8) RETURN
SPEC RL
~
••• E
r
~ F ~ .J
~
«';'-<6; .J
-
-,::;"
:-,
~
""2
~ H~ ':l
>- r
C _ -"[ -.
,. ~ ~-"'[L.""JE ~" ~ ~H
:<
>2E
T
",I<''' p~' .J
Select this to save the SPECIAL menu settings and return to the SETUP menu.
8-9, ADJUST
(1)
SHARPNESS
As you increase this value, the picture ou tline becomes
stronger and clearer. Adjust this value appropriately
depending on the sharpness of the picture.
(2) BLUE
Bl ue color gain adjustable.
(3) RED
Red color gain adjustable.
8-10. RESET
Resets the camera settings to the factory defaults.
8-11. EXIT
i1DuuS
T
..
~-,,~I'~
t
o
t '
",-:::'
.
....
"t
T <'"
P
.J
Press the SET button in the EXIT menu to save the current setting s and exit the
SETUP menu.
9. Troubleshooting
If there are problems in operating, please refer to the checklist below . If the problem
persists, please contact the agent where thi s product is purchased.
Problems Troubleshooting
Nothing appears on the screen . • Please check that the power cord and line
connection between the camera and monitor are
fixed properly.
• Please check that you have properly connected
VIDEO cable to the camera VIDEO output jack .
The image on the screen is dim.
• Is lens stained with dirt? Clean your lens with soft.
clean cloth .
• Set the monitor to proper condition .
• If the camera is exposed to too strong light. c hange
the camera position.
The image on the screen is
• Adjust the con trast feature of the monitor.
dark. • If you have an intermediate device, set the 75Q
/ Hi-z properly.
The camera is not working • Please check that you have properly connected the
properly, and the surface of the ca mera to an appropriate power source.
camera is hot.
The DAY/NIGHT menu does • Please c heck that AGC of EXPOSURE SETUP menu
not work. is 'OFF'.
The SENS-UP function does • Please check that AGC of EXPOSURE SETUP menu
not work. is 'OFF'.
• Please check that SHUTTER of EXPOSURE SETUP
menu is 'FLK' or 'MANUAL' .
The MOTION DETECTION • Please check if MOTION DETECTION function is
function is not working. turned on.
• Please check if MD LEVEL is to o low.
• Please check the setting of the MD area.
Color is not correct. • Please check the setting of WHITE BAL SETUP
menu.
The screen flickers continually. • Please c heck that direction of camera turns toward
the Sun.
