Pointer Lock Function
The Pointer Lock switch freezes the pointer's position and is used as a 'data hold' feature.
This feature is useful in dimly lit or hard to reach locations.

Specifications

Function
AC Current
(50/60Hz)
AC Voltage
(50/60Hz)
DC Voltage
Resistance
Temperature
Clamp jaw opening
Display
Input Impedance
AC bandwidth
Temperature Probe
Operating conditions
Operating Altitude
Battery
Fuse
Dimensions & Weight
Safety
Standards
Ranges
6, 15, 60, 150 A
600 A
150, 300 and 750V
75 V DC
2000 Ω (50 Ω mid-scale) (Rx1)
200 kΩ (5 kΩ mid-scale) (Rx100)
-4 to 302°F (-20°C to 150°C)
1.3" (34 mm) max.
Analog with Zero Adjustment
ACV: 2 kΩ/V, DCV: 4.5 kΩV
50 / 60 Hz
Thermistor
Temperature 32 - 104°F (0 - 40°C); Relative Humidity <80%
7000 ft. (2000 m) maximum.
One (1) 1.5V 'AA' Battery
500 mA, 250V fast
8.4 x 3.4 x 1.7" (214 x 85 x 43 mm); 12.4 oz. (350 g)
For indoor use and in accordance with the requirements for
double insulation to IEC1010-1 (2001): EN61010-1 (2001)
Overvoltage Category II 600V, Pollution Degree 2.
C C
Accuracy
± 3% of Full Scale
± 5% of Full Scale
± 3% of Full Scale
± 3% of Full Scale
± 3% of Full Scale Length
± 3% of arc
6 AM600 V2.0 6/07
