APPENDICES

Appendix A. Technical Specifications

Operating Temperature
Tip
System
Storage Temperature
Relative Humidity
Waterproof
Hazardous Environments
Camera
Diameter Probe
Image Sensor
Pixel Count
Housing
System
System Dimensions
Case Dimensions (Standard)
System Weight
Construction
LCD Monitor
Joystick Control
Button Set
Audio
Internal Memory
Data I/O Ports
Video Out
68
-25ºC to 100ºC (-13ºF to 212ºF). Reduced articulation below 0ºC (32ºF)
-20º to 46ºC (-4ºF to 115ºF). LCD may require warm-up period below 0ºC (32ºF).
-25º to 60ºC (-13ºF to 140ºF)
95% max, non-condensing
Insertion tube and tip to 14.7 psi (1 bar, 10.2 m of H2O, 33.5 ft of H2O).
Not rated for use in hazardous environments.
4.0 mm (0.16"), 6.1 mm (0.24"),
1/6" Color SUPER HAD™ CCD camera (6.1) 1/10" (4.0 mm)
440,000 pixels
Titanium
17.1 x 33.8 x 87.1 cm (6.75 x 8 x 15")
48.8 x 38.6 x 18.5 cm (19.2 x 15.2 x 7.3")
In small case with contents: 10.2 kg (22.4 lbs). In large case with contents: 19.6 kg (43.2 lbs).
Out of Case: 6120 system - 3.0 kg (6.7 lbs). 6110 system - 4.0 kg (8.7 lbs).
Magnesium and Polycarbonate housing with integrated elastomeric bumpers
Integrated (6.5") active matrix XGA color LCD, daylight readable display, with optically-
bonded, multipoint capacitive Dragontrail™ touchscreen.
360º All-Way® tip articulation, menu access, and navigation
Access user functions, measurement, and digital functions
Integrated 3.5mm headset / microphone jack or bluetooth headset
16 GB SSD for user storage
Two USB 3.0 host 'A' ports, one USB 3.0 client micro 'B' port,
DisplayPort
07/30/2014
