Supplying Power to the Visual iQ

The Visual iQ is powered by a 10.8 V (nominal), 73 Wh, 6.8 Ah Lithium Ion battery.
The battery is charged by connecting the power adaptor to the battery, then connecting
the supplied AC-to-DC power adaptor to a suitable (100-240 VAC, 50-60 Hz, <1.5 A rms)
AC power source. The power adaptor delivers to the battery 18 Volts at 3.34 Amps.
Note: When powering a system with an AC power source, connect the power plug to a
properly grounded source for reliable touchscreen operation.
Powering the Visual iQ On and Off
System Power On
Press and hold until the unit turns on. The buttons and Liquid Crystal Display (LCD)
will light and begin the power-up sequence. After approximately 35 seconds, the system
screen will display live video and on-screen controls. The system is now ready for use.
Note: All batteries are shipped with a partial charge. Batteries should be fully charged
prior to use.
System Power Off
Touch the lower left corner of the display screen (which typically contains the on-screen
1
GE Logo ( ) or the hard key at any time to open or close the Global Menu, which
2
provides access to several features including Shut Down ( ). Select Shut Down to power
off the Visual iQ.
Caution—Do not power off the Visual iQ by removing its battery. Only remove
battery after powering off as described above.
15
07/30/2014
