1. Introduction

This is the user manual of 9600IP. Some configuration should be done before
use the 9600IP phone, and then it can work normally. This manual will illustrate how
to set the phone through keyboard and web service.

1.1 Overview of Hardware

1.1.1
The two RJ-45 network interface support the 10/100M Ethernet. The default
WAN interface is a DHCP Client server. User connect the WAN interface to ADSL or
switch, and connect the LAN interface （the default IP address is 192.168.10.1) to
the computer. You can use the administrator's user name "admin" and password
"admin" to login and set.
1.1.2
Only the WAN interface supports the POE.

1.2 Overview of Software

Network Protocol
SIP v1(RFC2543)
l
v2(RFC3261)
IP/TCP/UDP/RTP/RTCP
l
IP/ICMP/ARP/RARP/SNTP
l
TFTP Client/DHCP Client/PPPOE
l
Client
Telnet/HTTP Server
l
DNS Clients
l
Codec
G.711： 64K bit/s(PCM)
l
G.723.1： 63k/5.3k bit/s
l
G.726： 16k/24k/32k/40k
l
bit/s(ADPCM)
G.729A： 8k bit/s(CS-ACELP)
l
G.729B： adds VAD & CNG to G.729
l
Voice Quality
VAD： Voice activity detection
l
CNG： Comfortable noise generator
l
LEC： Line echo canceller
l
Packet Loss Compensation
l
Adaptive Jitter Buffer
l
Call Function
Call Hold
l
Call Waiting
l
Tone
Ring Tone
l
Ring Back Tone
l
Dial Tone
l
Busy Tone
l
Phone Function
Volume Adjustment
l
Speed dial key
l
Phonebook
l
IP Assignment
IP (Static IP)
l
DHCP
l
PPPoE
l
Security
HTTP 1.1 basic/digest
l
authentication for Web setup
MD5 for SIP authentication
l
(RFC2069/RFC2617)
QoS
QoS field
l
NAT Traversal
STUN
l
Configuration
5
