Tektronix 371B Service Manual page 282

Mechanical Parts List
Replaceable mechanical parts list (Cont.)
Fig. &
Tektronix part Serial no.
index
number effective
number
-27 344-0396-XX
-28 407-3472-XX
-29 211-0038-XX
-30 407-3484-XX
-31 211-0038-XX
-32 260-2324-00
-33 213-0986-XX
-34 210-0054-XX
-35 210-0938-XX
-36 198-5616-00
-37 210-0457-XX
-38 342-0841-XX
-39 211-0007-XX
-40 407-3635-XX
-41 211-0038-XX
-42 122-0183-XX
-43 211-0038-XX
-44 426-2422-XX
-45 200-0103-XX
-46 355-0507-XX
-47 210-0455-XX
-48 210-0046-XX
-49 333-3514-XX
-50 426-2213-XX
-51 210-0586-XX
9-32
Serial no.
discont'd Qty Name & description
3 CLIP,CABLE:PVC
2 BRACKET,ANGLE:LOWER,PANEL
(ATTACHING PARTS)
4 SCREW,MACHINE:4-40 X 0.312,FLH,STL
(END ATTACHING PARTS)
2 BRACKET,SW MTG:ALUMINUM
(ATTACHING PARTS)
4 SCREW,MACHINE:4-40 X 0.312,FLH,STL
(END ATTACHING PARTS)
2 SW,SENSITIVE:SPDT,3A,250VAC,INTERLOCK:(S600,S602)
(ATTACHING PARTS)
4 SCREW,MACHINE:2-26 X 12MM,HEX,BRS
4 WASHER,LOCK:#4 SPLIT,0.025 THK STL
4 WASHER,FLAT:0.109 ID X 0.25 OD X 0.032,STL
(END ATTACHING PARTS)
1 WIRE SET,ELEC:371B:(W920)
(ATTACHING PARTS)
1 NUT,PL,ASSEM WA:6-32 X 0.312,STL
(END ATTACHING PARTS)
1 INSULATOR,CONN:H.V.,NYLON
(ATTACHING PARTS)
2 SCREW,MACHINE:4-40 X 0.188,PNH,STL
(END ATTACHING PARTS)
1 BRACKET,CMPNT:ALUMINUM
(ATTACHING PARTS)
2 SCREW,MACHINE:4-40 X 0.312,FLH,STL
(END ATTACHING PARTS)
1 ANGLE,RAIL:SUBPANEL MTG,LEFT
(ATTACHING PARTS)
2 SCREW,MACHINE:4-40 X 0.312,FLH,STL
(END ATTACHING PARTS)
1 SUBPANEL,TEST F:FDD,ALUMINUM
1 NUT,PLAIN,KNURL:0.25-28 X 0.375 OD,BRASS
1 STUD,SHOULDERED:BINDING POST,BRS
(ATTACHING PARTS)
1 NUT,PLAIN,HEX:0.25-28 X 0.375,BRS
1 WASHER,LOCK:0.261 ID,INTL,0.018 THK,STL
(END ATTACHING PARTS)
1 PANEL,FRONT:371B,PWR SW
1 SUBPANEL,FRONT:PWR SW
(ATTACHING PARTS)
2 NUT,PL,ASSEM WA:4-40 X 0.25,STL
(END ATTACHING PARTS)
Mfr.
code Mfr. part number
80009 3440396XX
80009 4073472XX
TK0435 ORDER BY DESC
80009 4073484XX
TK0435 ORDER BY DESC
80009 260232400
80009 2130986XX
86928 ORDER BY DESC
TK0413 ORDER BY DESC
TK0191 ORDER BY DESC
TK0435 ORDER BY DESC
TK0DK 30-0073
TK0435 ORDER BY DESC
TK0CA 30-0018
TK0435 ORDER BY DESC
80009 1220183XX
TK0435 ORDER BY DESC
80009 4262422XX
TK0588 ORDER BY DESC
TK0588 ORDER BY DESC
73743 3089-402
78189 1214-05-00-0541
80009 3333514XX
TK019 4262213XX
1
TK0435 ORDER BY DESC
