Tektronix 371B Service Manual page 263

Replaceable mechanical parts list
Fig. &
Tektronix part Serial no.
index
number effective
number
2-1 200-3281-XX
-2 200-3276-XX
-3 211-0538-XX
-4 378-0276-XX
-5 361-1381-XX
-6 337-3328-XX
-7 426-2133-XX
-8 211-0512-XX
-9 343-1269-XX
-10 212-0022-XX
-11 343-1270-XX
-12 212-0022-XX
-13 331-0491-XX
-16 670-9324-01
670-9324-02
-17 211-0062-XX
-18 343-1268-XX
-19 378-0614-XX
-20 214-3886-XX
-21 154-0928-00
-22 253-0267-XX
-23 253-0137-XX
-24 426-A192-00
-25 211-0538-XX
-26 211-0541-XX
-27 214-3880-XX
-28 211-0661-XX
-29 255-1106-XX
-30 334-6691-XX
371B Service Manual
Serial no.
discont'd Qty Name & description
1 COVER,BEZEL:POLYCARBONATE,TEK TAN
1 BEZEL,CRT:PC,TEK TAN
(ATTACHING PARTS)
2 SCREW,MACHINE:6-32 X 0.312,FLH,STL
(END ATTACHING PARTS)
1 FILTER,LT,CRT:BLUE,108.4MM X 134.4MM X 1MM
1 SPACER,RING:CRT,0.4MM
1 SHIELD,CRT:CLEAR
1 FRAME,CRT:371B
(ATTACHING PARTS)
4 SCREW,MACHINE:6-32 X 0.5,FLH,100 DEG,STL
(END ATTACHING PARTS)
2 RETAINER,CRT:FRONT,(A)
(ATTACHING PARTS)
2 SCREW,MACHINE:8-32 X 1.5,PNH,STL
(END ATTACHING PARTS)
2 RETAINER,CRT:FRONT,(B)
(ATTACHING PARTS)
2 SCREW,MACHINE:8-32 X 1.5,PNH,STL
(END ATTACHING PARTS)
1 MASK,CRT:371B
2 CIRCUIT BD ASSY:LAMP(R):(A28)
CIRCUIT BD ASSY:LAMP(L):(A29)
(ATTACHING PARTS)
4 SCREW,MACHINE:2-56 X 0.312,PNH,STL
(END ATTACHING PARTS)
2 RETAINER,LIGHT:REFLECTOR
2 REFLECTOR,LIGHT:INT SCALE ILLUMINATION
2 SPRING,RTNR:SCALE LAMP
1 ELECTRON TUBE:CRT,P31,INT SCALE:(V100)
1 TAPE,PRESS SENS:0.08 X 20 X 20000MM,AL FOIL
1 TAPE,SILICONE:RED RBR,1.25 X 0.02
1 FRAME,FRONT:371B,ALUMINUM
(ATTACHING PARTS)
8 SCREW,MACHINE:6-32 X 0.312,FLH,STL
2 SCREW,MACHINE:6-32 X 0.25,FLH,100 DEG,STL
(END ATTACHING PARTS)
1 CONTACT,SPRING:GROUNDING CRT
(ATTACHING PARTS)
1 SCR,ASSEM WSHR:4-40 X 0.25,PNH,STL
(END ATTACHING PARTS)
1 PLASTIC CHANNEL:250 X 3.3 X 4.0MM,NYLON
1 MARKER,IDENT:MKD DANGER
Mechanical Parts List
Mfr.
code Mfr. part number
80009 2003281XX
80009 2003276XX
TK0435 ORDER BY DESC
80009 3780276XX
80009 3611381XX
80009 3373328XX
80009 4262133XX
TK0435 ORDER BY DESC
80009 3431269XX
TK0435 2011-300
80009 3431270XX
TK0435 2011-300
80009 3310491XX
80009 670932401
80009 670932402
TK0435 ORDER BY DESC
80009 3431268XX
0JR05 ORDER BY DESC
80009 2143886XX
80009 154092800
80009 2530267XX
99742 2650
80009 4262421XX
TK0435 ORDER BY DESC
TK0435 ORDER BY DESC
80009 2143880XX
TK0435 ORDER BY DESC
80009 2551106XX
80009 3346691XX
9-13
