Tektronix 371B Service Manual page 272

Mechanical Parts List
Replaceable mechanical parts list (Cont.)
Fig. &
Tektronix part Serial no.
index
number effective
number
-31 260-2323-00
-32 211-0751-XX
-33 174-0296-00
-34 211-0661-XX
-35 386-5485-XX
-36 211-0507-XX
-37 198-5749-00
-38 211-0661-XX
-39 386-5909-XX
-40 211-0507-XX
-41 441-1977-XX
-42 211-0507-XX
-43 211-0538-XX
-44 342-0785-XX
-45 211-0661-XX
-46 129-1139-XX
-47 670-9319-02
-51 343-1275-XX
-52 211-0661-XX
-53 671-B211-00
-54 211-0661-XX
-58 343-1288-XX
-59 441-1743-XX
-60 211-0504-XX
9-22
Serial no.
discont'd Qty Name & description
1 SWITCH,PUSH:DPST,15A,250V,ON/OFF:(S100)
(ATTACHING PARTS)
2 SCR,ASSEM WSHR:M3 X 8
(END ATTACHING PARTS)
1 CA ASSY,SP,ELEC:34,28 AWG,5.5 L,RIBBON:(W400)
(ATTACHING PARTS)
2 SCR,ASSEM WSHR:4-40 X 0.25,PNH,STL
(END ATTACHING PARTS)
1 PLATE,CONN MTG:FEMALE,STEEL
(ATTACHING PARTS)
2 SCREW,MACHINE:6-32 X 0.312,PNH,STL
(END ATTACHING PARTS)
1 WIRE SET,ELEC:371B W/D-SUB 50
CONT,FEMALE:(W410),(ATTACHING PARTS)
2 SCR,ASSEM WSHR:4-40 X 0.25,PNH,STL
(END ATTACHING PARTS)
1 PLATE,CONN MTG:FEMALE,STEEL
(ATTACHING PARTS)
2 SCREW,MACHINE:6-32 X 0.312,PNH,STL
(END ATTACHING PARTS)
1 CHASSIS,XFMR:REAR ASSY,ALUMINUM
(ATTACHING PARTS)
2 SCREW,MACHINE:6-32 X 0.312,PNH,STL
2 SCREW,MACHINE:6-32 X 0.312,FLH,STL
(END ATTACHING PARTS)
1 INSULATOR,PLATE:CRT OUTPUT
(ATTACHING PARTS)
4 SCR,ASSEM WSHR:4-40 X 0.25,PNH,STL
(END ATTACHING PARTS)
4 SPACER,POST:25MM L,W4-40 THD,BRASS
1 CKT BOARD ASSY:CRT OUTPUT(A18)
1 RETAINER,XSTR:HV,SST
(ATTACHING PARTS)
1 SCR,ASSEM WSHR:4-40 X 0.25,PNH,STL
(END ATTACHING PARTS)
1 CKT BOARD ASSY:HV REG(A20)
(ATTACHING PARTS)
4 SCR,ASSEM WSHR:4-40 X 0.25,PNH,STL
(END ATTACHING PARTS)
CKT BOARD ASSY INCLUDES:
1 CLAMP,CABLE:PLASTIC
1 CHASSIS,CRT:LEFT
(ATTACHING PARTS)
3 SCREW,MACHINE:6-32 X 0.250,PNH,STL
(END ATTACHING PARTS)
Mfr.
code Mfr. part number
80009 260232300
80009 2110751XX
80009 174029600
TK0435 ORDER BY DESC
80009 3865485XX
TK0435 ORDER BY DESC
80009 198574900
TK0435 ORDER BY DESC
80009 3865909XX
TK0435 ORDER BY DESC
80009 4411977XX
TK0435 ORDER BY DESC
TK0435 ORDER BY DESC
80009 3420785XX
TK0435 ORDER BY DESC
80009 1291139XX
80009 670931902
80009 3431275XX
TK0435 ORDER BY DESC
TK0191 671B21100
TK0435 ORDER BY DESC
80009 3431288XX
80009 4411743XX
TK0435 ORDER BY DESC
371B Service Manual
