Tektronix 371B Service Manual page 281

Replaceable mechanical parts list
Fig. &
Tektronix part Serial no.
index
number effective
number
6-1 333-3512-XX
-2 210-0586-XX
-3
136-0933-00
136-0934-00
-4 386-5607-XX
-5 213-0816-XX
-6 386-5609-XX
-7 210-0586-XX
-8 671-0305-01
-9 366-0626-XX
-10 366-0621-XX
-11 377-0609-XX
-12 213-0022-XX
-13 311-1624-00
-14 210-0583-XX
-15 210-0046-XX
-16 260-2497-02
-17 407-4014-XX
-18 210-0586-XX
-19 260-2379-00
-20 352-0858-XX
-21 407-3637-XX
-22 210-0457-XX
-23 426-2331-XX
-24 333-3887-XX
-25 122-0184-XX
-26 211-0038-XX
371B Service Manual
Serial no.
discont'd Qty Name & description
1 PANEL,FRONT:371B,LOWER
(ATTACHING PARTS)
4 NUT,PL,ASSEM WA:4-40 X 0.25,STL
(END ATTACHING PARTS)
11 SOCKET,PIN TERM:0.16 DIA,GRAY:
(J700,J702,J704,J706,J708,J710,J712,J714,J716,J720 )
SOCKET,PIN TERM:0.16 DIA,RED:(J718)
1 PLATE,CONN MTG:W/SPRING,PC
(ATTACHING PARTS)
4 SCREW,TPG,TC:2-56 X 0.188L,TYPE T,PNH,STL
(END ATTACHING PARTS)
1 PLATE,CONN SHLD:ALUMINUM
(ATTACHING PARTS)
6 NUT,PL,ASSEM WA:4-40 X 0.25,STL
(END ATTACHING PARTS)
1 CKT BOARD ASSY:CONNECTOR(A30)
1 KNOB:SILVER GRAY,12MM OD
1 SHELL,KNOB:TEKTAN,30MM OD X 15MM H,ABS
1 INSERT,KNOB:8.6MM ID X 16MM OD X 8MM H,AL
(ATTACHING PARTS)
1 SETSCREW:4-40 X 0.188,STL
(END ATTACHING PARTS)
1 RES,VAR,NONWW:10K OHM,10%,0.25W:(R626)
(ATTACHING PARTS)
1 NUT,PLAIN,HEX:0.25-32 X 0.312,BRS
1 WASHER,LOCK:0.261 ID,INTL,0.018 THK,STL
(END ATTACHING PARTS)
1 SWITCH,ROTARY:ENCODER:(S140)
1 BRACKET,SW MTG:ALUMINUM
(ATTACHING PARTS)
3 NUT,PL,ASSEM WA:4-40 X 0.25,STL
(END ATTACHING PARTS)
1 CIRCUIT BREAKER:1A,250V:(S800)
1 HOLDER,LED:PLASTIC
1 BRACKET,ELEC SW:ALUMINUM
(ATTACHING PARTS)
2 NUT,PL,ASSEM WA:6-32 X 0.312,STL
(END ATTACHING PARTS)
1 FRAME:POLYCARBONATE
1 PANEL,FRONT:FDD,POLYCARBONATE
1 ANGLE,RAIL:SUBPANEL MTG,RIGHT
(ATTACHING PARTS)
2 SCREW,MACHINE:4-40 X 0.312,FLH,STL
(END ATTACHING PARTS)
Mechanical Parts List
Mfr.
code Mfr. part number
80009 3333512XX
TK0435 ORDER BY DESC
TK0BW SLB4-F6.3-8
TK0BW SLB4-F6.3-1
80009 3865607XX
0KB01 ORDER BY DESC
80009 3865609XX
TK0435 ORDER BY DESC
80009 671030501
80009 3660626XX
80009 3660621XX
80009 3770609XX
0KB01 ORDER BY DESC
80009 311162400
73743 2X-20319-402
78189 1214-05-00-0541
80009 260249702
80009 4074014XX
TK0435 ORDER BY DESC
TK0BY T11-1RE-4-4-1.0
S4238 30-0603
TK0AP 30-0022
TK0435 ORDER BY DESC
80009 4262331XX
80009 3333887XX
80009 1220184XX
TK0435 ORDER BY DESC
9-31
